WF9*F5****
Washing machine
User manual
imagine the possibilities
Thank you for purchasing this Samsung product.
Untitled-1 1
2016-11-17
2:59:11

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WF9 F5 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samsung WF9 F5 Series

Summary of Contents for Samsung WF9 F5 Series

  • Page 1 WF9*F5**** Washing machine User manual imagine the possibilities Thank you for purchasing this Samsung product. Untitled-1 1 2016-11-17 2:59:11...

  • Page 2: Table Of Contents

    Content Safety information What you need to know about the safety instructions Important safety symbols What the icons and signs in this user manual mean: ........... . .4 Important safety precautions Instructions about the WEEE Setting up your washing machine...
  • Page 3 Cleaning your washing machine Eco Drum Clean Cleaning procedures ................. . 31 Eco Drum Clean auto alarm function .

  • Page 4: Safety Information

    Safety information Congratulations on your new Samsung washing machine. This manual contains important information on the installation, use and care of your appliance. Please take some time to read this manual to take full advantage of your washing machine’s many benefits and features.

  • Page 5: Important Safety Precautions

    Important safety precautions WARNING: To reduce the risk of fire, electric shock, or injury to persons when using your appliance, follow basic precautions, including the following: 1. This appliance is not to be used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
  • Page 6 WARNING: Critical installation WARNINGS The installation of this appliance must be performed by a qualified technician or service company. • Failure to do so may result in electric shock, fire, an explosion, problems with the product, or injury. The appliance is heavy, therefore take care when lifting it. Plug the power cord into a wall socket that meets local electrical specifications.
  • Page 7 This appliance should be positioned so that the power plug, the water supply taps, and the drain pipes are accessible. CAUTION: Installation CAUTIONS This appliance should be positioned in such a way that the power plug is easily accessible. • Failure to do so may result in electric shock or fire due to electric leakage.
  • Page 8 • Failure to do so may result in electric shock or fire. If any foreign substance enters into the appliance, unplug the power plug and contact you nearest Samsung Customer Service. • This may result in electric shock or fire.
  • Page 9 Samsung and no responsibility can be attributed to Samsung for malfunctions or damages resulting from such misuse. Do not stand on the appliance or place objects (such as laundry, lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance.

  • Page 10: Instructions About The Weee

    Business users should contact their supplier and check the terms and conditions of the purchase contract. This product and its electronic accessories should not be mixed with other commercial wastes for disposal. For information on Samsung’s environmental commitments and product specific regulatory obligations e.g. REACH visit: samsung.com/uk/aboutsamsung/samsungelectronics/corporatecitizenship/data_corner.html English - 10...

  • Page 11: Setting Up Your Washing Machine

    Carefully unpack your washing machine, and make sure you’ve received all of the parts shown below. If your washing machine was damaged during shipping or if you do not have all of the parts, contact the Samsung Customer Service or your Samsung dealer.

  • Page 12: Meeting The Installation Requirements

    Meeting the installation requirements Electrical supply and grounding WARNING: Never use an extension cord. Use only the power cord that comes with your washing machine. When preparing the installation, ensure that your power supply offers: • An AC 220 - 240 V / 50 Hz fuse or circuit breaker •...

  • Page 13: Drain

    Drain Samsung recommends a standpipe height of 65 cm. The drain hose must be routed through the drain hose clip to the standpipe. The standpipe must be large enough to accept the outside diameter of the drain hose. The drain hose is attached at the factory.

  • Page 14: Installing Your Washing Machine

    Installing your washing machine CAUTION: Do not plug the power cord into a wall socket before the installation is complete. WARNING: Packaging materials can be dangerous to children; keep all packaging material (plastic bags, polystyrene, etc.) well out of the reach of children. STEP 1 - Selecting a location Before you install the washing machine, make sure the location: •...
  • Page 15 STEP 3 - Adjusting the levelling feet When installing your washing machine, ensure that the power plug, the water supply, and the drain are easily accessible. 1. Slide the washing machine into position. 2. Loosen all the lock nuts with the wrench. 3.
  • Page 16 3. First, loosen the four screws on the adaptor using a '+’ type screwdriver. part (D) part (E) Next, hold and turn following the arrow until there is a 5 mm gap. (*): 5 mm 4. Connect the adaptor to the water tap by tightening all the screws firmly while lifting the adaptor upwards.
  • Page 17 Connecting the hot water supply hose (selected models) 1. Connect the red L-shaped arm fitting for the hot water supply hose to the hot water supply intake at the back of the washing machine. Then part (A) tighten it by turning clockwise by hand.
  • Page 18 STEP 6 - Running Calibration Mode Your Samsung washing machine detects the weight of the laundry automatically. For a more accurate weight detection, it is recommended running Calibration Mode immediately after installing the washing machine. Follow the steps below to run Calibration Mode.

  • Page 19: Using Your Washing Machine

    Using your washing machine With your new Samsung washing machine, the hardest part of doing laundry will be deciding which load to wash first. Detergent and Additives Information Using the proper detergent The type of detergent you should use is based on the type of fabric (cotton, synthetic, delicate items, wool), colour, wash temperature, and degree of soiling.
  • Page 20 1. Pull out the detergent drawer at the top left of the washing machine. 2. Add the recommended amount of laundry detergent into the main wash detergent compartment before starting your washing machine. To use liquid detergent, use the liquid detergent guide (refer to the "Using liquid detergent (selected models)"...

  • Page 21: Laundry Capsules

    Laundry capsules To get the best results from using laundry capsules, please follow these instructions. 1. Put the capsule in the bottom of the empty drum towards the rear. 2. Put the laundry in the drum on top of the capsule. CAUTION: For cycles using cold water or cycles that complete in less than one hour, it is recommended to use a liquid detergent.

  • Page 22: Doing Laundry For The First Time

    Doing laundry for the first time Before doing laundry for the first time, you must run a complete empty cycle (i.e. without laundry). 1. Turn on the water supply to the washing machine. 2. Add a little detergent to the main wash compartment in the detergent drawer.

  • Page 23: Using The Control Panel

    Using the control panel 1. Cycle Selector Select the tumble pattern and spin speed for the cycle. For more information on each cycle, refer to the "Using the Cycle Selector" section on page 25. 2. Digital graphic display Displays the remaining wash cycle time, all cycle information, and error codes. Temp.
  • Page 24 Easy Iron button Press this button to prepare your laundry so that it can be easily ironed by reducing the wrinkles during the Spin cycle. Easy Iron is only available with the: Cotton, Synthetics, Denim, Stain Away, Dark Garment, Daily Wash, Super Eco Wash, Baby Care and Bedding cycles.

  • Page 25: Using The Cycle Selector

    Using the Cycle Selector Cycle Usage Cotton For averagely or lightly soiled cottons, table linen, underwear, towels, shirts, etc. For averagely or lightly soiled blouses, shirts, etc., made of polyester (diolen, trevira), Synthetics polyamide (perlon, nylon) or other similar blends. A wash cycle with a higher water level and an extra rinse cycle that ensures that no Denim detergent remains to mark your clothing.

  • Page 26: Child Lock

    Child Lock The Child Lock function allows you to lock the buttons so that the wash cycle you’ve chosen can’t be changed. Activating/Deactivating If you want to activate or deactivate the Child Lock function, hold down the Temp. and Rinse buttons at the same time for 3 seconds. The "Child Lock "...

  • Page 27: Smart Check

    The Smart Check function has been optimized for Galaxy & iPhone series (applicable models only). Downloading the Samsung Smart Washer app Download the Samsung Smart Washer app to your mobile phone from the Android market or Apple App store and install it. You can easily find it by searching for "Samsung Smart Washer".

  • Page 28: Doing Laundry

    Doing laundry Doing laundry using the Cycle Selector Your new washing machine makes washing laundry easy, using Samsung’s automatic control system "Fuzzy Control". When you select a wash cycle, the machine will set the correct temperature, washing time, and washing speed.

  • Page 29: Doing Laundry Manually

    Doing laundry manually You can do laundry manually without using the Cycle Selector. 1. Turn on the water supply to the washing machine. 2. Open the door. 3. Add your laundry loosely into the drum without overfilling it. 4. Close the door. 5.
  • Page 30 Prewashing cotton Your new washing machine, combined with modern detergents, will give perfect washing results, saving you energy, time, water and detergent. However, if your cotton is particularly dirty, perform a prewash cycle with a protein-based detergent. Determining the load capacity Do not overload the washing machine or your laundry may not wash properly.
  • Page 31 Cleaning your washing machine Keeping your washing machine clean improves its performance, reduces the need for unnecessary repairs, and lengthens its life. CAUTION: Never use the Eco Drum Clean cycle when laundry is in the washing machine. This may result in damage to the laundry or a problem with the washing machine. Eco Drum Clean This cycle is a self-cleaning cycle that removes mold or dirt that may accumulate inside the drum.
  • Page 32 Draining the washing machine in an emergency If there is a power outage, drain all remaining water before removing your laundry. 1. Unplug the washing machine from the electrical outlet. 2. Gently press the top area of the filter cover (A) to open.
  • Page 33 Cleaning the debris filter We recommend cleaning the debris filter at least 5 or 6 times a year, or when the "5E" error code is displayed. If foreign substances accumulate at the debris filter, the performance of the Eco Bubble function will be reduced. CAUTION: Before cleaning the debris filter, make sure to unplug the washing machine from the electrical outlet.
  • Page 34 Cleaning the detergent drawer and drawer recess 1. Press the release lever (A) on the inside of the detergent drawer and pull the detergent drawer out. 2. Remove the release lever (A) and the liquid detergent guide from the detergent drawer. 3.
  • Page 35 Maintaining your washing machine Repairing a frozen washing machine If the temperature drops below freezing and your washing machine is frozen: 1. Unplug the washing machine from the electrical outlet. 2. Pour warm water over the water tap to loosen the water supply hose(s). 3.
  • Page 36 Troubleshooting and information codes Checkpoints If you encounter a problem with the washing machine, first check the table below and try the suggestions. PROBLEM ACTION • Make sure the washing machine is plugged in. • Make sure the door is properly closed. •...
  • Page 37 PROBLEM ACTION Start/Pause to stop the washing machine. • Press or tap • It may take a few moments for the door lock mechanism to disengage. • The door will not open until 3 minutes after the washing machine has stopped or the power turned off.
  • Page 38 PROBLEM ACTION • Use the High or Extra High spin speed. • Use high efficiency (HE) detergent to reduce oversudsing. Load is wet at the end of • Load is too small. Small loads (one or two items) may become unbalanced a cycle.
  • Page 39 “UE” error code may be displayed. cE/3E/Uc • Call the Samsung Customer Service. For any codes not listed above, or if the suggested solution doesn’t fix the problem, call the Samsung Customer Service or your Samsung dealer. English - 39 Untitled-1 39...
  • Page 40 Cycle chart Cycle chart ( user option) Max load (kg) DETERGENT Spin Speed (MAX) rpm Max Temp. CYCLE (˚C) WF9*F5 Prewash Wash Softener 1400 1200 1400 1200 Cotton 1200 1200 Synthetics Denim 1200 1200 Stain Away 1200 1200 Dark Garment 1400 1200 Daily Wash...
  • Page 41 Appendix Fabric care chart The following symbols provide garment care directions. The care labels include four symbols in this order: washing, bleaching, drying and ironing (and dry cleaning when necessary). The use of symbols ensures consistency among garment manufacturers of domestic and imported items. Follow the care label directions to maximize garment life and reduce laundery problems.
  • Page 42 (A) re 1 pW Dimensions Height Unit dimensions Width Depth Net weight Gross weight Package weight Water Pressure 50-800 Electrical connection Voltage 220-240 Power consumption 2000-2400 Frequency Name of company Samsung Electronics Co., Ltd. English - 42 Untitled-1 42 2016-11-17 2:59:26...
  • Page 43 (A) re 1 pW Dimensions Height Unit dimensions Width Depth Net weight Gross weight Package weight Water Pressure 50-800 Electrical connection Voltage 220-240 Power consumption 2000-2400 Frequency Name of company Samsung Electronics Co., Ltd. English - 43 Untitled-1 43 2016-11-17 2:59:26...
  • Page 44 1. Annual energy consumption is based on 220 standard washing cycles for Cotton programs at 60 ˚C and 40 ˚C at full and partial load, and the consumption of off and left-on modes. Actual energy consumption will depend on how the appliance is used. 2.
  • Page 45 Memo Untitled-1 45 2016-11-17 2:59:26...
  • Page 46 Memo Untitled-1 46 2016-11-17 2:59:27...
  • Page 47 Memo Untitled-1 47 2016-11-17 2:59:27...
  • Page 48 QUESTIONS OR COMMENTS? COUNTRY CALL OR VISIT US ONLINE AT 0330 SAMSUNG (7267864) www.samsung.com/uk/support EIRE 0818 717100 www.samsung.com/ie/support DC68-03367W-01 Untitled-1 48 2016-11-17 2:59:27...
