Summary of Contents for Soundigital 6500.1D EVO

  • Page 1 6500.1D 2000.1D Owner's Manual Owner's Manual English English...

  • Page 2: Important Info

    Ÿ continuous sound pressure over 85 dB may cause Efficiency – The SounDigital Class D amplifiers have a irreversible hearing loss. total efficiency (power source + output) higher than 70%, assuring a battery consumption and a heating lower than the expected.

  • Page 3: Panels Description

    PANELS DESCRIPTION...
  • Page 4 PANELS DESCRIPTION Audio Output RCA connector; Audio Input RCA connector; Variable Low Pass Filter control (5Hz - 80Hz); Variable High Pass Filter control (80Hz - 20kHz); Variable signal gain control; Variable bass boost control (0dB - +12dB); Variable bass reinforcement frequency control (35Hz ~ 70Hz); Positive speaker connector (+);...

  • Page 5: Installation

    Warning! or damage to the amplifier. The SounDigital amplifiers are micro controlled and have an electronic monitoring of all of their functions, offering useful information to the user through their leds.
  • Page 6 INSTALLATION Unplug the negative (-) terminal of the battery before proceeding with any eletrical installation in the vehicle. OUTPUT Output for additional amplifier To avoid unwanted noise in the system, join the Gain positioning over the correct ground points of the equipment and audio output to spot may cause noise, trigger only one point.

  • Page 7: Technical Specs

    TECHNICAL SPECS RMS Power 6500.1D EVO 2 Ω 6500.1D EVO 1 Ω Impedance 4Ω 1Ω 2Ω 2Ω 4Ω 8Ω Power @ 12.6V 6500W 3575W 1966W 6500W 3575W 1966W Power @ 14.4V 8489W 4669W 2568W 8489W 4669W 2568W Input signal and filters...

  • Page 8: Limited Warranty

    LIMITED WARRANTY SounDigital warrants the original purchaser that this product shall be free of defects in materials an workmanship for a period of twelve (12) months from the original date of purchase. Some countries have extended warranty in case the product is installed by an authorized dealer.
