Summary of Contents for Shockwave S5
- Page 1 USER MANUAL MARINE SUSPENSION MODULE...
- Page 2 For customer inquiries and service support please • Corbin2 Seat call +1.778.426.8544 • Corbin2 Seat with Flip Bolster email support@shockwaveseats.com • SHOCKWAVE S5 Swivel Slide, Swivel, Slide, and Height Adjust ADDRESS 2074 Henry Ave. Sidney BC Canada V8L 5Y1 WEBSITE www.shockwaveseats.com...
-
Page 3: Table Of Contents
SHOCK COMPRESSION ADJUSTMENT SETTINGS CHANGING SUSPENSION MODULE HEIGHT REBOUND ADJUSTMENT SERVICE TIPS HOW TO VIDEOS DRAWINGS AND EQUIPMENT LIST SUSPENSION MODULE DRAWING (SW-05026) ACCESSORIES EMERGENCY PROCEDURES/TROUBLESHOOTING GENERAL BOATING BEST PRACTICE AND SAFETY CAUTIONS AND WARNINGS WARRANTY AND WARRANTY POLICY SHOCKWAVE COMMUNITY... -
Page 4: Mounting Your Suspension Module
We have created a series of ‘how to’ videos on our website to help you install your SHOCKWAVE S5. Visit Congratulations on your purchase of a SHOCKWAVE S5 Marine Suspension www.shockwaveseats.com/howto Module. We hope you enjoy this new boating experience offering you access to for more information. -
Page 5: Setting Up The Suspension Module
Strength of decks and deck mountings is the responsibility of the boat builder or installer of the seats. SHOCKWAVE assumes no liability for suspension modules that are incorrectly installed. -
Page 6: Steps To Set Up The Suspension Module
Cycle the shock absorber through its travel by bouncing on the seat 5 times. Do not sit on the seat with the SHOCKWAVE S5 Pump attached! Damage will occur to the shock and pump. Note, SHOCKWAVE S5 PUMP sold separately. -
Page 7: Shock Compression Adjustment Settings
SHOCK COMPRESSION ADJUSTMENT SETTINGS Setting the sag height is designed to be a starting point. To get the most out of the suspension module the shock absorber can be fine-tuned. This is done using a combination of compression and rebound damping to optimize ride quality as well as for varying sea conditions. -
Page 8: Changing Suspension Module Height
CHANGING SUSPENSION MODULE HEIGHT 201mm Spacer The SHOCKWAVE S5 comes with the shock absorber in the front mount position which is the lowest height configuration. If a higher installation height is required you will need to install one of the two Front Mount spacers provided. -
Page 9: Rebound Adjustment
REBOUND ADJUSTER Do not sit on the seat with the SHOCKWAVE S5 Pump attached! Damage will occur to the shock and pump. Note, SHOCKWAVE S5 PUMP sold separately. -
Page 10: Service Tips
LEAKS The shock absorber uses a patented sealing SHOCKWAVE recommends that all bolts should be visibly system. The shock absorber should hold pressure inspected for signs of being loose. Always use a thread- between settings and should only need to be topped up locking sealant on threads to prevent loosening of parts. -
Page 11: How To Videos
HOW TO VIDEOS For complete instructions, including video tutorials of how to install your Shockwave S5, please visit www.shockwaveseats.com/howto, where we have a comprehensive guide for installation options. For further instruction, please contact your Shockwave S5 dealer or email support@shockwaveseats.com. -
Page 12: Drawings And Equipment List
DRAWINGS AND EQUIPMENT LIST The illustrated part breakdown is designed to provide a functional overview of the SHOCKWAVE S5 Marine Suspension Module and provide a reference to points covered in the user manual. These drawings show: • The name and location of major components •... -
Page 13: Suspension Module Drawing (Sw-05026)
SUSPENSION MODULE DRAWING (SW-05026) ITEM PART NO. DESCRIPTION SW-04963 S5-PRO BOTTOM-PLATE SW-04964 S5-PRO TOP PLATE SW-04938 S5 CAST A-ARM FORWARD SW-04937 S5 CAST A-ARM AFT SW-04747 S5 PIVOT BUSHING SW-04748 S5 BUSHING SPACER SW-04867 SHOCK ABSORBER FA-M12X110-HH-CS S5 BOLT HEX HEAD... -
Page 14: Accessories
Available in Onyx the S5 and built to the same high level of durability and (black), Desert (tan) and Storm (White). corrosion resistance. The slide offers 5 inches of fore-aft travel and the 360-degree swivel locks in place in any of 16... -
Page 15: Emergency Procedures/Troubleshooting
EMERGENCY PROCEDURES/TROUBLESHOOTING CONDITION CAUSE SOLUTION(S) • Check system for leaks by applying soapy water to system connections and look for bubbles. If leak found replace • Leak in system shock absorber. Suspension module is lower than normal or • Worn or corroded fill valve •... -
Page 16: General Boating Best Practice And Safety
GENERAL BOATING BEST PRACTICE AND SAFETY SHOCKWAVE Marine Suspension Modules are designed to mitigate shock and vibration encountered in high-speed vessel operation in rough seas. Following the suggestions in this section will ensure that you are getting the most out of the product. -
Page 17: Cautions And Warnings
Your SHOCKWAVE S5 Marine Suspension Module will mitigate the effects of shock and vibration, reducing the potential of injury, but it will NOT prevent the possibility of injury. The increased level of comfort and control provided by SHOCKWAVE S5 marine suspension seating will allow the craft to operate at higher speeds in sea states which create high shock loads on the craft and potentially the occupants. -
Page 18: Warranty And Warranty Policy
WARRANTY AND WARRANTY POLICY SHOCKWAVE Seats expressly warrants that all mechanical seat components in its MARINE AND OTHER and SUSPENSION SEATS shall be free from defects in material and workmanship for three years from the date-of-sale provided such seats are subject to normal use and receive proper maintenance. SHOCKWAVE SEATS expressly warrants that the cushions and seat covers shall be free from defectively sewn seams for a period of 90 days or 750 hours, whichever comes first, excluding normal wear and tear. -
Page 19: Shockwave Community
JOIN THE SHOCKWAVE COMMUNITY @SHOCKWAVESEATS @SHOCKWAVESEATS youtube.com/shockwaveseats...
