Summary of Contents for Total Source 165TA5119
- Page 1 Original operating manual OPERATING MANUAL SUPPORT STANDS 16 5 TA 5119 – 16 5 TA 512 0 – 16 5 TA 5121 05/2021 – V01...
- Page 2 © 05-2021. TVH and TotalSource are registered trademarks. TVH Parts Holding NV, Brabantstraat 15, B-8790 Waregem. All rights reserved. ® ® No part of this publication may be reproduced or communicated in any form or by any means, electronic or mechanical, including copying, recording or use in an information storage or retrieval system, without prior and explicit permission of TVH Parts Holding NV.
- Page 3 Bulgarian Можете да намерите това ръководство на Вашия език чрез линка, посочен по – долу. Czech Tento návod najdete ve svém jazyce prostřednictvím odkazu níže. Danish Du kan finde denne vejledning på dit sprog via nedenstående link. German Sie finden diese Bedienungsanleitung in Ihrer Sprache unter folgendem Link. Greek Μπορείτε...
- Page 4 Thank you for using our product. For your safety and to ensure a correct operation, we would like to bring to your attention some aspects of this manual: • This booklet supplies useful instructions for the correct operation and maintenance of the product.
-
Page 5: Table Of Contents
TABLE OF CONTENTS INTRODUCTION ..................DESCRIPTION . -
Page 6: Introduction
INTRODUCTION This manual contains all the necessary information on the installation and operation of the support stands. Some of the maintenance operations should only be carried out by professional technicians. If you require this information and the maintenance steps, please contact your dealer. Also included in this manual are a number of safety instructions to create a safe working environment. - Page 7 These support stands may be unsafe if adequate maintenance is neglected. Therefore, adequate maintenance facilities, trained personnel and procedures should be provided. Maintenance and inspection shall be performed in conformity with the following practices: 1. A scheduled planned maintenance, lubrication and inspection system should be followed (see maintenance instructions chapter 7).
-
Page 8: Description
DESCRIPTION 2.1. Technical data Always check the type plate for the correct information. For 165TA5119 – Europe/America Type Support stands Load capacity per piece (kg) 1500 Min height (mm) (H1) Max height (mm) (H2) Weight (kg) For 165TA5119 – Australia Type Support stands... -
Page 9: Main Components Of The Product
For 165TA5121 – Australia Type Support stands Load capacity per piece (kg) 6000 Min height (mm) (H1) Max height (mm) (H2) Weight (kg) 26.6 2.2. Main components of the product N° Component Saddle Post Handle Safety decal Base 2.3. Type plate N°... -
Page 10: Safety Instructions
SAFETY INSTRUCTIONS 3.1. Explanation of the safety decals If the decals are damaged or missing, please replace them. N° Explanation Reference The wheels must be chocked 166TA4351 before using the jack The jack shall be placed in its intended position under the vehicle The vehicle must be positioned on a flat, stable surface... -
Page 11: Transport And Storage
TRANSPORT AND STORAGE 4.1. Transport If you want to move the support stands, pick up the stand at its base. Do not pick up the support stand at its saddle or post. This allows the saddle to slide out of the base, causing the support stands to fall, possibly causing damage to the stand. -
Page 12: Assembly And Installation
ASSEMBLY AND INSTALLATION 5.1. Packing list Description Amount Reference Support stands 165TA5119 Operating manual 166TA7663 5.2. Assembly of the product There is no special assembly required for this product. 12/20... -
Page 13: Operation
OPERATION 6.1. Safety instructions for operating the product • Keep the work area well illuminated. • Make sure that the support stands make a firm contact with the ground. • When the support stands are in use make sure that no persons are in the vicinity of the support stands or lie down underneath the vehicle to prevent serious injuries. - Page 14 3. Lift the vehicle with the appropriate jack. 4. Once at the correct height, carefully position the support stands under the vehicle in the designated places. Place the support stands on each side of the jack. The support stands should be spaced as far apart as possible! If you place the support stands too close together, the vehicle has a greater chance of falling over.
- Page 15 2. Lowering 1. Carefully raise the vehicle. 2. Remove the support stands by their base. Pull the handle so the saddle lowers. 3. Slowly lower the vehicle completely. 4. Remove the wheel chocks. 15/20...
-
Page 16: Maintenance
MAINTENANCE 7.1. Safety instructions for the repair of the product Some of the maintenance operations should only be carried out by professional technicians. If you require this information and the maintenance steps, please contact your dealer. • Do not attempt to repair the product unless you are trained and authorised to do so. - Page 17 3. Lubrication A periodic coating of lubricating oil at pivot points will help to prevent rust and assure that the saddle assemblies move freely. This maintenance may be carried out by the operator. Where to lubricate Please see pictures below for the pivot points that need a periodic coating of lubrication. Use a non-abrasive grease to lubricate the mechanical parts.
-
Page 18: Troubleshooting
TROUBLESHOOTING If you wish to receive the spare parts list, please contact your dealer. N° Problem Cause Action Saddle won’t Too much dust and/or dirt Clean the base and lubricate move Saddle won’t An object is pinched that doesn’t Inspect the post and remove the lower belong to the safety jack object... -
Page 19: Final Decommissioning And Disposal
FINAL DECOMMISSIONING AND DISPOSAL Final, proper decommissioning or disposal of the product must be performed in accordance with the regulations of the country in which the product is used. In particular, regulations governing the disposal of batteries, fuels and electronic and electrical systems must be observed. - Page 20 Your distributor: Manufactured outside the EU for: TVH PARTS HOLDING NV Brabantstraat 15 • 8790 Waregem • Belgium T +32 56 43 42 11 • F +32 56 43 44 88 • info@tvh.com • www.tvh.com...
