Page 1
2TR85CF ML-136983 4VK85DF ML-136939 3TR85CF ML-136983 4VK85CF ML-136940 4TR85CF ML-136990 For additional information on Vulcan-Hart or to locate an authorized parts and service provider in your area, visit our website at www.vulcanequipment.com VULCAN-HART 3600 NORTH POINT BLVD. DIVISION OF ITW FOOD EQUIPMENT GROUP, LLC BALTIMORE, MD 21222 WWW.VULCANEQUIPMENT.COM...
IN THE VICINITY OF THIS OR ANY OTHER APPLIANCE. Improper installation, adjustment, alteration, service or maintenance can cause property damage, injury or death. Read the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment. VULCAN-HART F-32971 Rev. M (June 2013)
REMOVING EXCESS DEBRIS FROM THE FILTER………….. FLUSH AND DISCARD…………………………………………….. 26 BOIL OUT BYPASS™…………………………………………….. THERMAL OVERLOAD PROTECTION RESET BUTTON…… MAINTENANCE………………………………………………………….. FLUE VENT INSPECTION……………………………………….. Service in the US and Canada…………………………………... Alarms and Error Messages…………………………………….. TROUBLESHOOTING…………………………………………………….. Troubleshooting Chart………………………………………………. 29 VULCAN-HART F-32971 Rev. M (June 2013)
Filter Pan Suction Tube Screen Assembly Complimentary Pack of Micro-Filtration Envelopes High temperature discard hose Manual, Quick Start Guide(s), and Warranty – Keep in safe place for future reference. VULCAN-HART F-32971 Rev. M (June 2013)
Do not permit fans to blow directly onto fryer. Keep the fryer area free and clear from combustibles. Avoid wall-type fans, which create cross-currents within a room. Avoid open windows next to sides or back. VULCAN-HART F-32971 Rev. M (June 2013)
The fryer must be restrained to prevent tipping and the splashing of hot liquid. The means of restraint may be the manner of installation, such as connection to a battery of appliances, installing the fryer in an alcove, or by separate means such as adequate ties. VULCAN-HART F-32971 Rev. M (June 2013)
National Electrical Code, ANSI/NFPA 70, or the Canadian Electrical Code, CSA C22.2, as applicable. Electrical diagram located on inside of door. VULCAN-HART F-32971 Rev. M (June 2013)
The installation shall be made with a connector that complies with the Standard for Connectors for Movable Gas Appliances, ANSI Z21.69, CAN/CGA- 6.16, and a quick-disconnect device that complies with the Standard for Quick- VULCAN-HART F-32971 Rev. M (June 2013)
Check the level of the fryer by placing a level on top of the fryer after gas connections have been made. Ensure that the fryer is level front-to-back and side-to-side in the final installed position. If using casters, lock the wheels after unit is level. VULCAN-HART F-32971 Rev. M (June 2013)
If the fryer shuts down due to overheating, DO NOT power up the fryer until the shortening temperature is below 300°F (149°C). If an overheating situation persists, contact your local Vulcan-Hart authorized service office. BEFORE FIRST USE Cleaning New units are wiped down at the factory to remove any visible signs of dirt, oil, grease, etc.
Replace shortening if it becomes poorly flavored. Keep equipment and surrounding clean. Use tank covers when not in use. (accessory). Set thermostat correctly. Remove excess moisture and particles from food products before placing on fryer. VULCAN-HART F-32971 Rev. M (June 2013) -11-...
For solid state digital and programmable computer controls the power burner will light automatically. The power burner will cycle on and off throughout the melt cycle and continue afterwards maintaining the set temperature. VULCAN-HART F-32971 Rev. M (June 2013) -12-...
Thoroughly drain the fryer. Refer to DRAINING THE FRYER. Clean the fryer according to CLEANING. Turn off the main gas shutoff valve. TURNING OFF THE FRYER 1. Press the power switch to the off position. VULCAN-HART F-32971 Rev. M (June 2013) -15-...
Allow solution to stand for a few minutes. 8. Drain the tank according to DRAINING THE TANK. Rinse thoroughly with clear, hot water. All traces of cleaner must be removed. Dry the tank thoroughly. VULCAN-HART F-32971 Rev. M (June 2013) -16-...
There is no need to tighten the band clamp with tools. EXTENDED SHUTDOWN Thoroughly drain the fryer. Refer to DRAINING THE FRYER. Clean the fryer according to CLEANING. Push Power switch to the off position Turn off the main gas shutoff valve. VULCAN-HART F-32971 Rev. M (June 2013) -17-...
Carefully line up the suction tube nozzle so that it mates with the oil receptacle block mounted on the frame of the fryer battery. Close the drawer. See Figures 1, 2 3 and 4 Suction Tube Filter Screen Filter Insert Knurled Bottom Fitting Fig. 1 VULCAN-HART F-32971 Rev. M (June 2013) -18-...
Page 19
Filter Screen Lays Flat On Bottom of Filter Pan Fig. 3 Micro-Filtration Fabric Envelope Assembly: Same Suction Tube Fabric Envelope Insert (Different from Screen Assembly) Fabric Envelope Closing Clip Same Knurled Knob Fig. 4 VULCAN-HART F-32971 Rev. M (June 2013) -19-...
Step 6 Reposition the filter tube into the provided clip. Align filter tube so that the end of the “S” Tube engages the Oil Receptacle fitting each time the drawer is opened and closed. VULCAN-HART F-32971 Rev. M (June 2013) -20-...
Please note the gas power burner will automatically turn off at this point. DRAINING will appear on the digital display for solid state digital (D) and DRAINING OIL will display on computer models (C). VULCAN-HART F-32971 Rev. M (June 2013) -21-...
Page 22
Once pressed, the gas power burner will ignite and begin heating the oil to desired temperature. 10. Press the START button for solid state knob control (A) and gas power burner with ignite and begin heating the oil. VULCAN-HART F-32971 Rev. M (June 2013) -22-...
6. Once the oil has been discarded completely and the filter pan is empty, press the filter button to turn off the Motor/ Pump. Then press the discard/flush switch off. VULCAN-HART F-32971 Rev. M (June 2013) -26-...
The arrow in Figure 7 shows the location of the reset button; located on the front of the motor / pump facing towards you. Hot oil and hot parts Fig 7. can cause burns. VULCAN-HART F-32971 Rev. M (June 2013) -27-...
When the fryer is cool, inspect annually. Check the flue and clear any obstructions. Service in the US and Canada Contact you local Vulcan-Hart Service office or address on the front of this manual. ALARMS AND ERROR MESSAGES NO OR LOW GAS SUPPLY – If no action is taken after 90 seconds, an alarm sounds continuously, the heat demand is disabled and any running cooking cycles are cancelled.
Filter screen is clogged and needs cleaning. Shortening is too thick / cold. Heat oil up to min. 300º F. Discard valve lever not fully engaged either for filtering or discarding. Thermal overload protection button tripped. VULCAN-HART F-32971 Rev. M (June 2013) -29-...
