THIS TECHNICAL MANUAL HAS BEEN DEVELOPED FOR AND
INTENDED TO BE USED BY A QUALIFIED TECHNICIAN
WORKING FOR AN AUTHORIZED KI MOBILITY DEALER.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ki Mobility AXiOM BACKS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Etac Ki Mobility AXiOM BACKS

Summary of Contents for Etac Ki Mobility AXiOM BACKS

  • Page 1 THIS TECHNICAL MANUAL HAS BEEN DEVELOPED FOR AND INTENDED TO BE USED BY A QUALIFIED TECHNICIAN WORKING FOR AN AUTHORIZED KI MOBILITY DEALER.
  • Page 2 715-254-0991 In writing at: Ki Mobility 5201 Woodward Drive Stevens Point, WI 54481 U.S.A Via email at: sales@kimobility.com Or via our Authorized EU Representative: Etac Supply Center AB Långgatan 12 33233 Anderstorp Sweden...

  • Page 3: Table Of Contents

    Table of Contents Tools ....................... 3 Axiom Back Product Weights ................. 3 Posterior Back (AXPB) Sizing................4 Deep Lateral (AXDL) Sizing ................5 Posterior Lateral and Lateral (AXPL & AXLB) Sizing ........6 Lateral Support Installation ................7 Shoulder Strap Guide Installation ..............8 Headrest Installation ..................

  • Page 4: Tools

    Tools Please see the list below to identify the tools needed throughout this tech manual. Always check tools to ensure the ends are not stripped and that the tool can perform it’s function properly without damaging any parts or hardware on the chair. Tools Needed •...

  • Page 5: Posterior Back (Axpb) Sizing

    Posterior Back (AXPB) Sizing Posterior Back (AXPB) Sizing Guide A - Height of Foam D - Height of Shell F - Width of Foam H - Depth of Foam B - Apex of Lateral E - Width of Shell G - Depth of Shell POSTERIOR BACK (AXPB) Assy AXPB1208...

  • Page 6: Deep Lateral (Axdl) Sizing

    Deep Lateral (AXDL) Sizing Deep Lateral (AXDL) Sizing Guide A - Height of Foam D - Height of Shell F - Width of Foam H - Depth of Foam B - Apex of Lateral E - Width of Shell G - Depth of Shell DEEP LATERAL (AXDL) Assy AXDL1214 16”...

  • Page 7: Posterior Lateral And Lateral (Axpl & Axlb) Sizing

    Posterior Lateral and Lateral (AXPL & AXLB) Sizing Posterior Lateral and Lateral (AXPL & AXLB) Sizing Guide A - Height of Foam D - Height of Shell F - Width of Foam H - Depth of Foam B - Apex of Lateral E - Width of Shell G - Depth of Shell POSTERIOR LATERAL BACK (AXPL) &...

  • Page 8: Lateral Support Installation

    Lateral Support Installation 1. Remove current stud plate using a 10mm wrench. Install new stud plate (D), two washers (B) and lateral mount (C) on the inside of the back shell and three washers (B) and nuts (A) on the backside of the back shell using a 10mm wrench.

  • Page 9: Shoulder Strap Guide Installation

    Shoulder Strap Guide Installation 1. Install the shoulder strap guide assembly onto the two pre-drilled holes at the top centerline of the back shell. 2. Using two bolts, two washers and the shoulder guide assembly on the outside of the back shell and two washers and two nuts on the inside of the back shell using a 10mm wrench.

  • Page 10: Headrest Installation

    Headrest Installation 1. Attach headrest mounting bracket to predrilled mounting location using provided 6mm screws, washers and nyloc nuts. a. For Standard (Bottom Left Image) or Multi-Axis Removable Hardware (Bottom Right Image), loosen the clamp by rotating the lever knob counterclockwise until the headrest can be moved freely in the clamp.

  • Page 11: Dex Backrest Hardware Installation

    DEX Backrest Hardware Installation General Setup 1. Determine installation slots based on configuration. 1” Fits Back Frame Widths 1” 1” 1” A xio m B ack Inner Slo t s Out er Slo t s W id t h 12" (30.5cm) 11"...
  • Page 12 DEX Backrest Hardware Installation 3. Hold the backrest shell against the chair at approximate height desired. Find a back cane location that can accomodate the clamp near the center of the slots on the backrest bracket. Typically the backrest will rest 1-2" above the cushion. ce at tions clam...
  • Page 13 DEX Backrest Hardware Installation 5. Use a level and a tape measure to ensure the clamps are level and the distance from back cane to clamp mount is 1/2". 1/2” o interference at No interference at clamp locations clamp locations 1”...
  • Page 14 DEX Backrest Hardware Installation Fitting Adjustments WARNING: It may be possible to adjust the final position of the Axiom Back with an end user seated in his wheelchair. This requires that the end user be able to sit in a stable position without the use of the backrest.

  • Page 15: Btx Backrest Hardware Installation

    BTX Backrest Hardware Installation General Setup 1. Determine installation slots based on configuration. 1” Fits Back Frame Widths 1” 1” 1” A xio m B ack Inner Slo t s Out er Slo t s W id t h 12" (30.5cm) 11"...
  • Page 16 BTX Backrest Hardware Installation 4. Determine the clamp orientation, forward or rear facing and the clamp bracket (A) orientation and hole use (See Clamp Positioning Chart below). Loosely assemble the clamps onto the back canes at the desired location talked about in step 3. Bolts should thread inwards from the outside of the chair. Tighten clamp enough so it stays in place and repeat on opposite side.
  • Page 17 BTX Backrest Hardware Installation Fitting Adjustments WARNING: It may be possible to adjust the final position of the Axiom Back with an end user seated in his wheelchair. This requires that the end user be able to sit in a stable position without the use of the backrest.

  • Page 18: Fxt Backrest Hardware Installation

    FXT Backrest Hardware Installation General Setup 1. Determine installation slots based on configuration. 1” Fits Back Frame Widths 1” 1” 1” A xio m B ack Inner Slo t s Out er Slo t s W id t h 12" (30.5cm) 11"...
  • Page 19 FXT Backrest Hardware Installation 4. Choose the desired angle and depth set up. Use the images and charts below to help determine how to achieve desired configurations. -0° -2.5° -5° B racket A rro w P ivo t A ngle 3 P ivo t A ngle 2 P ivo t A ngle 1 Rear Position (Closer to back canes) Front Position...
  • Page 20 FXT Backrest Hardware Installation Fitting Adjustments WARNING: It may be possible to adjust the final position of the Axiom Back with an end user seated in his wheelchair. This requires that the end user be able to sit in a stable position without the use of the backrest.
  • Page 21 Ki Mobility 5201 Woodward Drive Stevens Point, Wisconsin 54481 715-254-0991 www.kimobility.com DCN0858.3...
