1.3 Basic usage

No Usage
WiFi serial server
0 communicates with
WiFi serial server
WiFi serial server and
1
Server communication
WiFi serial server and
2
Client communication
For more information on how to use it, please refer to the network instructions in Section 5.

1.4 Product parameters

Parameter
No
Name
1 RF Chips
2 RAM
3 Flash
4 WiFi Version
Operating
5 Frequency
Band
Modulation
6
method
Transmit
7
power
Measured
8
distance
Operating
9
mode
Encryption
10
method
Configuratio
11
n method
Production
12
process
Interface
13
Method
Antenna
14
Interface
Copyright ©2012–2021，Chengdu Ebyte Electronic Technology Co.,Ltd.
WiFi serial server No. 1 is set to AP mode and establish TCP or UDP server, WiFi
serial server No. 2 is set to STATION mode and connect to AP No. 1, and
communicate with WiFi serial server No. 1 through TCP or UDP Client mode
WiFi serial server connects to the network through the wireless router and
communicates with the server on the network (LAN or Internet) via TCP Client or
UDP;
If you need to connect to an Internet server, you need to configure the router with the
appropriate port mapping.
WiFi Serial Server connects to the network through a wireless router and establishes a
TCP or UDP Server to listen for connection signals;
Client communicates with WiFi Serial Server Server by connecting to it.
Parameter Value
System Parameters
CC3200
256KB
8Mbit
WiFi parameters
802.11 b/g/n
2.412～2.484 GHz
OFDM/DSSS
20dBm
约 300m
AP/STA
WEP/WPA2
AT/UDP/HTTP
Basic parameters
Machine paste,
lead-free process
RS485：1*4*3.81mm
RS232：DB9
SMA-K
Description
TI
-
Winbond
-
-
-
pprox. 100mW
Clear and open environment, maximum power, antenna gain
3dBi, height 2m
Support AP working mode and STATION working mode
-
Convenient configuration of the module via serial AT
commands, remote UDP AT commands, and HTTP web pages
Wireless products must be machine labeled to ensure batch
consistency and reliability
Crimping method
Standard DB9, hole type
E103-W02DTU User Manual
Note
