Summary of Contents for Allnet ALL168200
- Page 1 Powerline Network Powerline Network Instant Networks for Internet Access…and More! Solution for SOHO, S MALL FFICE AND FFICE QUICK SETUP GUIDE 200 Mbps ETHERNET BRIDGE ALL168200 © 2006. All rights reserved. Page 1 ALLNET GmbH, Maistraße 2, 82110 Germering www.allnet.de...
-
Page 2: Powerline Network
Powerline Network © 2006. All rights reserved. Page 2 ALLNET GmbH, Maistraße 2, 82110 Germering www.allnet.de... - Page 3 Powerline Network REFACE This document describes the installation of the Allnet 200 Mbps Powerline Ethernet Bridge ALL168200 Network products. Please read this document before installing the product. O THE NSTALLER This publication contains the following sections: Important safety instructions The first thing you need to know before you begin to install...
-
Page 4: Important Safety Instructions
If the product has been exposed to rain or water. If the product does not operate normally when the operating instructions are followed. If the product exhibits a distinct change in performance. © 2006. All rights reserved. Page 4 ALLNET GmbH, Maistraße 2, 82110 Germering www.allnet.de... - Page 5 Pentium® 166 MHz processor, equivalent or higher Resource on your PC At least one free Ethernet port for Ethernet bridge ALL168200 2. Your PC must not be configured for another network. This means that: No network clients except for Microsoft Network*, Client for Netware* Networks, or Microsoft Family...
- Page 6 To meet the safety regulation, the longest distance between powerline carrier devices will be limited at 100 meter and for in-house use only. Distance more than 100 meters will cause the signal reduction or data loss. © 2006. All rights reserved. Page 6 ALLNET GmbH, Maistraße 2, 82110 Germering www.allnet.de...
- Page 7 Plug the provided Ethernet cable into the RJ45 connector of the Bridge and plug the other end of the cable into the Ethernet port on the AP. © 2006. All rights reserved. Page 7 ALLNET GmbH, Maistraße 2, 82110 Germering www.allnet.de...
- Page 8 When you unplug and plug the Ethernet Bridge to the outlet, it will take 35 to 75 seconds to establish the connection every time. Before you connect any Ethernet Device to the Powerline Bridge, you need to confirm the Ethernet device is 10/100 Base-T compatible. © 2006. All rights reserved. Page 8 ALLNET GmbH, Maistraße 2, 82110 Germering www.allnet.de...
-
Page 9: Specification
On: Powerline adapter detected Off: No Powerline adapter detected Blinking: Powerline traffic detected ETHERNET LINK/ACT On: Ethernet device linked Off: No Ethernet device linked Blinking: Ethernet traffic detected © 2006. All rights reserved. Page 9 ALLNET GmbH, Maistraße 2, 82110 Germering www.allnet.de...
