deltalight SUPERNOVA XS RECESSED 330 DIM10 Installation Instruction

Installation instruction
SUPERNOVA XS RECESSED 330 DIM10
6 274 86 3224 ED10
= W
350°
8°
240mm
9"-7/16
Ø330mm
Ø13"
HEADQUARTERS - www.deltalight.com - USA - www.deltalight.us - CANADA - www.deltalight.ca
Ø320mm
Ø12"-5/8
195mm
7"-11/16
60mm
2"-3/8

Application

Ceiling recessed mounted, flush with ceiling or 8°tilted

Installation to a standard EMT/FMC fitting

For indoor use only

Color Finish

W - White

Light source

1 x LED CLUSTER 25W

Product description

Surface treated aluminum construction
Electronic power supply included. 120-277V input, 1050mA-DC current controlled class 2
DIMMING : Lutron Hi-lume 1% EcoSystem/3-wire
Suitable for dry and damp locations
Protected against solid objects greater than 1,0 mm
Weight: 5,9lbs 2,7kg
Accessories not supplied (required)
274 88 036
NORTH AMERICAN EDITION
SUPERNOVA XS RECESSED 330 DIM10
Supernova XS recessed kit 330
NIC
IP40
Conforms to ANSI/UL Std. 1598
Cert. to CAN/CSA Std. 22.2 No. 250.0
Last Update ALLU 07/03/2016
1
