- Page 1 USER MANUAL MARINE SUSPENSION MODULE...
- Page 2 • Corbin2 Seat (High-Back & Mid-Back) • Corbin2 Seat (High-Back & Mid-Back) • Corbin2 Seat with Heated Cushions • Corbin2 Seat with Heated Cushions • SHOCKWAVE S5 Swivel Slide, Swivel, Slide, and Height Adjust • SHOCKWAVE S5 Swivel Slide, Swivel, and Slide.
-
Page 3: Table Of Contents
STEPS TO SET UP THE SUSPENSION MODULE SHOCK COMPRESSION ADJUSTMENT SETTINGS CHANGING SUSPENSION MODULE HEIGHT REBOUND ADJUSTMENT SERVICE TIPS DRAWINGS AND EQUIPMENT LIST SUSPENSION MODULE DRAWING (SW-05026) EMERGENCY PROCEDURES/TROUBLESHOOTING HOW TO VIDEOS S5 PRODUCT LINEUP GENERAL BOATING BEST PRACTICES AND SAFETY CAUTIONS AND WARNINGS... -
Page 4: Important Instructions
The footrest surface should be 1” [25.4mm] - 6.0” [152.4mm] below the base of the S5 and 7”[177.8mm] - 16”[406.4mm] infront of S5 and be a minimum of 16” [406.4mm] wide. - Page 5 WARNING WARNING Do not install any suspended footrest Do not leave pump attached when onto the S5 suspension module or seat operating the seat, as it will damage the mounted to the S5. Footrests mounted pump and fill valve. to the module or seat will void...
-
Page 6: Before You Start
BEFORE YOU START The maximum occupant weight for the S5 module is 250lbs [113kgs] on a vessel that sees maximum deck accelerations of 3g’s. For calm waters and deck of accelerations less then 2g’s, a 300lb [136kg] occupant is acceptable. When mounting a seat to the module, always use the largest fasteners possible for the bolting configuration. -
Page 7: Mounting Your Suspension Module
GETTING STARTED Congratulations on your purchase of a SHOCKWAVE S5 Marine Suspension Module. We hope you enjoy this new boating experience offering you access to new possibilities on the water. MOUNTING YOUR SUSPENSION MODULE • There must be sufficient deck •... -
Page 8: Setting Up The Suspension Module
Strength of decks and deck mountings is the responsibility of the boat builder or installer of the seats. SHOCKWAVE assumes no liability for suspension modules that are incorrectly installed. Prior to use be sure to pressurize the shock absorber! Do not operate the seat... -
Page 9: Steps To Set Up The Suspension Module
Cycle the shock absorber by bouncing on the seat 5 times. Do not sit on the seat with the SHOCKWAVE S5 Pump attached! Damage will occur to the shock and pump. Note, SHOCKWAVE S5 Pump sold separately. Do not exceed 350 PSI. The maximum shock absorber pressure. -
Page 10: Shock Compression Adjustment Settings
SHOCK COMPRESSION ADJUSTMENT SETTINGS Setting the sag height is designed to be a starting point. To get the most out of the suspension module the shock absorber can be fine-tuned. This is done using a combination of compression and rebound tuning to optimize ride quality as well as for varying sea conditions. -
Page 11: Changing Suspension Module Height
8-inch Height Configuration 201mm Spacer The SHOCKWAVE S5 comes with the shock absorber in the front mount position which is the lowest height configuration. If a higher installation height is required you will need to install one of the two spacers Front Mount provided. -
Page 12: Rebound Adjustment
FASTER REBOUND SLOWER REBOUND rebound faster. slower. REBOUND ADJUSTER Do not sit on the seat with the SHOCKWAVE S5 Pump attached! Damage will occur to the shock and pump. Note, SHOCKWAVE S5 Pump sold separately. -
Page 13: Service Tips
SHOCKWAVE recommends that all bolts should be visibly LEAKS: inspected for signs of being loose after every 125 hours The shock absorber should hold pressure and only need to be topped up occasionally. -
Page 14: Drawings And Equipment List
DRAWINGS AND EQUIPMENT LIST The illustrated parts breakdown is designed to provide a functional overview of the SHOCKWAVE S5 Marine Suspension Module and provide a reference to points covered in the user manual. These drawings show: • The name and location of major components •... -
Page 15: Suspension Module Drawing (Sw-05026)
SUSPENSION MODULE DRAWING (SW-05026) ITEM PART NO. DESCRIPTION SW-04963 S5-PRO BOTTOM-PLATE SW-04964 S5-PRO TOP PLATE SW-04938 S5 CAST A-ARM FORWARD SW-04937 S5 CAST A-ARM AFT SW-04747 S5 PIVOT BUSHING SW-04748 S5 BUSHING SPACER SW-04867 SHOCK ABSORBER FA-M12X110-HH-CS S5 BOLT HEX HEAD... -
Page 16: Emergency Procedures/Troubleshooting
EMERGENCY PROCEDURES/TROUBLESHOOTING CONDITION CAUSE SOLUTION(S) • Check system for leaks by applying soapy water to system connections and look for bubbles. If a leak is found, replace the • Leak in system shock absorber Suspension module is lower than normal or •... -
Page 17: How To Videos
S5 Suspension Module simple adjustment with a maximum inflation and the S5 Jockey Seat, fitting perfectly below the S5 pressure of 350 psi. Module. Call for pricing and available height options. - Page 18 17” wide. Thanks specifically for the S5 and built to the same high to the 6” of vertical adjustability it can accommodate level of durability and corrosion resistance. The...
-
Page 19: General Boating Best Practices And Safety
GENERAL BOATING BEST PRACTICES AND SAFETY SHOCKWAVE Marine Suspension Modules are designed to mitigate shock and vibration encountered in high-speed vessel operation in rough seas. Following the suggestions in this section will ensure that you are getting the most out of the product. -
Page 20: Cautions And Warnings
Your SHOCKWAVE S5 Marine Suspension Module will mitigate the effects of shock and vibration, reducing the potential of injury, but it will NOT prevent the possibility of injury. The increased level of comfort and control provided by SHOCKWAVE S5 Marine Suspension Seating will allow the craft to operate at higher speeds in sea states which create high shock loads on the craft and potentially the occupants.
