Allnet ALL-MC116SV-VDSL2 User Manual

Vdsl2 sllave briidge wiith 2 giigabiit lan ports + sfp

Advertisement

Quick Links

A A
L L
L L
- -
M M
C C
A
L
L
-
M
C
V V
D D
S S
L L
2 2
S S
l l
a a
v v
e e
V
D
S
L
2
S
l
a
v
e
L L
A A
N N
L
A
N
U U
S S
E E
R R
U
S
E
R
1 1
1 1
6 6
S S
V V
- -
V V
D D
1
1
6
S
V
-
V
D
B B
r r
i i
d d
g g
e e
w w
i i
t t
h h
2 2
B
r
i
d
g
e
w
i
t
h
2
p p
o o
r r
t t
s s
+ +
S S
F F
P P
p
o
r
t
s
+
S
F
P
' '
'
S S
M M
A A
N N
U U
A A
S
M
A
N
U
A
S S
L L
2 2
S
L
2
G G
i i
g g
a a
b b
i i
t t
G
i
g
a
b
i
t
L L
L

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ALL-MC116SV-VDSL2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Allnet ALL-MC116SV-VDSL2

  • Page 1 ’ ’ ’...
  • Page 2: Copyright

    In the interest of improving internal design, operational function, and/or reliability, ALLNET reserves the right to make changes to the products described in this document without notice. ALLNET does not assume any liability that may occur due to the use or application of the product(s) or circuit layout(s) described herein.
  • Page 3: Foreword

    fitness for a particular purpose. Make sure you follow in line with the environmental conditions to use this product. Foreword The ALL-MC116SV is a VDSL2 CPE(slave) bridge with 2 x 10/100/1000Base-T LAN ports solution and using G.993.2 VDSL2 standard technology for data transmission by a single copper wire pair.
  • Page 4: Safety Warnings

    Attention: Be sure to read this manual carefully before using this product. Especially Legal Disclaimer, Statement of Conditions and Safety Warnings. Caution: The ALL-MC116SV is for indoor applications only. This product does not have waterproof protection. Do not use in harsh environments (Over temperature range: 0°C ~ 50°C (32°F ~ 122°F)).
  • Page 5  DO NOT expose your device to dampness, dust or corrosive liquids.  DO NOT use this product near water, for example, in a wet basement or near a swimming pool.  Connect ONLY suitable accessories to the device. Make sure to connect the cables to the correct ports. ...
  • Page 6: Table Of Contents

    Table of Contents Copyright ................................1 Foreword ................................3 Safety Warnings ..............................4 Chapter 1. Unpacking Information ........................8 1.1 Check List ....................................8 Chapter 2. Installing the Device ......................... 9 2.1 Hardware Installation ................................9 2.2 Pre-installation Requirements ..............................9 2.3 General Rules ..................................10 2.4 Connecting the Ethernet of RJ-45 Ports ..........................
  • Page 7 2.7 Application Diagram ................................14 Chapter 3. Hardware Description........................16 3.1Front Panel: ....................................16 3.2 Rear Panel: ....................................18 3.3 LED Indicators ..................................19 Appendix A: Cable Requirements ........................20 Appendix B: Product Specifications ....................... 23 Appendix C: DIN-Rail mount installation ......................25...
  • Page 8: Chapter 1. Unpacking Information

    Chapter 1. Unpacking Information 1.1 Check List Carefully unpack the package and check its contents against the check list. Package Contents: 1 x ALL-MC116SV Accessory: 1 x Ethernet Cable, 4 x Rubber Feet, 1 x DC 12V Adapter 1 x SFP cover Notes: 1.
  • Page 9: Chapter 2. Installing The Device

    4. The power supply included in the package is commercial-grade. Do not use in industrial-grade applications. 5. Please look for the QR code on the bottom of the product, the user can launch the QR code scanning program to scan and download the user’s manual electronic format file. Above QR code icon is for reference. Chapter 2.
  • Page 10: General Rules

     Check if the network cables and connectors needed for installation are available.  Do not install phone lines strapped together with AC power lines, or telephone office line with voice signal.  Avoid installing this device with radio amplifying station nearby or transformer station nearby. 2.3 General Rules Before making any connections to the bridge, please note the following rules: ...
  • Page 11: Connecting The Ethernet Of Rj-45 Ports

    RJ-11 Pin out Assignments Pin# MNEMONIC FUNCTION Unused Unused Used Used Unused Unused  External Splitter installing ALL-MC116SV need install external splitter depend on PBX systems such as POTS/ISDN, when connecting with pone set and please make sure splitter which is compatible with local PBX system. 2.4 Connecting the Ethernet of RJ-45 Ports ALL-MC116SV has two Ethernet ports which support connection to Ethernet operation.
  • Page 12: Connecting The Sfp Slot

    2.5 Connecting the SFP Slot There are multiple types of SFP transceiver in market, please ensure the SFP transceiver is compatible to both side of device; otherwise, the connection can’t set up. 2.6 Connecting the Line of RJ-11 Port  The line port has 2 connectors: RJ-45 and terminal block.
  • Page 13  When inserting a RJ-11 plug, make sure the tab on the plug clicks into position to ensure that it is properly seated.  Do not plug a RJ-11 phone jack connector into the Ethernet port (RJ-45 port). This may damage the bridge. Instead, use only twisted-pair cables with RJ-45 connectors that conform to Ethernet standard.
  • Page 14: Application Diagram

    Notes: Be sure each twisted-pair cable (RJ-45 Ethernet cable) does not exceed 100 meters (333 feet). We advise using Category 5~7 UTP/STP cables for Cable Bridge or Bridge connections to avoid any confusion or inconvenience in the future when you attached to high bandwidth devices. Line port use AWG24 ~ 26 twisted pair phone wiring, we do not recommend 28 gauge or above.
  • Page 15 Figure 2.2 Application Diagram...
  • Page 16: Chapter 3. Hardware Description

    Chapter 3. Hardware Description This section describes the important parts of ALL-MC116SV. It features the front panel and rear panel. 3.1Front Panel: The front panel provides SFP Slot, RJ-45 Connector, RJ-11 connector and LED indicators of ALL-MC116SV. Front panel indicator: There are 7 LED indicators on front panel, the following Table shows the description. Figure 3.1 Front Panel...
  • Page 17 Tip: With only a glance of the front panel’s LED indicators, the converter status will be fully aware. Table 3-1 Description of the front interface Port Name Connector type Description E1 / E2 RJ-45 For connecting to a 10/100/1000-T Networking device. SFP slot For small form-factor pluggable transceiver.
  • Page 18: Rear Panel

    3.2 Rear Panel: Figure 3.2 Rear Panel...
  • Page 19: Led Indicators

    3.3 LED Indicators The ALL-MC116SV has 7 LED indicators. The following Table shows the description. (Table 3-3) Table 3-3 LED Indicators Description and Operation LEDs Color Status Description Power Good Green Power OFF Ethernet port on Link status ON (Steady) Green E1/E2 Blinking...
  • Page 20: Appendix A: Cable Requirements

    2. CO = Master / CPE =Slave. Appendix A: Cable Requirements A.1 Ethernet Cable A CAT 5~7 UTP (unshielded twisted pair) cable is typically used to connect the Ethernet device to the Modem. A: 10/100TX cable often consists of four pairs of wires, two of which are used for transmission. The connector at the end of the 10/100TX cable is referred to as a RJ-45 connector and it consists of eight pins.
  • Page 21 Unused BI_DD- Bi-directional pair D-...
  • Page 22 Figure A-2 Pin Assignments and Wiring for an RJ-45 Straight-Through Cable Figure A-3 Pin Assignments and Wiring for an RJ-45 Crossover Cable...
  • Page 23: Appendix B: Product Specifications

    Appendix B: Product Specifications Key Features and Benefits:  Comply with G993.2 VDSL2 standard  Comply with IEEE802.3/802,3u/802.3ab standards  Supports auto follow band profile.  Supports 1000 Base-X SFP slot.  Supports G.993.5 Vectoring.  Supports G.998.4 G.inp  Supports UPBO &...
  • Page 24 Specification: Item Description IEEE 802.3u / IEEE802.3ab / IEEE802.3z Protocol and Standards : Connector : 10/100/1000Base-T RJ-45*2 Interface : 1000Base-X SFP Slot*1 Comply with ITU-T G993.2/G993.5/G998.4 Connector : RJ-11/ Terminal block combo DMT Encoding / PTM Transmission VDSL2 Interface : On-board surge protector MTU : 2K LAN : Act / Link, Power...
  • Page 25: Appendix C: Din-Rail Mount Installation

    Dimensions : 95mm x 110mm x 27mm(3.74’’x.4.33’’x 1.06’’ ) Power Consumption : 3W Typical Appendix C: DIN-Rail mount installation This appendix describes how to install the DIN-Rail to the bridged. The accessory is optional. Please refer to install the DIN-RAIL as following step: Install the DIN-Rail mounting plate to the ALL-MC116SV.
  • Page 26 Figure C-1 Figure C-2 Figure C-3 Appendix D: Troubleshooting Diagnosing Bridge’s Indicators The Bridge can be easily monitored through its comprehensive panel indicators. These indicators assist in identifying problems the Media Converter may encounter. This section describes common problems you may encounter and possible solutions: 1.
  • Page 27 2. Symptom: Link indicator does not light up (green) after making a connection. Network interface (ex. a network adapter card on the attached device), network cable, or switch port Cause: is defective.  Verify if both of the ALL-MC116SV (all devices) and attached device are powered on. ...
  • Page 28 Transmission Mode The default of transmission mode for RJ-45 ports is 10/100/1000 Mbps Ethernet, SFP port is 1.25Gbps (1000Base-X), and for RJ-11 port is 100Mbps xDSL. Therefore, if the Link signal is disrupted (e.g. by unplugging the network cable and plugging it back in again, or by resetting the power), the port will try to re-establish connection with the attached device via auto-negotiation.
  • Page 30 This recycle logo Indicates that this product is capable of being recycled, not that the product has been recycled or will be accepted in all recycling collection systems. The RoHS directive aims to restrict certain dangerous substances commonly used in electronic and electronic equipment. This RoHS...
  • Page 31 compliant symbol indicate the component is tested for the presence of Lead (Pb), Cadmium (Cd), Mercury (Hg), Hexavalent chromium (Hex-Cr), Polybrominated biphenyls (PBB), and Polybrominated diphenyl ethers (PBDE). For Cadmium and Hexavalent chromium, there must be less than 0.01% of the substance by weight at raw homogeneous materials level. For Lead, PBB, and PBDE, there must be no more than 0.1% of the material, when calculated by weight at raw homogeneous materials.
  • Page 32      ...
