UNIT SPECIFICATIONS

Dimensions
BTUh
(with 85°F air
entering condenser
coil)
CFM
Cellar Size*
Duct Sizing
Weight
(lbs.)
Amps
(running)
dBA
In cellar: 40 • Adjacent to unit: 50
Installation
Fully ducted (attic or maintenance room)
Thermostat
Aftermarket (24V thermostat not included)
55°F temperature differential
Temp. Delta
(maintains proper cellar temperature when exhaust environment remains between 42°F and 110°F)
Outside Venting
Can be done if the outside temperature remains between 42°F and 110°F
Warranty
Two-year limited warranty (parts and labor)
* Sizing the Unit to the Room
The specification chart will provide information on the unit's cooling capacity. There are circumstances in which a cellar design may
require a larger unit due to preexisting design restrictions. Certain building materials such as glass, stone, or concrete may seem
adequate but do not offer the insulation capacity required to maintain the optimum temperature for storing wine. We recommend
purchasing a unit with a larger capacity to compensate for these design limitations. Undersized cooling units can lead to premature
failure and/or prevent the system from reaching the desired set temperature. As a result, undersized cooling units are not covered
under warranty.
Page 6 | 1-800-343-9463
PFD3300
15.75"H x 15.75"W x 37"L (without duct plenums)
22.75" H x 15.75" W x 48"L (duct plenums on top of unit)
15.75" H x 22.75" W x 48"L (duct plenums on side of unit)
4060
326 (top); 312 (side)
800 cu. ft.
8" supply
10" return
115
8.0
PFD4400
5521
326 (top); 312 (side)
1250 cu. ft.
8" supply
10" return
116
8.8
PFD8800
6025
340 (top); 335 (side)
2000 cu.ft
8" supply
10" return
125
12.6
