FAIL-SAFE
FWW
FWE
1 3 W - 8 0 W
F l u o r e s c e n t
P O LY C A R B O N AT E H I G H
A B U S E W A L L O R C E I L I N G
L U M I N A I R E
C L E A R P R I S M AT I C
O R W H I T E
• Min. 0.130" thick, one piece
injection molded UV
stabilized polycarbonate
lens
• Captive, stainless steel
tamper-resistant TORX
head screws prevent
unauthorized access
• Die-formed 16 ga. CRS with
welded and ground ends
and internal weld bands for
added strength. Standard
white high reflectance
polyester powder coat
finish
• Lamps by others
• Double wall lens channel
captivates lens to prevent
unauthorized fixture
penetration
• Copper wound HPF, rapid
start, Class P, CBM/ETL
ballast is standard
• U.L. listed, C.S.A. certified,
standard damp label
1438
COOPER LIGHTING
®
D E S C R I P T I O N
Fail-Safe's FWW and FWE
Series combine vandalproof
features with commercial
aesthetics to offer owners an
unbreakable solution to the
problem of broken fixtures in
unsupervised areas like
employee locker rooms or
service station washrooms.
The FWW Series is designed
for wall mount applications.
The FWE Series is designed for
ceiling mount applications. An
emergency battery pack is
available as an option. U.L.
listed, C.S.A. certified,
standard damp label.
E N D V I E W S
FWW
®
-
O R D E R I N G I N F O R M AT I O N
S A M P L E N U M B E R : F W W - 2 4 0 - 1 2 0 - L E 3 - G L R
Product Family
FWW=High Abuse
Wall Luminaire
FWE=High Abuse
Ceiling Mount
Luminaire
Lamp Type
2'
4'
T5 Fluorescent
T5 Fluorescent
128=(1) 28W Lamp
128=(1) 28W Lamp
228=(2) 28W Lamps
228=(2) 28W Lamps
328=(3) 28W Lamps
3
328=(3) 28W Lamps
154=(1) 54W T5HO
154=(1) 54W T5HO
Lamp
254=(2) 54W T5HO
254=(2) 54W T5HO
Lamps
T8 Fluorescent
132=(1) 32W Lamp
T8 Fluorescent
117=(1) 17W Lamp
232=(2) 32W Lamps
217=(2) 17W Lamps
T12 Fluorescent
T12 Fluorescent
140=(1) 40W Lamp
2
240=(2) 40W Lamps
120=(1) 20W Lamp
220=(2) 20W Lamps
2
Biaxial Fluorescent
140BX=(1) 40W Biax
Lamp
240BX=(2) 40W Biax
Lamp
Notes: For additional options, consult your Cooper Lighting Representative. Specifications and Dimensions subject to change without notice.
1
For specific electronic ballast, specify brand and catalog number.
available in non-US voltages and 50Hz for international markets. Consult your Cooper Lighting Representative for availability and ordering
information.
D I M E N S I O N S
M O U N T I N G
A
FWW
5 1/4"
2' (nominal)
(133mm)
FWE
5 1/4"
2' (nominal)
(133mm)
FWW
5 1/4"
4' (nominal)
(133mm)
FWE
5 1/4"
4' (nominal)
(133mm)
5 1/4"
(133mm)
5" (127mm)
Voltage
3
Ballast
120=120V
LE3=Energy Saving
277=277V
347=347V
Electronic Ballast
EB81=(1) Ballast for
EB82=(2) Ballasts for
EB21=(1) Ballast for
3
EB22=(2) Ballasts for
Lamp
EBX1=(1) Ballast for
Lamps
EBX2=(2) Ballasts for
2
Electronic ballast not available with F20T12 lamps.
B
B
B
B
B
25"
(635mm)
25"
(635mm)
49"
(1245mm)
49"
(1245mm)
5 1/4" (133mm)
FWE
(127mm)
3
Options
EBP=Emergency
Ballast
Battery Pack
FNL=Fluorescent
Night Light (Lamp
1
by others)
GCO=Grounded
use with T8 Lamp
Convenience
Outlet
use with T8 Lamp
GLR=Fuse and Holder
OPL=Opal Diffuser
use with T12 Lamp
2
RIF=Radio
Interference Filter
use with T12 Lamp
SPS=Security Push
2
Button On/Off
Switch
use with Biaxial
WL=Wet Location
Lamp
(covered ceiling
only)
use with Biaxial
Lamp
A
A
A
A
5"
Accessories
(Order Separately)
VRSD=Torxhead
Vandal
Resistant
Screwdriver
3
Products also
1438
