- Page 1 Installation, use and maintenance instructions Forced draught gas burner Code Model Type 3751982 GAS 3 519T80 2915859 (3) - 02/2010...
- Page 2 DECLARATION Declaration of conformity in accordance with ISO / IEC 17050-1 Manufacturer: RIELLO S.p.A. Address: Via Pilade Riello, 7 37045 Legnago (VR) Product: Forced draught gas burner Model: GAS 3 These products are in compliance with the following Technical Standards:...
-
Page 3: Technical Data
TECHNICAL DATA Thermal output 130 - 340 kW 112,000 - 292,000 kcal/h Fuel Natural gas Pci 8 - 10 kWh/m = 7000 - 8600 kcal/m For maximum output 11,1 mbar are needed measured at the coupling with Minimum gas pressure nil pressure in the combustion chamber and gas with calorific value of 8600 kcal/m Maximum gas pressure... -
Page 4: Standard Equipment
STANDARD EQUIPMENT Quantity Description Flange Gasket Screws Flange gasket ACCESSORIES • RADIO DISTURBANCE PROTECTION KIT code 3010386 If the burner is installed in places particularly subject to radio disturbance (emission of signals exceeding 10 V/m) owing to the presence of an INVERTER, or in applications where the length of the thermostat connections exceeds 20 metres, a protection kit is available as an interface between the control box and the burner. -
Page 5: Working Range
WORKING RANGE COMBUSTION CHAMBER PRESSURE - MAXIMUM OUTPUT (in compliance with DIN 4788) kcal/h D1788 MINIMUM GAS PRESSURE - OUTPUT Pressure: detected at the pressure test-point 7) (fig. 1) with nil mbar into the combustion chamber. Should the combustion chamber be pressurized, the pressure necessary will be that of the graph plus the pressurization value. - Page 6 BURNER ELECTRICAL WIRING (carried out in the factory) D2563 Capacitor Protection against radio interference Relay Burner terminal strip Fan motor Air pressure switch RMG Control box Ionisation probe Ignition transformer Burner earth TTENTION In the case of phase-phase feed, a bridge must be fitted on the control box terminal board between terminal 6 and the earth terminal.
- Page 7 ELECTRICAL CONNECTIONS TO THE WIRING TERMINAL BLOCK (to be carried out by the installer) Remote lock-out signal Minimum gas pressure switch Burner earth Limit control device system Safety control device system Gas safety shut off valve Gas shut off valve D2658 Notice - Leads minimal section 1 mm...
-
Page 8: Burner Start-Up Cycle
BURNER START-UP CYCLE Air-purge: loosen the screw placed on the minimal gas pressure switch mounted on the gas train Screw Plug for pressure measure Pressure switch S7506 AIR PRESSURE SWITCH The air pressure switch setting shall be carried out after having S7507 set all other adjustments of the burner and the air pressure switch shall be at its lowest set-point. -
Page 9: Combustion Head Adjustment
COMBUSTION HEAD ADJUSTMENT Two separate adjustments have to be made: air and gas. These adjustments can be carried out when the burner is still open, during the installation (see page 2 - Fixing to the boiler). Air setting Loosen the two screws 1) and move the internal part of the combustion head 2) so that its rear edge 3) is coincident with the desired set-point on the plate 4). -
Page 10: Combustion Checks
COMBUSTION CHECKS It is advisable to not exceed 10% of CO (gas with calorific value of 8600 kcal/m ), in order to avoid the risk that small changes of the adjustments due, for instance, at draught variation, may cause com- bustion with insufficient air and consequently formation of CO. - Page 11 BURNER STARTING DIFFICULTIES AND THEIR CAUSES Signal Problem Possible cause Recommended remedy 2 blinks Once the pre-purg- 1 - The operation solenoid lets little gas . Increase ing phase and safety through time have passed, 2 - One of the two solenoid valves does Replace the burner goes into not open.
- Page 12 Signal Problem Possible cause Recommended remedy 10 blinks The burner does not 32 - Incorrect electrical wiring ..Check switch on, and the lockout appears The burner goes into 33 - Defective control box ... . . Replace lockout 34 - Presence of electromagnetic .
-
Page 13: Normal Operation / Flame Detection Time
NORMAL OPERATION / FLAME DETECTION TIME The control box has a further function to guarantee the correct burner operation (signal: GREEN LED perma- nently on). To use this function, wait at least ten seconds from the burner ignition and then press the control box button for a minimum of 3 seconds. -
Page 14: Operating Fault Diagnostics
OPERATING FAULT DIAGNOSTICS The control box has a self-diagnostic system, which easily allows identifying the operating faults (RED LED signal). ITo use this function, wait at least ten seconds from the safety lock out, and then press the reset button for a minimum of 3 seconds. - Page 16 RIELLO S.p.A. I-37045 Legnago (VR) Tel.: +39.0442.630111 http:// www.riello.it http:// www.rielloburners.com Subject to modifications...
