T17e Server Installation
© Copyright Bitmaintech Pte.Ltd. 2007 – 2019. All rights reserved.
Bitmaintech Pte.Ltd. (Bitmain) reserves the right to make corrections, modifications, enhancements, improvements, and other
changes to its products and services at any time and to discontinue any product or service without notice.
Customers should obtain the latest relevant information before placing orders and should verify that such information is current and
complete. All products are sold subject to Bitmain's terms and conditions of sale supplied at the time of order acknowledgment.
Bitmain warrants performance of its products to the specifications applicable at the time of sale in accordance with Bitmain's standard
warranty. Testing and other quality control techniques are used to the extent Bitmain deems necessary to support this warranty.
Except where mandated by government requirements, testing of all parameters of each product is not necessarily performed.
Bitmain assumes no liability for third-party applications assistance. Customers are responsible for their products and applications
using Bitmain components. To minimize the risks associated with customer products and applications, customers should provide
adequate design and operating safeguards.
Bitmain does not warrant or represent that any license, either express or implied, is granted under any Bitmain patent right, copyright
or other Bitmain intellectual property right relating to any combination, machine, or process in which Bitmain products or services
are used. Information published by Bitmain regarding third-party products or services does not constitute a license from Bitmain to
use such products or services or a warranty or endorsement thereof. Use of such information may require a license from a third party
under the patents or other intellectual property of the third party, or a license from Bitmain under the patents or other intellectual
property of Bitmain.
Resale of Bitmain products or services with statements different from or beyond the parameters stated by Bitmain for that product
or service voids all express and any implied warranties for the associated Bitmain product or service and is an unfair and deceptive
business practice. Bitmain is not responsible or liable for any such statements.
All company and brand products and service names are trademarks or registered trademarks of their respective holders.
Guide
Document Version 1.0
Oct. 2019

Advertisement

Table of Contents
loading

Summary of Contents for BITMAIN ANTMINER T17e

  • Page 1 Use of such information may require a license from a third party under the patents or other intellectual property of the third party, or a license from Bitmain under the patents or other intellectual property of Bitmain.
  • Page 2 T17e Server Installation Guide All text and figures included in this publication are the exclusive property of Bitmaintech Pte.Ltd. (Bitmain), and may not be copied, reproduced, or used in any way without the express written permission of Bitmain. Information in this document is subject to change without notice and does not represent a commitment on the part of Bitmain.
  • Page 3: Table Of Contents

    T17e Server Installation Guide Table of Contents 1. Overview ............................. 4 1.1 T17e Server Components ......................... 5 1.2 Specifications ............................ 7 2. Setting Up the Server ........................... 8 3. Configuring the Server ........................10 4. Monitoring Your Server........................11 5. Administering Your Server ......................... 12 5.1 Checking Your Firmware Version....................
  • Page 4: Overview

    1.Overview 1. Overview The T17e server is Bitmain’s newest version in the 17e server series. Power supply APW9+ is part of T17e server. All T17e servers are tested and configured prior to shipping to ensure easy set up. Front View...
  • Page 5: T17E Server Components

    T17e Server Installation Guide 1.Overview T17e Server Components The main components and controller front panel of T17e servers are shown in the following figure: - 5 -...
  • Page 6 T17e Server Installation Guide 1.Overview APW9+ Power Supply: Note: 1.Power supply APW9+ is part of T17e server. For detailed parameters, please refer to the specifications below. 2.Additional two power cords are needed. - 6 -...
  • Page 7: Specifications

    T17e Server Installation Guide 1.Overview 1.2 Specifications Product Glance Value Version T17e Model No. 266-Aa Crypto Algorithm/Coins SHA256/BTC/BCH Hashrate, TH/s 53.00 Reference power efficiency on wall @25°C, 55.00+10% J/TH Value Detailed Characteristics Hardware Configuration Miner Size (Length*Width*Height, w/o 298.0*175.0*304.0 (1-1) package), mm (1-2) Net weight, kg...
  • Page 8: Setting Up The Server

    Setting Up the Server To set up the server: The file IPReporter.zip is supported by Microsoft Windows only. Go to the following site: https://shop.bitmain.com/support.htm?pid=00720160906053730999PVD2K0vz0693 2. Download the following file: IPReporter.zip. 3. Extract the file. The default DHCP network protocol distributes IP addresses automatically.
  • Page 9 T17e Server Installation Guide 2.Setting Up the server 7. On the controller board, click the IP Report button. Hold it down until it beeps (about 5 seconds). The IP address will be displayed in a window on your computer screen. 8.
  • Page 10: Configuring The Server

    T17e Server Installation Guide 3.Configuring the Server Configuring the Server Setting Up the Pool To configure the server: 1. click General Settings. 2. Set the options according to the following table: Option Description Pool URL Enter the URL of your desired pool. The T17e servers can be set up with three mining pools, with decreasing priority from the first pool (pool 1) to the third pool (pool 3).
  • Page 11: Monitoring Your Server

    T17e Server Installation Guide 4. Monitoring Your Server Monitoring Your server To check the operating status of your server: 1. Click the status marked below. Note: The T17e server is with automatic frequency. Firmware will stop running when the Temp (PCB) reaches to 80℃...
  • Page 12: Administering Your Server

    5.2 Upgrading Your System Make sure that the T17e server remains powered during the upgrade process. If power fails before the upgrade is completed, you will need to return it to Bitmain for repair. To upgrade the server’s firmware: 1. In System, click Upgrade.
  • Page 13: Modifying Your Password

    T17e Server Installation Guide 5. Administering Your Server 2. For Keep Settings: Select the check box to keep your current settings (default). ■ Clear the check box to reset the server to default settings. ■ 3. Click the (Browse) button and navigate to the upgrade file. Select the upgrade file, then click Flash image. A message appears notifying you if the T17e firmware can be upgraded and if yes, will then proceed to flash the image.
  • Page 14: Environmental Requirements

    T17e Server Installation Guide Environmental Requirements Please run your server in accordance with the following requirements 1. Basic Environmental Requirements: 1.1. Climatic Conditions: Description Requirement Operating Temperature 0-40℃ Operating Humidity 10-90%RH (non-condensing) Storage Temperature -20-70℃ Storage Humidity 5-95%RH(non-condensing) Altitude <2000m 1.2.
  • Page 15 T17e Server Installation Guide 2.2 Requirements of Corrosive Gas Corrosive Gas Unit Concentration < 3 < 10 < 1 < 50 < 1 < 500 < 2 Note: ppb (part per billion) refers to the unit of concentration,1ppb stands for the volume ratio of part per billion.
  • Page 16: Regulations

    T17e Server Installation Guide Regulations: FCC Notice (FOR FCC CERTIFIED MODELS): This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
