INSTALLATION INSTRUCTIONS
Copy Part# IS-SB39452, Rev. 2
Date: 05/2023
Jetboat Steering System
Bezel Mounting Kit
Part # SB39452
NOTICE!
Installer: These instructions contain important safety information and
must be forwarded to the boat owner.
These instructions show you how to install a bezel mount kit for a jetboat
steering system. This steering system is for use with small jet propelled
boats using 2 cycle engines.
NOTICE!
This steering system is not for use with large jet pumps using
automotive V8 engines.
A complete system consists of the following components:
• Bezel mounting kit SB39452
• Helm assembly SH5087 — 135° steering wheel turn, or,
• Helm assembly SH5088 — 270° steering wheel turn
• Cable assembly SSC219xx (xx denotes length in feet)
• Steering wheel, consult Dometic catalog
• Engine connection kit, see Dometic catalog
WARNING!
Before starting installation read these instructions and engine makers
instructions thoroughly. Failure to follow either of these instructions or
incorrect assembly can result in loss of control and cause property
damage and/or personal injury.
Do not substitute parts from other manufacturers. They may cause a
safety hazard for which Dometic cannot accept responsibility.
To avoid excessive steering loads and to get the best steering perfor-
mance, the water jet nozzle and the reverse gate must be adjusted as
instructed in the motor manufacturer's operation manual. Failure to do
so can affect the performance of the boat and its safe operation.
NOTICE!
Helms and cable assemblies are supplied lubricated ready for
installation, do not add any lubricant to either assembly. Use of other
lubricants can cause damage to the steering cable, resulting in the
cable seizing or premature wear.
WARNING!
Helms must not be disassembled for any reason. Removal and
replacement of any hardware may lead to total failure of the system
which could cause personal injury and or property damage.
