Summary of Contents for Dometic Xtreme NFB SHX7606
- Page 1 MECHANICAL MARINE STEERING Mechanical Steering for Outboard Powered Vessels Xtreme Helm — SHX7606 ™ ™ Installation and User Manual [REVISION 5] Form No. 4445104072 | ©2023 Dometic...
- Page 2 ©2023 Dometic All Rights Reserved. This document, subject matter and all information herein is the sole, exclusive and confidential property of Dometic and shall not be disclosed, copied, reproduced or used in whole or in part for any purpose other than as specifically authorized in writing by Dometic.
-
Page 3: Table Of Contents
Table of Contents 1 Important Safety Information ..........1-1 1.1 Explanation of symbols ............ 1-1 1.2 Safe operation ............... 1-2 1.3 Safety considerations for installers ........1-3 2 System Installation .............. 2-1 2.1 Preparation for installation ..........2-1 2.2 Steering cable routing ............ 2-1 2.3 Helm installation ............ - Page 4 Notes...
-
Page 5: Important Safety Information
If you have any questions about safe installation or operation of this system, contact Dometic Marine. Please don’t guess. 1.1 Explanation of symbols The symbols below are used throughout this publication to alert you to potential hazards involved with the operation and installation of this product. -
Page 6: Safe Operation
1.2 Safe operation WARNING! The safety information below is intended to inform you of hazards that may be present when operating a boat equipped with Dometic controls and steering. Read and understand this information. General • Read and understand this manual and any other documentation provided with your steering system. -
Page 7: Safety Considerations For Installers
• Helms must not be disassembled for any reason. WARNING! Failure to comply with Dometic instructions may result in loss of steering control, which could lead to a collision and/or ejection from the boat, causing property damage, personal injury, and/or death. - Page 8 WARNING! Do not substitute parts from other manufacturers, they may cause a safety hazard for which Dometic cannot accept responsibility. Use only Dometic SSCX64 Xtreme steering cable with this helm. ™...
-
Page 9: System Installation
2 System Installation 2.1 Preparation for installation Before the steering cable can be installed, the helm, bezel, and steering wheel must be fully installed as shown in the bezel kit instructions. 2.2 Steering cable routing The helm assembly can be mounted for either port or starboard cable routing. - Page 10 Then turn steering wheel counter clockwise to draw the cable fully into the helm. Continue turning the wheel after the cable end enters the helm spigot, you will feel some pressure then hear a click. Keep turning past that point until you can not turn any further.
-
Page 11: Connection To Engine
Step 6 Rotate the steering wheel several times from stop to stop, and watch the movement of the steering cable output ram. On starboard routed cables, turning the steering wheel clockwise should cause the ram to extend. On port routed cables, turning the steering wheel clockwise should cause the ram to retract. -
Page 12: Operation And Maintenance Notes
Boat builder and boat dealer, please supply these installation instructions and owner’s manual with the delivery of boat. Boat owner keep these instructions with your boat for future reference. Boat owner consult with your boat builder, boat dealer, or Dometic if you have any questions regarding these instructions. -
Page 13: Mounting Template
3 Mounting Template 3.1 Helm — SHX7606 NOTICE! If this template has been downloaded electronically or copied from another document, please verify all template dimensions prior to cutting. Print/copy reproductions may be scaled differently. 3 HOLES 3/8" (10mm) DIA. 1 HOLE 3-1/4"... - Page 14 This page left intentionally blank.
- Page 15 Notes...
- Page 16 YOUR LOCAL DEALER YOUR LOCAL SUPPORT YOUR LOCAL SUPPORT YOUR LOCAL SALES OFFICE YOUR LOCAL SALES OFFICE A complete list of Dometic companies, which comprise the Dometic Group, can be found in the public filings of: dometic.com/dealer dometic.com/dealer dometic.com/ dometic.com/contact contact dometic.com/sales-offices...
