Contents
Overview ··········································································································· 1
About this guide ······························································································· 1
Product overview ······························································································ 1
Installation preparations ··················································································· 2
Installation site ·································································································· 2
Installation tools ································································································ 2
Installing the switch ··························································································· 3
Installation flow ································································································ 3
Installing the switch in a rack ········································································· 4
Attaching an ESD wrist strap ································································· 4
Installation accessories ··········································································· 4
Mounting positions ·················································································· 5
Installing an S5820X-26S switch in a 19-inch rack ···························· 7
Installing an S5820X-28C switch in a 19-inch rack ························· 10
Installing an S5820X-28S switch in a 19-inch rack ·························· 12
Mounting the switch on a workbench ·························································· 13
Connecting the grounding cable ·································································· 14
Connecting the grounding cable for an S5820X-28C or S5820X-28S
switch ······································································································ 15
Installing fan trays ·························································································· 17
Installing power modules ··············································································· 18
Connecting the power cord ·········································································· 21
Installing an interface card ··········································································· 25
Installing an OAP card ·················································································· 26
i

























Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S5820X-28C and is the answer not in the manual?

Questions and answers

Related Manuals for H3C S5820X-28C

Summary of Contents for H3C S5820X-28C

  • Page 1: Table Of Contents

    Mounting positions ·················································································· 5   Installing an S5820X-26S switch in a 19-inch rack ···························· 7   Installing an S5820X-28C switch in a 19-inch rack ························· 10   Installing an S5820X-28S switch in a 19-inch rack ·························· 12   Mounting the switch on a workbench ·························································· 13  ...

  • Page 2: Overview

    The H3C S5820X Switch Series includes the following models: S5820X-28S • S5820X-28C • S5820X-26S • NOTE: The H3C S5820X Switch Series models and installation procedures might be updated without prior notice. For the latest quick start guide, go to http://www.h3c.com.hk.

  • Page 3: Installation Preparations

    To ensure correct operation and long service life of your switch, install it in an environment that meets the temperature, humidity, and electromagnetic shield (EMS) requirements. For more information, see H3C S5820X Switch Series Installation Guide. Installation tools The installation tools are not provided with the switch.

  • Page 4: Installing The Switch

    Installing the switch Installation flow Figure 2 Installation flow...

  • Page 5: Installing The Switch In A Rack

    Figure 3 Attaching an ESD wrist strap Installation accessories The S5820X-28S/S5820X-26S switch comes with a pair of 1 U load-bearing mounting brackets. The S5820X-28C switch comes with a pair of 2 U load-bearing mounting brackets, and each mounting bracket is attached with a cable management bracket.

  • Page 6: Mounting Positions

    Figure 5 Chassis rail and slide rail (1) Chassis rail (2) Slide rail Mounting positions The S5820X-28S and S5820X-28C switches provide three mounting positions: one front mounting position (near the network ports), one mid-mounting position, and one rear mounting position (near the power modules). Figure 6...
  • Page 7 Figure 6 Mounting positions on an S5820X-28S switch (1) Front mounting position (2) Mid-mounting position (3) Rear mounting position The S5820X-26S switch provides two mounting positions: one front mounting position (near the network ports) and one rear mounting position (near the power modules), as shown in Figure Figure 7 Mounting positions on an S5820X-26S switch...

  • Page 8: Installing An S5820X-26S Switch In A 19-Inch Rack

    Installing an S5820X-26S switch in a 19-inch rack Table 1 Installing an S5820X-26S switch in a 19-inch rack Installation procedure Remarks Installation diagram • For mounting near the power Attach the mounting modules, see Figure brackets to the Required • For mounting near the ports, switch.
  • Page 9 Figure 8 Installing the mounting brackets near the power modules and installing the chassis rails Figure 9 Installing the mounting brackets near the ports and installing the chassis rails Figure 10 Installing cage nuts in a rack post...
  • Page 10 Figure 11 Attaching slide rails to the rack Figure 12 Connecting the grounding cable to the primary grounding point (1) Grounding sign (2) Grounding cable...

  • Page 11: Installing An S5820X-28C Switch In A 19-Inch Rack

    Figure 13 Installing the switch in the rack (mounting brackets near the power modules) Installing an S5820X-28C switch in a 19-inch rack Table 2 Installing an S5820X-28C switch in a 19-inch rack Installation procedure Remarks Installation diagram Separate the mounting...
  • Page 12 Before you install the mounting brackets in the mid-mounting position, separate the mounting brackets from the cable management bracket. Figure 14 Attaching mounting brackets to the S5820X-28C switch (1) Separate the mounting bracket from the cable management bracket (2) Install mounting brackets near the ports...

  • Page 13: Installing An S5820X-28S Switch In A 19-Inch Rack

    Figure 15 Installing the switch in the rack Installing an S5820X-28S switch in a 19-inch rack Table 3 Installing an S5820X-28S switch in a 19-inch rack Installation procedure Remarks Installation diagram Attach the mounting brackets to the Required Figure switch. Install cage nuts in the rack posts.

  • Page 14: Mounting The Switch On A Workbench

    Figure 17 Installing the switch in the rack Mounting the switch on a workbench CAUTION: Ensure 10 cm (3.94 in) of clearance around the switch. • Do not place heavy objects on the switch. • If a standard 19-inch rack is not available, you can place you switch on a workbench.

  • Page 15: Connecting The Grounding Cable

    Connecting the grounding cable for an S5820X-26S switch The S5820X-26S switch has three grounding points, as shown in Figure H3C recommends that you use the primary grounding point. Figure 19 Grounding points of the S5820X-26S switch (1) Auxiliary grounding point 2 (2) Primary grounding point...

  • Page 16: Switch

    Figure 20 Connecting the grounding cable Connecting the grounding cable for an S5820X-28C or S5820X-28S switch The S5820X-28C and S5820X-28S switches have a grounding point at their rear panels. This guide uses the S5820X-28S switch as an example: To connect the grounding cable: Connect one end of the grounding cable to the grounding point of the switch.
  • Page 17 Figure 21 Connecting one end of the grounding cable to the S5820X-28S switch To connect the other end of the grounding cable to a grounding strip: Cut the grounding cable to a length according to the distance between the switch and the grounding strip. Peel 5 mm (0.20 in) of insulation sheath from the end, and then insert the naked metal part through the black insulation covering into the end of the ring terminal.

  • Page 18: Installing Fan Trays

    The switch supports hot-swappable fan trays. Table 4 lists the fan trays available for the switch. For more information about the fan trays, see H3C LSW1FAN & LSW1BFAN Installation Manual and H3C LSWM1FANSC & LSWM1FANSCB Installation Guide. Table 4 Installing fan trays...

  • Page 19: Installing Power Modules

    Figure 25 Installing an LSWM1FANSC fan tray Installing power modules CAUTION: For an S5820X-28C switch, do not remove the filler modules in the • power module slots. Before you install a PSR300-12A, PSR300-12A1, PSR300-12A2, PSR300-12D1, or PSR300-12D2 power module on an S5820X-28C switch, make sure the filler module has been installed.
  • Page 20 Table 5 lists the power modules available for these switches. For more information about the power modules, see H3C PSR300- 1 2A & PSR300- 1 2D Series Power Modules User Manual, H3C LSVM1AC650 & LSVM1DC650 Power Modules User Manual, and H3C LSVM1AC300 & LSVM1DC300 Power Modules User Manual.
  • Page 21 Figure 27 Installing an LSVM1AC650 power module If only one power module is installed, install the filler panel into another power module slot. Figure 28 uses the S5820X-26S switch as an example. Figure 28 Installing the filler panel on an S5820X-26S switch Before you remove a power module, remove the power cord from the power module.

  • Page 22: Connecting The Power Cord

    Figure 29 Removing an LSVM1AC650 power module Connecting the power cord CAUTION: Connect the power cord after you install the power module in the switch. • Make sure the power module switch is turned off when you connect the • power cord.
  • Page 23 Power module Standard Power cord connection procedures model configuration • PSR300- 1 2D1 Connect the DC power cord, as shown DC power cord • Figure PSR300- 1 2D2 Connect the AC power cord, and use • AC power • LSVM1AC650 the cable tie to secure the power cord cord •...
  • Page 24 Figure 32 Connecting an AC power cord Figure 33 Connecting the DC power cord to a PSR300-12D1 power module...
  • Page 25 Figure 34 Connecting the AC power cord to an LSVM1AC650/LSVM1AC300 power module (1) Cable tie (2) AC power cord (3) Power module handle Figure 35 Connecting the DC power cord to an LSVM1DC650/LSVM1DC300 power module The DC power cord connector for an LSVM1DC650/LSVM1DC300 power module has tabs.

  • Page 26: Installing An Interface Card

    • immediately if no new interface card is installed. In addition to built-in ports, the S5820X-28C switch provides two interface card slots and comes with filler panels in the slots. You can install one or two interface cards as needed. For the interface cards available for the S5820X-28C switch, see H3C S5820X Switch Series Installation Guide.

  • Page 27: Installing An Oap Card

    • immediately if no new OAP card is installed. The S5820X-28C switch provides an OAP card slot and comes with a filler panel in the OAP card slot. You can install an OAP card as needed. For the OAP cards available for the S5820X-28C switch, see H3C S5820X Switch Series Installation Guide.
  • Page 28 Figure 39 Removing the filler panel from an OAP card slot Figure 40 Installing an OAP card...
