- Page 1 Original operating manual OPERATING MANUAL GARAGE JACK K R I G 0 01 – K R I G 0 0 2 – K R I G 0 0 3 05/2021 – V01...
- Page 2 © 05-2021. TVH and TotalSource are registered trademarks. TVH Parts Holding NV, Brabantstraat 15, B-8790 Waregem. All rights reserved. ® ® No part of this publication may be reproduced or communicated in any form or by any means, electronic or mechanical, including copying, recording or use in an information storage or retrieval system, without prior and explicit permission of TVH Parts Holding NV.
- Page 3 Bulgarian Можете да намерите това ръководство на Вашия език чрез линка, посочен по – долу. Czech Tento návod najdete ve svém jazyce prostřednictvím odkazu níže. Danish Du kan finde denne vejledning på dit sprog via nedenstående link. German Sie finden diese Bedienungsanleitung in Ihrer Sprache unter folgendem Link. Greek Μπορείτε...
- Page 4 Thank you for using our product. For your safety and to ensure a correct operation, we would like to bring to your attention some aspects of this manual: • This booklet supplies useful instructions for the correct operation and maintenance of the product.
-
Page 5: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ..................DESCRIPTION . -
Page 6: Introduction
INTRODUCTION This manual gives information about the commencement of operation, use and maintenance of your newly purchased garage jack. Some of the maintenance operations should only be carried out by professional technicians. If you require this information and the maintenance steps, please contact your dealer. Also included in this manual are a number of safety instructions to create a safe working environment This garage jack is a manually operated garage jack designed to lift a vehicle. - Page 7 The garage jack may be unsafe if adequate maintenance is neglected. Therefore, adequate maintenance facilities, trained personnel and procedures should be provided. Maintenance and inspection shall be performed in conformity with the following practices: 1. A scheduled planned maintenance, lubrication and inspection system should be followed (see maintenance instructions chapter 7).
-
Page 8: Description
DESCRIPTION 2.1. Technical data Always check the type plate for the correct information. For KRIG0001 Type Garage jack Lifting capacity (kg) 2000 Minimum height of the saddle (mm) (H3/H4) Maximum height of the saddle (mm) (H3/H4) Width of the base (mm) Length of the base (mm) (L1) 1170 Weight (kg) -
Page 9: Main Components Of The Product
H3/H4 2.2. Main components of the product N° Component Handle Foot pump Wheels Saddle Wheels Safety decal 2.3. Type plate N° Explanation Type xxxxxx Serial n° xxxxxx Type of product Capacity xxx kg Serial number Net weight xx kg Capacity of the product (kg) Height xxx mm Year of manufacturing... -
Page 10: Safety Instructions
SAFETY INSTRUCTIONS 3.1. Explanation of the safety decals If the decals are damaged or missing, please replace them. N° Explanation Reference The wheels must be locked 162TA8911 before using the jack To lift the jack, press the lever up and down quickly The jack shall be placed in its intended position under the vehicle... - Page 11 • Use extreme caution when lifting vehicles from the sides. Always make sure that the height between the floor and the bottom of the raised tyre is never more than one fourth (1/4th) of the vehicle’s tread width. If this value is exceeded, the vehicle could reach a point of instability and tip over, or the angle of the frame could cause the jack to kick out and drop the load.
-
Page 12: Transport And Storage
TRANSPORT AND STORAGE The garage jack must always be stored level, in a dry and temperature-controlled environment. Transport the jack to the work area by either (a) wheeling it or (b) lifting and carrying it. The jack should always be wheeled to the work area if possible – only lift and carry the jack if it cannot be wheeled safely. -
Page 13: Assembly And Installation
ASSEMBLY AND INSTALLATION 5.1. Packing list Description Amount Reference Jack 165TA5116 165TA5117 165TA5118 Spare parts list Contact your dealer Operating manual 166TA7670 5.2. Safety instructions Wear safety gloves and safety shoes when assembling the garage jack. 5.3. Assembly of the product With the jack sitting on its wheels on a flat surface, insert the bottom of the upper handle into the handle socket and secure it by twisting it clockwise. -
Page 14: Operation
OPERATION 6.1. Safety instructions for operating the product • Keep the work area well illuminated. • Make sure that the garage jack make a firm contact with the ground. • When the garage jack is in use make sure that no persons are in the vicinity of the forklift jack or lie down underneath the vehicle to prevent serious injuries. - Page 15 5. Continue pumping the handle until the vehicle is lifted to desired height. Pay attention to the saddle position as the vehicle is being raised to make sure there is no danger that the support area is slipping off or lifting from the saddle. 6.
-
Page 16: Maintenance
MAINTENANCE 7.1. Safety instructions for the repair of the product If you need the hydraulic diagram, please contact your dealer. Some of the maintenance operations should only be carried out by professional technicians. If you require this information as well as the maintenance steps, please contact your dealer. •... - Page 17 2. Cleaning • Clean as needed and wipe with an oily cloth. • When you use a high-pressure cleaner, do not direct the jet onto the bearings and seals, otherwise the grease will be washed out and the lifespan of the machine will be shortened.
- Page 18 Pump bleeding instructions • Open the release valve (large red knob on top) approximately 2 full turns. • Slowly perform 2 full strokes of the handle. • Raise the handle fully up, turn the jack over on its left side, as viewed from the rear. Push the handle “down”.
-
Page 19: Troubleshooting
TROUBLESHOOTING If you need the hydraulic diagram, please contact your dealer. N° Problem Cause Action The jack won’t lift The jack is overloaded Remove excess weight a weight • Insufficient oil level Check the level of the hydraulic oil. • The oil level is too high Remove or add oil to correct the problem. -
Page 20: Final Decommissioning And Disposal
FINAL DECOMMISSIONING AND DISPOSAL Final, proper decommissioning or disposal of the product must be performed in accordance with the regulations of the country of application. In particular, regulations governing the disposal of batteries, fuels and electronic and electrical systems must be observed. Waste packaging should be sorted and put into solid dustbins according to the materials and needs to be collected by the local special environment protection bureau. - Page 21 21/28...
-
Page 22: Annexes
ANNEXES 10.1. CE-certificate For KRIG001 ORIGINAL DECLARATION EG-VERKLARING VAN OVEREENSTEMMING DÉCLARATION CE DE CONFORMITÉ EC DECLARATION OF CONFORMITY EG-KONFORMITÄTSERKLÂRUNG DECLARACIÓN CE DE CONFORMIDAD DICHIARAZIONE CE DI CONFORMITÀ DECLARAÇÃO DE CONFORMIDADE CE (MACHINE DIRECTIVE 2006/42/EC) De fabrikant, Le fabricant, The manufacturer, Der Hersteller, El fabricante, Il fabbricante, O fabricante:... - Page 23 ORIGINAL DECLARATION • dat de krik voldoet aan alle toepasselijke bepalingen van de hierna vermelde richtlijnen en geharmoniseerde normen; que le cric satisfait à l’ensemble des dispositions pertinentes des directives et normes harmonisées ci- dessous; that the machine jack fulfills all the relevant provisions of the directives and harmonized standards stated herein below;...
- Page 24 For KRIG002 ORIGINAL DECLARATION EG-VERKLARING VAN OVEREENSTEMMING DÉCLARATION CE DE CONFORMITÉ EC DECLARATION OF CONFORMITY EG-KONFORMITÄTSERKLÂRUNG DECLARACIÓN CE DE CONFORMIDAD DICHIARAZIONE CE DI CONFORMITÀ DECLARAÇÃO DE CONFORMIDADE CE (MACHINE DIRECTIVE 2006/42/EC) De fabrikant, Le fabricant, The manufacturer, Der Hersteller, El fabricante, Il fabbricante, O fabricante: TVH Parts Holding NV, Brabantstraat 15, B - 8790 Waregem Verklaart met betrekking tot het hierna beschreven PRODUCT: Déclare, concernant le PRODUIT décrite ci-dessous :...
- Page 25 ORIGINAL DECLARATION • dat de krik voldoet aan alle toepasselijke bepalingen van de hierna vermelde richtlijnen en geharmoniseerde normen; que le cric satisfait à l’ensemble des dispositions pertinentes des directives et normes harmonisées ci- dessous; that the machine jack fulfills all the relevant provisions of the directives and harmonized standards stated herein below;...
- Page 26 For KRIG003 ORIGINAL DECLARATION EG-VERKLARING VAN OVEREENSTEMMING DÉCLARATION CE DE CONFORMITÉ EC DECLARATION OF CONFORMITY EG-KONFORMITÄTSERKLÂRUNG DECLARACIÓN CE DE CONFORMIDAD DICHIARAZIONE CE DI CONFORMITÀ DECLARAÇÃO DE CONFORMIDADE CE (MACHINE DIRECTIVE 2006/42/EC) De fabrikant, Le fabricant, The manufacturer, Der Hersteller, El fabricante, Il fabbricante, O fabricante: TVH Parts Holding NV, Brabantstraat 15, B - 8790 Waregem Verklaart met betrekking tot het hierna beschreven PRODUCT: Déclare, concernant le PRODUIT décrite ci-dessous :...
- Page 27 ORIGINAL DECLARATION • dat de krik voldoet aan alle toepasselijke bepalingen van de hierna vermelde richtlijnen en geharmoniseerde normen; que le cric satisfait à l’ensemble des dispositions pertinentes des directives et normes harmonisées ci- dessous; that the machine jack fulfills all the relevant provisions of the directives and harmonized standards stated herein below;...
- Page 28 Your distributor: Manufactured outside the EU for: TVH PARTS HOLDING NV Brabantstraat 15 • 8790 Waregem • Belgium T +32 56 43 42 11 • F +32 56 43 44 88 • info@tvh.com • www.tvh.com...
