- Page 1 Original operating manual OPERATING MANUAL TRAILER SAFETY JACK 13 9 TA17 3 4 01/2022 – V01...
- Page 2 © 01-2022. TVH and TotalSource are registered trademarks. TVH Parts Holding NV, Brabantstraat 15, B-8790 Waregem. All rights reserved. ® ® No part of this publication may be reproduced or communicated in any form or by any means, electronic or mechanical, including copying, recording or use in an information storage or retrieval system, without prior and explicit permission of TVH Parts Holding NV.
- Page 3 Bulgarian Можете да намерите това ръководство на Вашия език чрез линка, посочен по – долу. Czech Tento návod najdete ve svém jazyce prostřednictvím odkazu níže. Danish Du kan finde denne vejledning på dit sprog via nedenstående link. German Sie finden diese Bedienungsanleitung in Ihrer Sprache unter folgendem Link. Greek Μπορείτε...
- Page 4 Thank you for using our product. For your safety and to ensure a correct operation, we would like to bring to your attention some aspects of this manual: • This booklet supplies useful instructions for the correct operation and maintenance of the product.
-
Page 5: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ..................DESCRIPTION . -
Page 6: Introduction
INTRODUCTION This manual gives information about the commencement of operation, use and maintenance of your newly trailer safety jack. Also included in this manual are a number of safety instructions to create a safe working environment. This trailer safety jack is intended to be used to support or jack the end of a semi-trailer that is parked against a loading dock and not connected to a truck’s fifth wheel. -
Page 7: Description
DESCRIPTION 2.1. Technical data Always check the type plate for the correct information. Type Hydraulic trailer safety jack Load capacity (tonnes) 45,5 Minimum height (mm) 1070 Maximum height (mm) 1350 Weight (kg) 2.2. Main components of the product N° Component Saddle Control handle Transport handle... -
Page 8: Safety Instructions
SAFETY INSTRUCTIONS 3.1. Explanation of the safety decals If the decals are damaged or missing, please replace them. Explanation Reference Read the manual before use 163TA4380 3.2. General safety instructions • TVH Parts Holding NV cannot anticipate each possible circumstance that may result in danger. -
Page 9: Transport And Storage
TRANSPORT AND STORAGE The trailer safety jack must always be stored level, in a dry and temperature-controlled environment. Transport the trailer safety jack to the work area by either (a) wheeling it or (b) lifting and carrying it. The trailer safety jack should always be wheeled to the work area if possible – only lift and carry the safety jack if it cannot be wheeled safely. -
Page 10: Assembly And Installation
ASSEMBLY AND INSTALLATION 5.1. Packing list Description Amount Reference Handle Contact your dealer Jack Contact your dealer Operating manual 48690799 5.2. Safety instructions Always wear safety gloves and safety shoes when assembling the trailer safety jack. 5.3. Assembly of the product Make sure the trailer safety jack is on a flat, level surface. -
Page 11: Operation
OPERATION 6.1. Safety instructions for operating the product • Keep the work area well illuminated. • Make sure that the trailer safety jack make a firm contact with the ground. • When the trailer safety jack is in use make sure that no persons are in the vicinity of the trailer safety jack or lie down underneath the semi trailer to prevent serious injuries. - Page 12 If you use the trailer safety jack as a support when loading the trailer, we recommend that there is a distance of about 10 centimetres (3.90 inches) between the trailer safety jack and the trailer. The load in the trailer will cause the trailer to lower. This makes it easier to remove the trailer safety jack after the work has been done.
-
Page 13: Maintenance
MAINTENANCE 7.1. Safety instructions for the maintenance of the product • Always wear safety gloves and shoes when maintaining the product • This product contains hydraulic oil • Do not attempt to repair the product unless you are trained and authorised to do •... - Page 14 6. Cleaning Only clean the equipment with a cloth dampened in a soap solution (REF 131TA5500)* or TotalSource wipes (REF 147TA3378). Do not use solvents, petrol, strong detergents etc. If the equipment is heavily soiled, the use of a pressure cleaner is only permitted providing that it is set to a maximum of 200 bar.
-
Page 15: Troubleshooting
TROUBLESHOOTING N° Problem Cause Action The trailer safety There is friction and/or rust Lubricate the trailer safety jack jack won’t lift (see chapter ‘Maintenance’) The loading capacity has been Take away weight so that it falls exceeded within the loading capacity Wheels do not roll There is too much dust and/or dirt Remove the dirt and lubricate... -
Page 16: Final Decommissioning And Disposal
FINAL DECOMMISSIONING AND DISPOSAL Final, proper decommissioning or disposal of the product must be performed in accordance with the regulations of the country of application. In particular, regulations governing the disposal of batteries, fuels and electronic and electrical systems must be observed. -
Page 17: Annexes
ANNEXES 10.1. CE certificate 17/20... - Page 18 18/20...
- Page 19 NOTES ........................
- Page 20 Your distributor: Manufactured outside the EU for: TVH PARTS HOLDING NV Brabantstraat 15 • 8790 Waregem • Belgium T +32 56 43 42 11 • F +32 56 43 44 88 • info@tvh.com • www.tvh.com...
