Contents Safety information What you need to know about safety instructions Important safety symbols Instructions about the WEEE Important safety precautions Instructions when using your dishwasher Instructions for protecting your children Instructions for installing your dishwasher Installation What’s included Installation requirements Step-by-step installation Skirting board Info Light...
Page 3
Troubleshooting Checkpoints Information codes Cycle chart Appendix Transportation/relocation Protection against frost Disposing the dishwasher and helping the environment For more ecodesign information Specifications For standard test English DW8500AM_DW60A8070BB_EU_DD81-03206B-01_EN.indd 3 DW8500AM_DW60A8070BB_EU_DD81-03206B-01_EN.indd 3 2021-03-24 2021-03-24 1:25:19 1:25:19...
If you have any questions or concerns, contact your nearest service center or find help and information online at www.samsung.com. Important safety symbols...
This product and its electronic accessories should not be mixed with other commercial wastes for disposal. For information on Samsung’s environmental commitments and product specific regulatory obligations e.g. REACH, WEEE, Batteries, visit our sustainability page available via Samsung.com English DW8500AM_DW60A8070BB_EU_DD81-03206B-01_EN.indd 5...
Safety information Important safety precautions To reduce the risk of fire, electric shock, or injury to persons when using your appliance, follow basic precautions, including the following: 1. This appliance is not to be used by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a...
Page 7
6. For appliances with ventilation openings in the base, a carpet must not obstruct the openings. 7. Children of less than 3 years should be kept away unless continuously supervised. 8. CAUTION: In order to avoid a hazard due to inadvertent resetting of the thermal cut-out, this appliance must not be supplied through an external switching device, such as a timer, or connected to a...
Safety information Instructions when using your dishwasher This dishwasher is not designed for commercial use. It is intended for use in domestic households and in similar working and residential environments such as: • Shops • Offices and showrooms and by residents in establishments such as: •...
Knives and other utensils with sharp points must be loaded in the basket with their points down or placed in a horizontal position. Instructions for protecting your children This appliance is not a toy! To avoid the risk of injury, keep children well away and do not allow them to play in or around the dishwasher or to use the controls.
Safety information Instructions for installing your dishwasher Before setting up the appliance, check it for any externally visible damage. Under no circumstances should you use a damaged appliance. A damaged appliance could be dangerous. The dishwasher must only be plugged into the electricity supply via a suitable switched socket.
Page 11
The plastic housing of the water connection contains an electrical component. The housing must not be submerged in water. There are electrical wires in the hose of Aqua-Stop. Never cut the water inlet hose, even if it is too long. Installation, maintenance and repairs may only be carried out by a suitably qualified and competent person in strict accordance with current national and local safety regulations.
Page 12
Make sure that your dishwasher’s hardness level setting is correct as your area. (Refer to the “Salt storage” section on page 53.) Please consult www.samsung.com/support for more information about materials and repair. English DW8500AM_DW60A8070BB_EU_DD81-03206B-01_EN.indd 12...
Make sure all the parts are included in the product package. If you have a question about the dishwasher or the parts, contact a local Samsung customer centre or your retailer. The actual appearance of the dishwasher may differ, depending on your model and country.
Page 14
Installation FBI (Sliding, DW60A80**IB) models Top bracket (2) Ø4 X 14 screw (14) Protective Plastic cap (2) condensation sticker (1) Custom panel fixer Ø3.5 X 16 screw (2) Sub foot (3) Custom panel fixer Ø3.9 X 13 screw (4) Upper side trim (1) BU (Built Under, DW60A80**U*) models Top brackets (2) Ø4 X 14 screws (2)
Page 15
Installation kit (not provided) Hose clamp Tools required (not provided) Safety glasses Gloves Flashlight Wrench (22 mm) for the front foot Torx T15 Pliers Nipper Tape measure Pencil Phillips screwdriver Flat head Cutting knife screwdriver Level Hole saw Ear clamp plier (80-100 mm) English DW8500AM_DW60A8070BB_EU_DD81-03206B-01_EN.indd 15...
• Do not modify the power plug of the Then, contact a local Samsung customer dishwasher. If the power plug does centre or a qualified technician. not fit the outlet, have a proper outlet installed by a qualified electrician.
Page 17
Drain Ambient temperature If you are using a drain system dedicated Do not install the dishwasher in an area to the dishwasher, connect the drain hose exposed to freezing temperatures. The to a drain system that is between 30 cm dishwasher always retains some water in and 70 cm off the ground.
Installation Step-by-step installation The installation procedure may differ depending on the model. STEP 1 Select a location Select a location that meets the following conditions. • The location must have a solid floor that can support the weight of the dishwasher. •...
Page 19
Cabinet dimensions 550 (Fully Built-in model) NOTE Check if the distance between the floor and the bottom of the worktop is more than 850 mm. If so, insert the sub foot included in the installation kit. For details, see the next section.
Page 20
Installation STEP 2 To insert the sub foot (Except Free Standing model) If the distance between the floor and the bottom of the worktop is more than 850 mm, insert the sub foot into the hole on the bottom of the dishwasher before you start the installation.
Page 21
STEP 4 Arrange the hoses 1. Clean the bottom of the countertop. 2. Attach the protective sticker as shown. 3. Pull the power plug, the water hose, and the drain hose through the sink hole. CAUTION • Use caution not to kink or step on the power plug or the hoses.
Page 22
Installation STEP 5 Install the custom panel (For Fully Built-In models) FBI (Fully Built-In, DW60A80**BB) models 1. Put the installation template on the back of the custom panel and fix it Ø2 temporarily using transparent tape. Note that the rear of the custom panel will be attached to the dishwasher door.
Page 23
4. Tighten the door bracket (C) with 8 screws (D, Ø4 X 14) as shown in the figure. 5. Insert the door brackets (C) on the custom panel to the holes (E) on the dishwasher door to fix the custom panel. 6.
Page 24
Installation 9. Open the dishwasher door and remove the 4 screws. CAUTION Use caution when opening the door. The door might open or close unexpectedly if the spring level is not adjusted appropriately, resulting in physical injury. 10. Secure the custom panel to the door by fastening the 4 screws (3.5 X 45).
Page 25
FBI (FBI Sliding, DW60A80**IB) models This dishwasher model is equipped with an auto-balancing system in the door. It has a sliding hinge, which is perfect for plinth-less kitchens or for installation above a small cupboard. Custom panel’s height (A) can be between minimum 670 mm to maximum 800 mm depending on the installation environment.
Page 26
Installation 3. Remove the installation template, and then tighten the Custom panel fixers (B), (C) with 12 screws (A) as shown in the figure. 4. While holding the custom panel, attach it to the door and insert the Custom panel fixers into the corresponding holes at the door.
Page 27
STEP 6 Install the trim You can use the trim to reduce the noise level. 1. To install the upper side trim, remove the protective vinyl of double-side adhesive tape on the back of the trim. 2. Insert the Hook shape of the trim to the rear side of tub top bracket.
Page 28
Installation STEP 7 Level the dishwasher You can adjust the height of the dishwasher to level it. Note that in these steps, the dishwasher is currently inserted halfway. 1. Use the level to check if the dishwasher is level. 2. To adjust the front height, use a flat head(-) screwdriver.
Page 29
4. Leave at least a 5 mm space between the top of the dishwasher and the bottom of the countertop. Min. (5 mm) 5. When levelling is complete, check if the door opens and closes properly. English DW8500AM_DW60A8070BB_EU_DD81-03206B-01_EN.indd 29 DW8500AM_DW60A8070BB_EU_DD81-03206B-01_EN.indd 29 2021-03-24 2021-03-24 1:25:26...
Page 30
Installation STEP 8 Secure the dishwasher You can use the brackets to secure the dishwasher to the countertop. Alternatively, you can drill the side holes to secure the dishwasher to the cabinet sides. To the countertop using the brackets 1. Insert the provided brackets into the top front holes of the dishwasher as shown.
Page 31
To the sides CAUTION If the plastic caps are not assembled, water may leak and cause a fire or electric shock. 1. Remove the plastic caps. 2. Tighten the 2 screws (Ø3.5 X 16) to the 2 places (marked on the illustration). 3.
Page 32
Installation STEP 9 Connect the drain hose 1. Connect the drain hose to the drain outlet. CAUTION • Install the drain system properly so that the drain hose does not come out of the drain outlet in the draining process. •...
Skirting board You can attach the skirting board according to the model or installation conditions. Skirting board 1. Put the skirting board on the bottom of the dishwasher. 2. Open the door of the dishwasher, and draw a baseline on the skirting board where it interferes with the door.
Page 34
Installation Pre-cut skirting board (DW60A80**U* Series) 1. Insert the provided brackets to the bottom of the dishwasher. Turn them into position. • See the figure on the left for the correct attaching sequence and place of the brackets. 2. Insert the pre-cut skirting board into the brackets first, and then tighten the screws to fix the board.
Info Light You can see the dishwasher’s operating status by checking the info light. Info Light When the dishwasher has operated, the info light is on and shining toward the floor. This tells you the dishwasher’s operating status. NOTE Check whether the info light is covered by the rubber skirt.
Installation Kick plate (DW60A80**U* Series) If you want to install the kick plate, follow these steps. 1. Insert the provided brackets to the bottom of the dishwasher. Turn them into position. • See the figure on the left for the correct attaching sequence and place of the brackets.
On your smartphone, go to Settings and connect to your home Wi-Fi network. Download On an app market (Google Play Store, Apple App Store, Samsung Galaxy Apps), find the SmartThings app with a search term of “SmartThings”. Download and install the app on your device.
Page 38
• If your Internet provider has registered the MAC address of your PC or the modem module for permanent use, your Samsung dishwasher fails to connect to the Internet. If this is the case, contact your Internet provider. • The Internet firewall may interrupt your Internet connection. If this happens, contact your Internet provider.
Page 39
• Hereby, Samsung Electronics, declares that the radio equipment type appliance is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: The official Declaration of conformity may be found at http://www.samsung.com, go to Support > Search Product Support and enter the model name.
Page 40
Installation 1. How to access: press and hold the Start button in AP mode. (To enter the AP mode, press and hold the Smart Control button for 3 seconds.) 2. Display format - After receiving WSN data from WiFi module, “-” + first 2 digits are diplayed and next 3 digits are diplayed by every “start”...
Open Source Announcement The software included in this product contains open source software. The following URL http://opensource.samsung.com/opensource/SMART_TP2_0/seq/0 leads to open source license information as related to this product. English DW8500AM_DW60A8070BB_EU_DD81-03206B-01_EN.indd 41 DW8500AM_DW60A8070BB_EU_DD81-03206B-01_EN.indd 41 2021-03-24 2021-03-24 1:25:28 1:25:28...
Before you start Follow these instructions carefully to ensure proper installation of the dishwasher and to prevent accidents when washing dishes. Dishwasher at a glance DW60A807*/DW60A806*/DW60A805* models 9 0 8 01 Cutlery rack 02 Upper rack 03 Salt storage 04 Lower rack 05 Dispenser 06 Glass support 07 Door...
Page 43
DW60A804* models 9 0 8 01 Knife rack 02 Upper rack 03 Salt storage 04 Lower rack 05 Dispenser 06 Cutlery basket 07 Door 08 Base 09 Inlet hose 10 Drain hose 11 Glass support English DW8500AM_DW60A8070BB_EU_DD81-03206B-01_EN.indd 43 DW8500AM_DW60A8070BB_EU_DD81-03206B-01_EN.indd 43 2021-03-24 2021-03-24 1:25:32...
Before you start CAUTION • Do not wash items that are covered with ash, sand, wax, lubricating grease, or paint. These materials will damage the dishwasher. Ash does not dissolve and will spread inside the dishwasher. • Remove food remains such as bones, fruit seeds, etc. and waste such as toothpicks, paper napkins, etc.
Basic use of racks Height adjustment You can adjust the height of the upper rack so that the lower rack can accommodate larger sized dishes. Depending on the height of the upper rack, the lower rack can accommodate plates up to 30 cm in diameter, and the upper rack can accommodate plates up to 18 cm (with Cutlery rack) or 25 cm (without Cutlery rack) in diameter.
Page 46
Before you start Loading dishes Lower rack We recommend that you place large items, that are difficult to clean (such as pots, pans, lids, serving dishes and bowls), in to the lower rack. It is preferable to place serving dishes and lids on the side of the racks in order to avoid blocking the rotation of the upper nozzle.
Page 47
Using the folding tines For better stacking of pots and pans, the tines can be folded down as show in the figure. Upper rack The upper rack is designed to hold more delicate and lighter dishware such as glasses, coffee and tea cups and saucers, as well as plates, small bowls and shallow pans (as long as they are not too dirty).
Page 48
Before you start Guide Tines You can load dishes into the central rack in various ways by changing the guide tines. If the guide button is moved to the left, you can load standard wine glasses. If the guide button is in the middle, you can load shorter wine or brandy glasses.
Page 49
Rack Tray You can easily unload cutlery from a removable tray in the upper rack. You can also remove the left or right tray to load relatively larger utensils. Both trays are removable. Cutlery rack Using the glass support The glass support is especially suited for wine glasses.
Before you start Detergent compartment All dishwasher cycles require detergent in the detergent compartment. Apply detergent as recommended for the selected cycle to ensure best performance. WARNING • Do not place dishwasher detergent in your mouth. Avoid breathing in detergent fumes.
Page 51
3. Close the lid by sliding it up. 4. If the items are heavily soiled, pour a small amount of detergent onto the door for better cleaning results. NOTE The additional detergent will activate during the pre-wash process. The cover opens automatically to dispense the detergent during the wash. English DW8500AM_DW60A8070BB_EU_DD81-03206B-01_EN.indd 51 DW8500AM_DW60A8070BB_EU_DD81-03206B-01_EN.indd 51...
Before you start Rinse aid reservoir Rinse aid improves the drying performance of the dishwasher. When the Rinse Refill indicator lights up on the control panel, refill with rinse aid. Only use liquid rinse aid. Powdered rinse aid will clog the reservoir opening and cause the dishwasher to malfunction.
Salt storage CAUTION • Use dishwasher-specific salt only. Do not use any other type of salt or solvent. This may damage the salt storage and the water softening system. • To prevent corrosion due to an excessive amount of salt or salty water, always fill the salt storage before a washing cycle gets started.
Before you start Salt indicator The indicator ( ) turns on if there is not enough salt for the next several cycles. Touchpad responsiveness To prevent the touch-enabled controls from losing responsiveness, follow these instructions. • Touch the centre of each button with one finger.
Setting mode You can change the sound, auto door open function, rinse aid level, and water hardness settings to your preference. Entering the Setting mode 1. Turn the dishwasher on. 2. Press and hold the AUTO cycle button for five seconds within 60 seconds from turning on the dishwasher.
Page 56
Before you start Rinse aid level setting You can change the amount of rinse aid applied during a cycle. 1. To select the rinse aid level setting menu. Select the “AUTO” key for 5 seconds, after the beep followed by the reset of the “0:00” display, press the “Sanitize” key. - The display shows the current setting.
Operations Control panel DW60A807*/DW60A806*/DW60A805* models DW60A804* models 01 POWER Press to turn the dishwasher on or off. Press to select a desired wash cycle. For more information, 02 Cycle see the “Cycle overview” section on page 59. 03 Lower rack only Press to wash items using only the lower rack.
Page 58
Operations Indicators DW60A807*/DW60A806*/DW60A805* models DW60A804* models No Salt indicator Lights up when the salt storage runs out of salt. Rinse Refill indicator Lights up when the dishwasher runs out of rinse aid. Control Lock indicator (DW60A807*/ Lights up if Control Lock is activated. DW60A806*/ DW60A805* models) Self Clean indicator...
Cycle overview DW60A807*/DW60A806*/DW60A805* models DW60A804* models This cycle detects the level of soil and automatically initiates 01 AUTO the optimal cycle, which is appropriate for all levels of soiled items. This cycle reduces power and water consumption, which is 02 ECO appropriate for normally soiled items.
Page 60
Operations Download Course (DW60A807*/DW60A806*/DW60A805* models) You can download and use courses other than those provided by default through your smartphone. 1. Press the POWER button. 2. Select Download Course. 3. Select the downloadable course you want to use in your smartphone app. Extra Silence, Pots and Pans, Plastic, and Baby Care courses are available.
Simple steps to start 1. Open the door, and then load the dishwasher. Make sure to remove food remains and waste on the dishes. 2. Apply detergent to the detergent dispenser. For better results, add rinse aids. 3. Press POWER, and then select a cycle with necessary options (Lower rack only, Speed Booster, Sanitize, and Delay Start).
Operations Salt storage The water softener is designed to remove minerals and salts from the water, which would have a detrimental or adverse effect on the operation of the appliance. The higher the content of these minerals and salts, the harder your water is. The softener should be adjusted according to the hardness of the water in your area.
Operations Delay Start You can delay the cycle starting time up to 24 hours in 1-hour increments. To increase the delay time, press Delay Start. The hour displayed indicates the time at which the cycle will start. 1. Open the door, and then load the dishwasher. 2.
Maintenance Cleaning Keep the dishwasher clean to improve performance, reduce unnecessary repairs, and lengthen the lifecycle. Exterior Clean spills on the surface of the dishwasher immediately. Use a soft, damp cloth on the control panel to gently wipe away spills and dust. CAUTION •...
Page 66
Maintenance Nozzles To prevent the nozzles from being clogged or if the nozzles are clogged, remove and clean each nozzle. Use caution when removing the nozzles as they may break. Upper nozzle 1. Open the door, and then pull out the upper rack to reveal the upper nozzle.
Page 67
Filter We recommend cleaning the filter every month. 1. Open the door, and then remove the lower rack first. 2. Turn the filter handle counterclockwise to unlock the Coarse filter. 3. Remove the Coarse filter, and then the cylindrical micro filter underneath. English DW8500AM_DW60A8070BB_EU_DD81-03206B-01_EN.indd 67 DW8500AM_DW60A8070BB_EU_DD81-03206B-01_EN.indd 67...
Maintenance 4. Remove any dirt and impurities from the micro filter and the Coarse filter. 5. Rinse them with running water, and then dry well. 6. Reinsert the filter, and then the Coarse filter. 7. Turn the filter handle clockwise to lock. CAUTION Make sure the Coarse filter is closed properly.
Troubleshooting Checkpoints If you encounter an issue with the dishwasher, first check the table below and try the suggestions. Symptom Possible cause Action • Make sure the door is latched and completely closed. The door is not completely • Make sure the upper rack closed.
Page 70
Troubleshooting Symptom Possible cause Action • Select a cycle according to An incorrect cycle was the soil level of the dishes selected. as instructed in this manual. • Clean the filters. The filters are clogged or not • Make sure the filters are correctly fastened.
Page 71
Symptom Possible cause Action The dishwasher makes a sound when the dispenser cover is • This is normal. open and the drain pump is operating. The dishwasher is • Make sure the dishwasher too noisy. The dishwasher is not level. is level.
Samsung service center. Check filter and drain pipe. If it is jammed, clean it. If the issue continues, contact a local Samsung service center. If any information code keeps appearing on the screen, contact a local Samsung service centre. English DW8500AM_DW60A8070BB_EU_DD81-03206B-01_EN.indd 72...
Remove the door so that animals and children cannot get trapped inside the appliance. For more ecodesign information Ecodesign inforamtion can be found by going to user manual at www.samsung.com/ support. English DW8500AM_DW60A8070BB_EU_DD81-03206B-01_EN.indd 77...
For standard test NOTE The information for comparability test as follows. DW60A807*/DW60A806*/DW60A805* models • Washing capacity: 14 place settings • Test standard: EN 60436 • Position of upper rack: lower position • Wash cycle: ECO • Additional options: None • Rinse aid level setting: F4 •...
Page 80
For standard test DW60A804* models • Washing capacity: 13 place settings • Test standard: EN 60436 • Position of upper rack: lower position • Wash cycle: ECO • Additional options: None • Rinse aid level setting: F4 • Water hardness level setting: H3 •...
