- Page 1 MIG/MAG WELDING MACHINES ALF 182 BASIC aXe ALF 222 BASIC aXe INSTRUCTION MANUAL ALFA IN a.s. © www.alfain.eu ALF 182-222 BASIC aXe MANUAL EN 06...
-
Page 2: Table Of Contents
ACCESSORIES ..................... 9 DESCRIPTION OF THE APPLIANCE ............... 10 GETTING STARTED ..................13 WELDING ....................16 ROUTINE MAINTENANCE & INSPECTION ............ 21 10. STATEMENT OF WARRANTY ..............21 11. DISPOSAL ....................22 12. WARRANTY LIST ..................23 ALFA IN a.s. © www.alfain.eu... -
Page 3: Introduction
We reserve the law of adjustments and changes in case of printing errors, change of technical paramaters, accessories etc. without previous notice. These changes may not be reflected in the manuals for use in paper or electronic form. ALFA IN a.s. © www.alfain.eu... -
Page 4: Safety Instructions And Warnings
The kinds of fumes and gases from the plasma arc depend on the kind of metal being used, coatings on the metal, and the different processes. You must be very careful when welding any metals which may contain one or more of the following: ALFA IN a.s. © www.alfain.eu... - Page 5 The maximum open-circuit voltage of the plasma machines is established by national and international standards (EN 60974-1) depending on the type of current to be used, on its waveform and on the ALFA IN a.s. © www.alfain.eu...
- Page 6 2. Welding gloves 3. Welding apron and cloth 4. Welding boots RISK OVERVIEW 1. Risk of electric shock. 2. Ultraviolet light and light radiation 3. Risk of inhaling gas fumes and dust particles 4. Burns 5. Noise ALFA IN a.s. © www.alfain.eu...
-
Page 7: Conditions Of Use
The gas bottle with a maximum height of 0.9 m may be placed and properly anchored on the platform The machine must be protected against a. Moisture and rain and snow b. Mechanical damage ALFA IN a.s. © www.alfain.eu... -
Page 8: Technical Data
During operation, the device may be the source of interference. Caution We warn users, that they are responsible for possible interference from welding. 4. TECHNICAL DATA ALF 182 BASIC AXE Method MIG/MAG Mains voltage V/Hz 3 x 400/50... -
Page 9: Accessories
3. Gas hoses ACCESSORIES TO ORDER 1. Wire cleaner 2. CO2 Gas pre heating cable 3. Reduction valve KU 5, K 2 4. Gay cylinder 5. Torch consumables 6. Earthing cable 4 - 5 m ALFA IN a.s. © www.alfain.eu... -
Page 10: Description Of The Appliance
ON / OFF Switch Voltage switch LED ON Indicator Work leads LED over heating indicator Wire speed potentiometer EURO connector Gas heater connector Solenoid Valve – gas connector Mains cable Chain for fixing the gas cylinder ALFA IN a.s. © www.alfain.eu... - Page 11 PCB - encoder ON / OFF Switch Voltage switch LED ON Indicator LED over heating indicator Wire speed potentiometer Spot time potentiometer Interval time potentiometer WIRE FEEDER Fig 3 – Wire feeder Pos. Description Fixing shaft Pressure arm ALFA IN a.s. © www.alfain.eu...
- Page 12 = 30 mm b = 30 mm Grove type Wire diameter Item No 0,6-0,8 2187 Steel 0,8-1,0 2188 0,8-1,0 2270 Aluminium 1,6-2,0 2513 0,8-1,0 2318 Flux core Note: Largest permissible diameter of the wire is 1,0 mm. ALFA IN a.s. © www.alfain.eu...
-
Page 13: Getting Started
D2. 3. Cut off the curved or damaged end of welding wire and lead it through the inlet liner E3, and the roll into the liner inside the EURO torch connector ALFA IN a.s. © www.alfain.eu... - Page 14 4. In case there is suitable groove on the roll, turn it around and fix it back to the feeder. Fig. 6- The influence of the roll groove on the wire Correct Wrong Wrong ALFA IN a.s. © www.alfain.eu...
- Page 15 The electric arc and the weld must be perfectly shielded by gas. Too small amount of gas does not perform the protective atmosphere and on the other hand to big amount of the gas brings air into the electric arc. Fig. 8 – Gas fitting ALFA IN a.s. © www.alfain.eu...
-
Page 16: Welding
The appliance must be plugged into the mains, the ON/OFF switch A1 on "I". To select the voltage use step switch A2. To select the current (that is linked to the wire speed) use the potentiometer A6 (P1). ALFA IN a.s. © www.alfain.eu... - Page 17 The welding stops after the second pressing and releasing the torch button then. Welding proces 1- 2 3 - 4 ALFA IN a.s. © www.alfain.eu...
- Page 18 P2, the pause by the right potentiometer P3. By pressing the torch button activate the time circuit that starts and end the welding procedure. Welding proces Welding proces Pause ALFA IN a.s. © www.alfain.eu...
- Page 19 The default time is 50-80 ms. I tis possible to change the burn back time by means of a trimmer placed on the rear side of the control board. It is necessary to take off the front panel. Only a qualified person may curry out this operation. ALFA IN a.s. © www.alfain.eu...
- Page 20 Gas flow [l/min] of welding [l/hour] 6 * 60 = 360 8 * 60 = 480 10 * 60 = 600 12 * 60 = 720 16 * 60 = 960 20 * 60 = 1200 ALFA IN a.s. © www.alfain.eu...
-
Page 21: Routine Maintenance & Inspection
The warranty period begins on the date of sale to the end user. 4. If warranty is being sought, please contact your ALFA IN product supplier for the warranty repair procedure. 5. ALFA IN warranty will not apply to: ALFA IN a.s. © www.alfain.eu... -
Page 22: Disposal
ALFA IN a.s. © www.alfain.eu... -
Page 23: Warranty List
As a warranty list serves proof of purchase (invoice) on which is the serial number of the machine, eventually a warranty list below, which is filled in by an authorized dealer. Serial number: Day, month (written in words) and year of sale: Stamp and dealer signature: ALFA IN a.s. © www.alfain.eu...
