Ebyte E103-W02DTU User Manual page 6

Chengdu Ebyte Electronic Technology Co.,Ltd.
Communicati
15
on interface
Serial port
16
baud rate
Power
17 supply
voltage
Operating
18
current
19 Product Size
Average
20
weight
Working
21
temperature
Working
22
Humidity
Storage
23
Temperature
Copyright ©2012–2021，Chengdu Ebyte Electronic Technology Co.,Ltd.
RS232/RS485 Male female thread, 50 ohm characteristic impedance
300～400000 bps
Both RS232 and RS485
Support multiple data bits, check bits, stop bits (factory
8～28V DC
default 115200, 8N1)
Power adapter or crimp terminal VCC/GND (either can be
77mA
selected)
Note: Voltage higher than 28V will cause permanent damage
82*84*24mm
to the module
130g The power supply is 12V
Temperature and humidity
-40～+85℃
Industrial grade
10%～90%
Relative humidity, non-condensing
-40～+85℃
Industrial grade
