KENT CWP 1525 Instruction Manual

Petrol high pressure cleaner

Hide thumbs

Table of Contents

Quick Links

Download this manual

Date:

18/4-2017

KENT HØJTRYK A/S

High-pressure cleaners.

SKOVBRYNET 10

Instruction manual

DK-6752 GLEJBJERG

TLF. +45 75 19 80 33 E-mail:

Petrol high pressure cleaner

CWP 1525 - 1721 - 2018 - 2415 (14HP)

CWP 2042 - 2530 - 3025 - 3521 - 4018 - 5015 (23,5HP)

Caution: Read this manual before operating the product

Need help?

Do you have a question about the CWP 1525 and is the answer not in the manual?

Questions and answers

Summary of Contents for KENT CWP 1525

Page 1: Table Of Contents
TLF. +45 75 19 80 33 E-mail: info@kent-as.dk www.kent-as.dk Petrol high pressure cleaner CWP 1525 – 1721 – 2018 – 2415 (14HP) CWP 2042 – 2530 – 3025 – 3521 – 4018 – 5015 (23,5HP) Caution: Read this manual before operating the product Table of contents:...
Page 2: Kent Højtryk A/Sskovbrynet
Batch – CWP 2042 - 5015 High-pressure cleaners. Date: 18/4-2017 Instruction manual Page: 2 of 28 © Kent hojtryk\Clean-9000\Brugs-9000-EN-d.307.doc EC-DECLARATION OF CONFORMITY FOR MACHINERY KENT HØJTRYK A/S Manufacturer: Skovbrynet 10 DK - 6752 Glejbjerg +45 75 26 73 00 Tel:...
Page 3: Machine Description
1. Machine description 1.1 Application: Congratulations with your choice of a Kent high-pressure cleaner. You have purchased a unit with high technological value. It is a professional and reliable machine which you can use for many years. Thus, we ask you to read and follow the instruction manual carefully.
Page 4: Functionality
Date: 18/4-2017 Instruction manual Page: 4 of 28 © Kent hojtryk\Clean-9000\Brugs-9000-EN-d.307.doc 1.2 Functionality: Section of 3 cyl. pump piston cycle. Pump: 3-cylinder, vibrationless and noiseless, oil bath lubricated high-pressure plunger pump made of rust- and acidproof materials. The plungers are made of non-wearing ceramic material. Suitable for temperatures up to 60°...
Page 5: User Guide
Date: 18/4-2017 Instruction manual Page: 5 of 28 © Kent hojtryk\Clean-9000\Brugs-9000-EN-d.307.doc 2. User guide 2.1 Preparation The high-pressure cleaner must be moved by use of either a forklift truck, by rigging it directly onto a pallet with the high-pressure cleaner securely fixed or lifting by crane with the shown hook which is mounted on the top of the device, as mentioned in section 4.1.
Page 6: Start Up
18/4-2017 Instruction manual Page: 6 of 28 © Kent hojtryk\Clean-9000\Brugs-9000-EN-d.307.doc 2.2 Start up This machine must only be operated by persons over 18 years. (Danish At-instruction (At = Danish Working Environment Authority) D. 2.20 November 2006): Young persons covered by compulsory education must not operate pressure equipment.
Page 7 18/4-2017 Instruction manual Page: 7 of 28 © Kent hojtryk\Clean-9000\Brugs-9000-EN-d.307.doc Chemicals dosage: Fill plastic can with desired chemical. Mount injector suction hose in can. Open double nozzle pipe valve, and approx. 10 % chemical will be added to water. Indoor high-pressure cleaning is only permitted in halls and together with good ventilation. If you feel unwell during cleaning, stop working immediately and go outside.
Page 8 Page: 8 of 28 © Kent hojtryk\Clean-9000\Brugs-9000-EN-d.307.doc The employer must make sure that the employees wear hearing protection as soon as they start work which is considered to be damaging to hearing. This means that noise exposure even below 85 dB(A) may require the use of hearing protection.
Page 9 Instruction manual Page: 9 of 28 © Kent hojtryk\Clean-9000\Brugs-9000-EN-d.307.doc Precautions for storage/frost: We recommend filling the pump with anti-freeze equal to anti-freeze for cars if the machine will be stored in a place with a risk of being exposed to frost, or will not be used for more than 3 months. In case of low temperatures some parts may freeze or settle if the machine has been stored for a long time.
Page 10 Instruction manual Page: 10 of 28 © Kent hojtryk\Clean-9000\Brugs-9000-EN-d.307.doc Important: When application of chemicals/soap has been terminated the suction hose and injector non-return valve MUST be cleaned with pure water. Place injector suction hose in a bucket or similar container with pure water and allow injector to suck water for a few minutes.
Page 11: Safety Rules
Instruction manual Page: 11 of 28 © Kent hojtryk\Clean-9000\Brugs-9000-EN-d.307.doc 2.3 Safety rules 1. Always wear protective equipment as described in the work instructions. This applies in particular for the use of suitable working clothes, safety goggles, gloves, safety footwear, respiratory protection equipment and hearing protection.
Page 12 18/4-2017 Instruction manual Page: 12 of 28 © Kent hojtryk\Clean-9000\Brugs-9000-EN-d.307.doc 7. Never point the water jet towards yourself, other persons or animals. Cleaning of clothes on persons is not allowed. 8. Avoid splashes on electrical wires and installations. 9. Be careful with sensitive and expensive installations.
Page 13: Maintenance Instructions
18/4-2017 Instruction manual Page: 13 of 28 © Kent hojtryk\Clean-9000\Brugs-9000-EN-d.307.doc 3. Maintenance instructions 3.1 General maintenance Any repairs or adjustments may only be carried out when the high pressure cleaner is secured against accidental start-up. Furthermore, remove battery cable from battery pole to provide an extra layer of safety for the person conducting repairs.
Page 14 Instruction manual Page: 14 of 28 © Kent hojtryk\Clean-9000\Brugs-9000-EN-d.307.doc Decalcification: Carried out when needed and is important to prevent clogging of the tube coil in the boiler. Fill with water and acetic acid in the mixture proportion 1 portion of acetic acid and 10 portions of water, leave the mixture for a couple of hours followed by flushing of loose pieces of chalk and dirt.
Page 15: Fault Finding
Batch – CWP 2042 - 5015 High-pressure cleaners. Date: 18/4-2017 Instruction manual Page: 15 of 28 © Kent hojtryk\Clean-9000\Brugs-9000-EN-d.307.doc 3.2 Fault finding Fault finding on the high pressure cleaners Fault finding Cause Remedy Cleaner does not start Fuse defective. Replace fuse.
Page 16: Spare Parts
18/4-2017 Instruction manual Page: 16 of 28 © Kent hojtryk\Clean-9000\Brugs-9000-EN-d.307.doc 3.3 Spare parts Note model number and name-plate on the high-pressure cleaner so that we can deliver the ordered spare parts to your machine. Always use original spare parts. Example of identification label: Overleaf the high-pressure cleaner is shown with part numbers on all spare parts.
Page 17 Batch – CWP 2042 - 5015 High-pressure cleaners. Date: 18/4-2017 Instruction manual Page: 17 of 28 © Kent hojtryk\Clean-9000\Brugs-9000-EN-d.307.doc CWP1525...
Page 18 Batch – CWP 2042 - 5015 High-pressure cleaners. Date: 18/4-2017 Instruction manual Page: 18 of 28 © Kent hojtryk\Clean-9000\Brugs-9000-EN-d.307.doc CWP2415...
Page 19 Batch – CWP 2042 - 5015 High-pressure cleaners. Date: 18/4-2017 Instruction manual Page: 19 of 28 © Kent hojtryk\Clean-9000\Brugs-9000-EN-d.307.doc CWP2018...
Page 20 Batch – CWP 2042 - 5015 High-pressure cleaners. Date: 18/4-2017 Instruction manual Page: 20 of 28 © Kent hojtryk\Clean-9000\Brugs-9000-EN-d.307.doc CWP1721...
Page 21 Batch – CWP 2042 - 5015 High-pressure cleaners. Date: 18/4-2017 Instruction manual Page: 21 of 28 © Kent hojtryk\Clean-9000\Brugs-9000-EN-d.307.doc CWP2042, CWP2530 & CWP3025...
Page 22 Batch – CWP 2042 - 5015 High-pressure cleaners. Date: 18/4-2017 Instruction manual Page: 22 of 28 © Kent hojtryk\Clean-9000\Brugs-9000-EN-d.307.doc CWP3521, CWP4018 & CWP5015...
Page 23: Installation And Assembly
18/4-2017 Instruction manual Page: 23 of 28 © Kent hojtryk\Clean-9000\Brugs-9000-EN-d.307.doc 4 Installation and assembly 4.1 Unpacking: Unpack the machine and make sure that it is complete and not damaged. In case it is not complete or damaged, do not use the machine and consult your dealer. For reasons of packaging or transport some accessory components can be supplied loose.
Page 24: Technical Specifications
Batch – CWP 2042 - 5015 High-pressure cleaners. Date: 18/4-2017 Instruction manual Page: 24 of 28 © Kent hojtryk\Clean-9000\Brugs-9000-EN-d.307.doc 4.3 Technical specifications: High-pressure cleaners HWD-Cleaner Working Water Motor Pump Length Width Height Weight Model pressure consumption capacity Fuel Type stamps...
Page 25 High-pressure cleaners. Date: 18/4-2017 Instruction manual Page: 25 of 28 © Kent hojtryk\Clean-9000\Brugs-9000-EN-d.307.doc Pressure regulation: Working pressure adjustable from 30 bar to max. pressure at the lance Noise level: Under 97 dB Warning: Never let the machine bee idle for more than 3 minutes at a time...
Page 26: Note
Batch – CWP 2042 - 5015 High-pressure cleaners. Date: 18/4-2017 Instruction manual Page: 26 of 28 © Kent hojtryk\Clean-9000\Brugs-9000-EN-d.307.doc 5 Notes:...
Page 27 Batch – CWP 2042 - 5015 High-pressure cleaners. Date: 18/4-2017 Instruction manual Page: 27 of 28 © Kent hojtryk\Clean-9000\Brugs-9000-EN-d.307.doc KENT HØJTRYK A/S SKOVBRYNET 10 DK-6752 GLEJBJERG TLF. +45 75 19 80 33 www.kent-as.dk E-mail: info@kent-as.dk...
Page 28 Instruction manual Page: 28 of 28 © Kent hojtryk\Clean-9000\Brugs-9000-EN-d.307.doc We also produce: Hot water cleaners up to 30 l / min and 500 bars with gasoline / diesel / electric motor, oil heated. And low-pressure Hot Box with max. flow 45 l/min.
