Pico Macom MCM-55 Specifications

DISTRIBUTION
Active Components
Broadband 54-300MHz
frequency range (Channels
CATV 2-36, 95-99)
High 55dB gain for optimal
carrier-to-noise ratio and
superior picture quality
± 0.5dB flatness across
band provides low distortion
and excellent frequency
response
Employs state-of-the art
hybrid push-pull technology
for distortion-free audio-video
quality
Adjustable slope and gain con-
trols for easy system balancing
Easy-access controls and low-
loss (-30dB) test point enable
simplified setup and perform-
ance monitoring
Shielded enclosure provides
over 95dB RFI shielding per-
formance reducing leakage and
ingress
Built-in lightning and line volt-
age surge protection protects
the unit from damage
Black anodized extruded alu-
minum heat-sink maximizes
heat dissipa-tion for improved
reliability and corrosion resistance
External UL approved power
adapter supplied for ease of
installation and to reduce heat
build-up within the unit
www.picomacom.com
300 MHz VHF High-Gain Push-Pull Amplifier
MCM55
300 MHz VHF High-Gain Push-Pull Amplifier
The Pico Macom MCM55 is a high quality hybrid push-pull wall-mounted
distribution amplifier producing signals with extremely low-noise and har-
monic distortion. These amplifiers are capable of 42 channel operation over
the 54-300MHz range in smaller MDU, CATV or SMATV systems. Because of
its high gain and low noise figure, the MCM55 is also ideally suited for head-
end applications with low-level input signals. The hybrid module provides
excellent heat sinking capabilities that are required for the reliability of a high
output amplifier. To ensure reliability and minimize heat build-up within the
unit, an external UL approved power adapter is supplied.
