Dishwasher
User manual
DW60A609*/DW60A608* Series
DW6500AM_DW60A6092FW_EU_DD81-04050B-01_EN.indd 1
2021-09-30
12:36:13

Advertisement

Table of Contents
loading

Related Manuals for Samsung DW60A608 Series

Summary of Contents for Samsung DW60A608 Series

  • Page 1 Dishwasher User manual DW60A609*/DW60A608* Series DW6500AM_DW60A6092FW_EU_DD81-04050B-01_EN.indd 1 2021-09-30 12:36:13...

  • Page 2: Table Of Contents

    Contents Safety information What you need to know about safety instructions Important safety symbols Instructions about the WEEE Important safety precautions Instructions when using your dishwasher Instructions for protecting your children Instructions for installing your dishwasher Installation What’s included Installation requirements Step-by-step installation Skirting board Kick plate (DW60A60**U* Series)
  • Page 3 Troubleshooting Checkpoints Information codes Cycle chart Appendix Transportation/relocation Protection against frost Disposing the dishwasher and helping the environment Energy, water saving tip EPREL information Specifications For standard test English DW6500AM_DW60A6092FW_EU_DD81-04050B-01_EN.indd 3 2021-09-30 12:36:13...

  • Page 4: Safety Information

    If you have any questions or concerns, contact your nearest service center or find help and information online at www.samsung.com. Important safety symbols...

  • Page 5: Instructions About The Weee

    This product and its electronic accessories should not be mixed with other commercial wastes for disposal. For information on Samsung’s environmental commitments and product specific regulatory obligations e.g. REACH, WEEE, Batteries, visit our sustainability page available via Samsung.com English DW6500AM_DW60A6092FW_EU_DD81-04050B-01_EN.indd 5...

  • Page 6: Important Safety Precautions

    Safety information Important safety precautions To reduce the risk of fire, electric shock, or injury to persons when using your appliance, follow basic precautions, including the following: 1. This appliance is not to be used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a...
  • Page 7 6. For appliances with ventilation openings in the base, a carpet must not obstruct the openings. 7. For use in Europe: Children of less than 3 years should be kept away unless continuously supervised. 8. CAUTION: In order to avoid a hazard due to inadvertent resetting of the thermal cut-out, this appliance must not be supplied through an external switching device, such as a timer, or connected to a...

  • Page 8: Instructions When Using Your Dishwasher

    Safety information Instructions when using your dishwasher This dishwasher is not designed for commercial use. It is intended for use in domestic households and in similar working and residential environments such as: • Shops • Offices and showrooms and by residents in establishments such as: •...

  • Page 9: Instructions For Protecting Your Children

    Knives and other utensils with sharp points must be loaded in the basket with their points down or placed in a horizontal position. Instructions for protecting your children This appliance is not a toy! To avoid the risk of injury, keep children well away and do not allow them to play in or around the dishwasher or to use the controls.

  • Page 10: Instructions For Installing Your Dishwasher

    Safety information Instructions for installing your dishwasher Before setting up the appliance, check it for any externally visible damage. Under no circumstances should you use a damaged appliance. A damaged appliance could be dangerous. The dishwasher must only be plugged into the electricity supply via a suitable switched socket.
  • Page 11 The plastic housing of the water connection contains an electrical component. The housing must not be submerged in water. There are electrical wires in the hose of Aqua-Stop. Never cut the water inlet hose, even if it is too long. Installation, maintenance and repairs may only be carried out by a suitably qualified and competent person in strict accordance with current national and local safety regulations.
  • Page 12 Make sure that your dishwasher’s hardness level setting is correct as your area. (Refer to the “Salt storage” section on page 46.) Please consult www.samsung.com/support for more information about materials and repair. English DW6500AM_DW60A6092FW_EU_DD81-04050B-01_EN.indd 12...

  • Page 13: Installation

    Make sure all the parts are included in the product package. If you have a question about the dishwasher or the parts, contact a local Samsung customer centre or your retailer. The actual appearance of the dishwasher may differ, depending on your model and country.
  • Page 14 Installation FBI (Sliding, DW60A60**IB) models Top bracket (2) Ø4 X 14 screw (14) Protective Plastic cap (2) condensation sticker (1) Custom panel fixer Ø3.5 X 16 screw (2) Sub foot (3) Custom panel fixer BU (Built Under, DW60A60**U*) models Top brackets (2) Ø4 X 14 screws (2) Sub foot (3) Ø3.5 X 16 screws...
  • Page 15 Installation kit (not provided) Hose clamp Tools required (not provided) Safety glasses Gloves Flashlight Wrench (22 mm) for the front foot Torx T15 Pliers Nipper Tape measure Pencil Phillips screwdriver Flat head Cutting knife screwdriver Level Hole saw Ear clamp plier (80-100 mm) English DW6500AM_DW60A6092FW_EU_DD81-04050B-01_EN.indd 15...

  • Page 16: Installation Requirements

    • Do not modify the power plug of the Then, contact a local Samsung customer dishwasher. If the power plug does centre or a qualified technician. not fit the outlet, have a proper outlet installed by a qualified electrician.
  • Page 17 Drain Ambient temperature If you are using a drain system dedicated Do not install the dishwasher in an area to the dishwasher, connect the drain hose exposed to freezing temperatures. The to a drain system that is between 30 cm dishwasher always retains some water in and 70 cm off the ground.

  • Page 18: Step-By-Step Installation

    Installation Step-by-step installation The installation procedure may differ depending on the model. STEP 1 Select a location Select a location that meets the following conditions. • The location must have a solid floor that can support the weight of the dishwasher. •...
  • Page 19 Cabinet dimensions 550 (Fully Built-in model) 570 (Built under, Semi Built in model) NOTE Check if the distance between the floor and the bottom of the worktop is more than 850 mm. If so, insert the sub foot included in the installation kit. For details, see the next section.
  • Page 20 Installation STEP 2 To insert the sub foot (Except Free Standing model) If the distance between the floor and the bottom of the worktop is more than 850 mm, insert the sub foot into the hole on the bottom of the dishwasher before you start the installation.
  • Page 21 STEP 4 Arrange the hoses 1. Clean the bottom of the countertop. 2. Attach the protective condensation sticker as shown. 3. Pull the power plug, the water hose, and the drain hose through the sink hole. CAUTION • Use caution not to kink or step on the power plug or the hoses.
  • Page 22 Installation STEP 5 Install the custom panel (For Fully Built-In models) FBI (Fully Built-In, DW60A60**BB) models 1. Place the installation template on the back of the custom panel and fix it Ø2 temporarily using transparent tape. Note that the rear of the custom panel will be attached to the dishwasher door.
  • Page 23 4. Tighten the door bracket (C) with 8 screws (D, Ø4 X 14) as shown in the figure. 5. Insert the door brackets (C) on the custom panel to the holes (E) on the dishwasher door to fix the custom panel. 6.
  • Page 24 Installation 9. Open the dishwasher door and remove the 4 screws. CAUTION Use caution when opening the door. The door might open or close unexpectedly if the spring level is not adjusted appropriately, resulting in physical injury. 10. Secure the custom panel to the door by fastening the 4 screws (3.5 X 45).
  • Page 25 FBI (FBI Sliding, DW60A60**IB) models This dishwasher model is equipped with an auto-balancing system in the door. It has a sliding hinge, which is perfect for plinth-less kitchens or for installation above a small cupboard. Custom panel’s height (A) can be between minimum 670 mm to maximum 800 mm depending on the installation environment.
  • Page 26 Installation 3. Remove the installation template, and then tighten the Custom panel fixers (B), (C) with 12 screws (A) as shown in the figure. 4. While holding the custom panel, attach it to the door and insert the Custom panel fixers into the corresponding holes at the door.
  • Page 27 STEP 6 Level the dishwasher You can adjust the height of the dishwasher to level it. Note that in these steps, the dishwasher is currently inserted halfway. 1. Use the level to check if the dishwasher is level. 2. To adjust the front height, use a flat head(-) screwdriver.
  • Page 28 Installation 4. Leave at least a 5 mm space between the top of the dishwasher and the bottom of the countertop. Min. (5 mm) 5. When levelling is complete, check if the door opens and closes properly. English DW6500AM_DW60A6092FW_EU_DD81-04050B-01_EN.indd 28 2021-09-30 12:36:18...
  • Page 29 STEP 7 Secure the dishwasher You can use the brackets to secure the dishwasher to the countertop. Alternatively, you can drill the side holes to secure the dishwasher to the cabinet sides. To the countertop using the brackets 1. Insert the provided brackets into the top front holes of the dishwasher as shown.
  • Page 30 Installation To the sides CAUTION If the plastic caps are not assembled, water may leak and cause a fire or electric shock. 1. Remove the plastic caps. 2. Tighten the 2 screws (Ø3.5 X 16) to the 2 places (marked on the illustration). 3.
  • Page 31 STEP 8 Connect the drain hose 1. Connect the drain hose to the drain outlet. CAUTION • Install the drain system properly so that the drain hose does not come out of the drain outlet in the draining process. • Make sure that the drain hose, supply hose, and power cord is not kinked or folded.

  • Page 32: Skirting Board

    Installation Skirting board You can attach the skirting board according to the model or installation conditions. Skirting board 1. Put the skirting board on the bottom of the dishwasher. 2. Open the door of the dishwasher, and draw a baseline on the skirting board where it interferes with the door.
  • Page 33 Pre-cut skirting board (DW60A60**U* Series) 1. Insert the provided brackets to the bottom of the dishwasher. Turn them into position. • See the figure on the left for the correct attaching sequence and place of the brackets. 2. Insert the pre-cut skirting board into the brackets first, and then tighten the screws to fix the board.

  • Page 34: Kick Plate (Dw60A60**U* Series)

    Installation Kick plate (DW60A60**U* Series) If you want to install the kick plate, follow these steps. 1. Insert the provided brackets to the bottom of the dishwasher. Turn them into position. • See the figure on the left for the correct attaching sequence and place of the brackets.

  • Page 35: Before You Start

    Before you start Follow these instructions carefully to ensure proper installation of the dishwasher and to prevent accidents when washing dishes. Dishwasher at a glance DW60A609* models 9 0 8 01 Cutlery rack 02 Upper rack 03 Salt storage 04 Lower rack 05 Dispenser 06 Glass support 07 Door...
  • Page 36 Before you start DW60A608* models 9 0 8 01 Knife rack 02 Upper rack 03 Salt storage 04 Lower rack 05 Dispenser 06 Cutlery basket 07 Door 08 Base 09 Inlet hose 10 Drain hose 11 Glass support English DW6500AM_DW60A6092FW_EU_DD81-04050B-01_EN.indd 36 2021-09-30 12:36:22...

  • Page 37: Unsuitable Items For The Dishwasher

    CAUTION • Do not wash items that are covered with ash, sand, wax, lubricating grease, or paint. These materials will damage the dishwasher. Ash does not dissolve and will spread inside the dishwasher. • Remove food remains such as bones, fruit seeds, etc. and waste such as toothpicks, paper napkins, etc.

  • Page 38: Basic Use Of Racks

    Before you start Basic use of racks Height adjustment You can adjust the height of the upper rack so that the lower rack can accommodate larger sized dishes. Depending on the height of the upper rack, the lower rack can accommodate plates up to 30 cm in diameter, and the upper rack can accommodate plates up to 18 cm (with Cutlery rack) or 25 cm (without Cutlery rack) in diameter.
  • Page 39 Loading dishes Lower rack We recommend that you place large items, that are difficult to clean (such as pots, pans, lids, serving dishes and bowls), in to the lower rack. It is preferable to place serving dishes and lids on the side of the racks in order to avoid blocking the rotation of the upper nozzle.
  • Page 40 Before you start Using the folding tines For better stacking of pots and pans, the tines can be folded down as show in the figure. Upper rack The upper rack is designed to hold more delicate and lighter dishware such as glasses, coffee and tea cups and saucers, as well as plates, small bowls and shallow pans (as long as they are not too dirty).
  • Page 41 Guide Tines You can load dishes into the central rack in various ways by changing the guide tines. If the guide button is moved to the left, you can load standard wine glasses. If the guide button is in the middle, you can load shorter wine or brandy glasses.
  • Page 42 Before you start Rack Tray You can easily unload cutlery from a removable tray in the upper rack. You can also remove the left or right tray to load relatively larger utensils. Both trays are removable. Cutlery rack Using the glass support The glass support is especially suited for wine glasses.

  • Page 43: Detergent Compartment

    Detergent compartment All dishwasher cycles require detergent in the detergent compartment. Apply detergent as recommended for the selected cycle to ensure best performance. WARNING • Do not place dishwasher detergent in your mouth. Avoid breathing in detergent fumes. Dishwasher detergent contains irritants and caustic chemicals that can induce respiratory conditions.
  • Page 44 Before you start 2. Add the recommended amount of detergent to the main wash detergent compartment. 3. Close the lid by sliding it up. 4. If the items are heavily soiled, pour a small amount of detergent onto the door for better cleaning results.

  • Page 45: Rinse Aid Reservoir

    Rinse aid reservoir Rinse aid improves the drying performance of the dishwasher. When the Rinse Refill indicator lights up on the control panel, refill with rinse aid. Only use liquid rinse aid. Powdered rinse aid will clog the reservoir opening and cause the dishwasher to malfunction.

  • Page 46: Salt Storage

    Before you start Salt storage CAUTION • Use dishwasher-specific salt only. Do not use any other type of salt or solvent. This may damage the salt storage and the water softening system. • To prevent corrosion due to an excessive amount of salt or salty water, always fill the salt storage before a washing cycle gets started.

  • Page 47: Touchpad Responsiveness

    Salt indicator The indicator ( ) turns on if there is not enough salt for the next several cycles. Touchpad responsiveness To prevent the touch-enabled controls from losing responsiveness, follow these instructions. • Touch the centre of each button with one finger.

  • Page 48: Setting Mode

    Before you start Setting mode You can change the sound, auto door open function, rinse aid level, and water hardness settings to your preference. Entering the Setting mode 1. Turn the dishwasher on. 2. Press and hold the AUTO (DW60A60**BB, DW60A60**IB model) or Program (DW60A60**F*, DW60A60**U* model) cycle button for five seconds within 60 seconds from turning on the dishwasher.
  • Page 49 Rinse aid level setting You can change the amount of rinse aid applied during a cycle. 1. Press the Delay Start button to select the rinse aid level setting menu. - The display shows the current setting. (Default setting: “F4”) 2.

  • Page 50: Operations

    Operations Control panel DW60A609*BB, DW60A608*BB, DW60A609*IB, DW60A608*IB models DW60A609*F*, DW60A608*F*, DW60A609*U*, DW60A608*U* models 01 POWER Press to turn the dishwasher on or off. Press to select a desired wash cycle. For more information, 02 Program see the “Cycle overview” section on page 52. 03 Upper rack only Press to wash items using only the upper rack.
  • Page 51 You can delay the cycle starting time up to 24 hours. For 08 Delay Start more information, see the “Delay Start” section on page 56. Press START to start operation. Make sure the door is closed. 09 START Cancel & Drain: To cancel the current cycle and drain the (Cancel &...

  • Page 52: Cycle Overview

    Operations Cycle overview This cycle detects the level of soil and automatically initiates 01 AUTO the optimal cycle, which is appropriate for all levels of soiled items. This cycle reduces power and water consumption, which is 02 ECO * appropriate for normally soiled items. 03 Intensive Select this cycle for heavily soiled items.

  • Page 53: Simple Steps To Start

    Simple steps to start 1. Open the door, and then load the dishwasher. Make sure to remove food remains and waste on the dishes. 2. Apply detergent to the detergent dispenser. For better results, add rinse aids. 3. Press POWER, and then select a cycle with necessary options (Upper rack only, Lower rack only, Sanitize, Multi tab, and Delay Start).

  • Page 54: Salt Storage

    Operations Salt storage The water softener is designed to remove minerals and salts from the water, which would have a detrimental or adverse effect on the operation of the appliance. We recommend using soft water for better results. Hard water contains impurities that can reduce the washing performance.
  • Page 55 Water Salt Water hardness Autonomy hardness consumption (cycles/1 kgs) °dH °fH °Clark mmol/l setting (gram/cycle) 0-0.94 6-11 10-20 7-14 1.0-2.0 12-17 21-30 15-21 2.1-3.0 18-22 31-40 22-28 3.1-4.0 23-34 41-60 29-42 4.1-6.0 35-55 61-98 43-69 6.1-9.8 NOTE • 1 dH (German degree) = 0.178 mmol/l •...

  • Page 56: Delay Start

    Operations Delay Start You can delay the cycle starting time up to 24 hours in 1-hour increments. To increase the delay time, press Delay Start. The hour displayed indicates the time at which the cycle will start. 1. Open the door, and then load the dishwasher. 2.

  • Page 57: Maintenance

    Maintenance Cleaning Keep the dishwasher clean to improve performance, reduce unnecessary repairs, and lengthen the lifecycle. Exterior Clean spills on the surface of the dishwasher immediately. Use a soft, damp cloth on the control panel to gently wipe away spills and dust. CAUTION •...
  • Page 58 Maintenance Nozzles To prevent the nozzles from being clogged or if the nozzles are clogged, remove and clean each nozzle. Use caution when removing the nozzles as they may break. Upper nozzle 1. Open the door, and then pull out the upper rack to reveal the upper nozzle.
  • Page 59 Filter We recommend cleaning the filter every month. 1. Open the door, and then remove the lower rack first. 2. Turn the filter handle counterclockwise to unlock the Coarse filter. 3. Remove the Coarse filter, and then the cylindrical micro filter underneath. English DW6500AM_DW60A6092FW_EU_DD81-04050B-01_EN.indd 59 2021-09-30...

  • Page 60: Long-Term Care

    Maintenance 4. Remove any dirt and impurities from the micro filter and the Coarse filter. 5. Rinse them with running water, and then dry well. 6. Reinsert the filter, and then the Coarse filter. 7. Turn the filter handle clockwise to lock. CAUTION Make sure the Coarse filter is closed properly.

  • Page 61: Troubleshooting

    Following the repair by a non-authorised service provider, self-repair or non-professional repair of the product, Samsung is not liable for any damage to the product, any injury or any other product safety issue caused by any attempt to repair the product which does not carefully follow these repair and maintenance instructions.
  • Page 62 Troubleshooting Symptom Possible cause Action • Select a cycle according to An incorrect cycle was the soil level of the dishes selected. as instructed in this manual. • Clean the filters. The filters are clogged or not • Make sure the filters are correctly fastened.
  • Page 63 Symptom Possible cause Action The dishwasher makes a sound when the dispenser cover is • This is normal. open and the drain pump is operating. The dishwasher is • Make sure the dishwasher too noisy. The dishwasher is not level. is level.

  • Page 64: Information Codes

    * Applicable parts : door hinge and seals, other seals, spray arms, drain filters, interior racks and plastic peripherals such as baskets and lids. ** This means a minimum of 10 years after Samsung places the last unit of the model on the market.

  • Page 65: Cycle Chart

    Cycle chart Cycle AUTO Intensive Pre wash (45 °C)  Pre wash (50 °C)  Main wash (55 °C- Main wash (50 °C)  Main wash (65 °C)  65 °C)  Rinse  Rinse  Rinse  Rinse  Cycle sequence Rinse ...
  • Page 66 Cycle chart NOTE • The cycle time depends on the options you have added, and the pressure and temperature of the supplied water. • The dishwasher drains the remaining water inside automatically if it has not been used for the last 5 days. •...

  • Page 67: Appendix

    Appendix Transportation/relocation Make sure the dishwasher is empty with no loose parts. First, drain the dishwasher as follows. 1. When the draining process is complete, open the door. 2. Turn the dishwasher off, and then shut the water valve off. 3.

  • Page 68: Energy, Water Saving Tip

    • Use an appropriate amount of detergent and rinse according to the manufacturer’s guidelines. • Dishwasher use saves water compared to ordinary washing by hand. • Ecodesign information can be found by going to www.samsung.com/support. EPREL information To access energy labelling information about this product on the European Product Registry for Energy Labelling (EPREL), go to https://eprel.ec.europa.eu/qr/******...

  • Page 69: Specifications

    Specifications DW60A6090F* DW60A6090U* DW60A6090BB DW60A6090IB DW60A6092F* DW60A6092U* DW60A6092BB DW60A6092IB MODEL DW60A6080F* DW60A6080U* DW60A6080BB DW60A6080IB DW60A6082F* DW60A6082U* DW60A6082BB DW60A6082IB Fully Built-in Type Free Standing Built Under Fully Built-in (Sliding) Power 220-240 V ~ , 50 Hz Water pressure 0.04-1.0 MPa DW60A609* 14 Place settings Wash capacity...

  • Page 70: For Standard Test

    For standard test NOTE The information for comparability test as follows. DW60A609* models • Washing capacity: 14 place settings • Test standard: EN 60436 • Position of upper rack: lower position • Wash cycle: ECO • Additional options: None • Rinse aid level setting: F4 •...
  • Page 71 DW60A608* models • Washing capacity: 13 place settings • Test standard: EN 60436 • Position of upper rack: lower position • Wash cycle: ECO • Additional options: None • Rinse aid level setting: F4 • Water hardness level setting: H3 •...
  • Page 72 06196 77 555 77 www.samsung.com/de/support ITALIA 800-SAMSUNG (800.7267864) www.samsung.com/it/support CYPRUS 8009 4000 only from landline, toll free www.samsung.com/gr/support 80111-SAMSUNG (80111 726 7864) only from GREECE land line www.samsung.com/gr/support (+30) 210 6897691 from mobile and land line 261 03 710 www.samsung.com/be_fr/support LUXEMBURG...
