Motorola Advisor TPG2200 Manual

M
TM
Advisor TPG2200 Pager
Standard Capacity Battery
Door with Belt Clip
PMHN4464_
*MN009016A01*
MN009016A01-AA
en-US
MOTOROLA, MOTO, MOTOROLA SOLUTIONS
and the Stylized M logo are trademarks or regis-
tered trademarks of Motorola Trademark Hold-
ings, LLC and are used under license. All other
trademarks are the property of their respective
owners. © 2022 Motorola Solutions, Inc. All
rights reserved.
Printed in
Attaching Battery Cover with Belt
Clip
1. Turn the belt clip to horizontal position.
Note: Ensure the latch button is at the Unlock
position before attaching the battery cover.
2. Insert the bottom tabs of the battery cover
into the pager housing slots.
Housing Slots
de-DE
Removing Battery Cover
1. Turn the belt clip to horizontal position.
2. Slide the latch button to the left to unlock
the battery cover.
3. To remove the battery cover, pull the
latches on both sides to disengage the
battery cover from the pager.
Note: The belt clip can in vertical or horizontal
position.
3. Ensure the bottom tabs are engaged with
the housing and press the battery cover
towards the pager until it clicks into place.
4. Lock the battery cover by sliding the
latch button to the right.
5. Turn the belt clip to vertical position and
ensure the latch button in at lock position.
