deltalight FEMTOLINE 35 F HE PROFILE Installation Instruction

Installation instruction
FTL35 F HE - PROFILE
6 392 01 00 00
= B / W / ANO
37mm
1"-7/16
25mm
1"
HEADQUARTERS - www.deltalight.com - USA - www.deltalight.us - CANADA - www.deltalight.ca
Application
Ceiling/Wall/Floor surface mounted
For indoor use only
Color finish
B - Black
W - White
ANO - Alu anodized
Specification features
Surface treated aluminum
Input voltage: 24V-DC
Class 2, 2 x 22AWG or 4 x 22AWG cable 2' included.
MAX. lenght profile : 6m = 19'-3/4
Suitable for dry or damp locations
Protected against solid objects greater than 12 mm
Weight: 0,7lbs | 0,3kg
Dimensions
Height:
width:
Accessories
FTL35 F HE - END CAP SET
Optional
5/16" CONDUIT + 2 x 18 AWG L 10'
5/16" CONDUIT + 2 x 18 AWG L 19' 3/4
5/16" CONDUIT + 2 x 18 AWG L 30'
NORTH AMERICAN EDITION
FEMTOLINE 35 F HE - PROFILE
IP20
37 mm = 1"- 7/16
25 mm = 31/32"
392 01 03 01
6 330 98 10
6 330 98 18
6 330 98 30
Conforms to ANSI/UL Std. 2108
Cert. to CAN/CSA Std. 22.2 No. 250.0
Last Update ALLU 21/01/2019
