Intex Rectangular Ultra Frame 128314GN Manual page 34

Before assembling your product, please take a few minutes to check the contents
and become familiar with all the parts.
3
4
5
36in (91 cm) & 42in (107 cm) models
NOTE: Drawings for illustration purpose only.
Actual product may vary. Not to scale.
REF.
DESCRIPTION
NO.
1 U-SHAPED TOP RAIL
2 TOP BRACE
3 LONG FASTENER (WITH 2 EXTRA)
4 STEP MOUNTING PIN (WITH 2 EXTRA)
5 STEP
6 J-SHAPED SIDE LEG (MARKED "A")
7 J-SHAPED SIDE LEG (MARKED "B")
This ladder is designed and manufactured for
Item #
28060 (white & blue)
11406/28056 (grey & white)
28061 (white & blue)
11435/28057 (grey & white)
SAVE THESE INSTRUCTIONS
(190IO) 36", 42" 1-SECTION POOL LADDER ENGLISH 7.5" X 10.3" PANTONE 295U 06/06/2016
PARTS REFERENCE
QUANTIRY
2
2
10
26
6
2
2
Intex pool wall height:
1
2
6
7
SPARE PART NO.
#11406
#28060 #28061
#28056
11402 12508 11402
11403 12509 11403
10810 10810 10810
10349 10913 10349
10348 10914 10348
11404A 12510A 11405A 12511A
11404B 12510B 11405B 12511B
Pool Wall Height
36in (91 cm)
36in (91 cm)
42in (107 cm)
42in (107 cm)
English
190A
#11435
#28057
12508
12509
10810
10913
10914
Page 3
