deltalight KIX M1 Installation Instruction

Installation instruction
KIX M1
6 232 121 833
= A / N
Ø54mm
Ø2"-1/8
75mm
2"-15/16
Ø94mm
Ø3"-11/16
HEADQUARTERS - www.deltalight.com - USA - www.deltalight.us - CANADA - www.deltalight.ca
90°

Application

Wall or Floor surface mounted
44mm
For exterior and interior use
1"-3/4
Installation to standard 4" octagonal box with optional coverplate or mudkit installation

Color Finish

A - Alu gray
N - Dark gray

Light source

1 x POWER LED 7W

Product description

Surface treated aluminum construction
remote 24Vdc, Class 2 power supply required, non dimmable
Suitable for dry, damp or wet locations
Lens FL-30°
Kap striper B ( removable )
Dust-protected - Protected against water jets
Weight: 2.0lbs 0,9kg

Options

6 207 02 02
6 204 00 116
NORTH AMERICAN EDITION
MUD KIT 2
Coverplate R116
KIX M1
IP55
Conforms to ANSI/UL Std. 2108
Cert. to CAN/CSA Std. 22.2 No. 250.0
Last Update ALLU 07/08/2018
1
