LADDER SETUP (continued)
2. U-SHAPED TOP RAIL INSTALLATION (refer to figure 2):
1
A
3
3. INSTALLATON OF THE REMAINING LADDER SIDE (refer to figure 3):
4. TOP BRACE INSTALLATION – ONE SIDE AT A TIME (refer to figure 4):
5. BEFORE USE OF LADDER:
With all parts now in place, verify that all fasteners/screws are fully tightened and
apply downward pressure to each step to be sure they are fully anchored in place.
If your ladder came with a ladder barrier, proceed to instructions for ladder barrier
installation, otherwise proceed to placing the ladder over the side wall of your pool,
with one side of the ladder located inside the pool and the other side outside of the
pool - see figure 5.
SAVE THESE INSTRUCTIONS
(190IO) 36", 42" 1-SECTION POOL LADDER ENGLISH 7.5" X 10.3" PANTONE 295U 06/06/2016
2
B
4
3
3
3
5
