- Page 1 - 1 - WELDING INVERTER PEGAS 200 AC/DC PULSE OPERATING MANUAL ALFA IN a.s. © www.alfain.eu NA156-6...
-
Page 2: Table Of Contents
BILEVEL – SECOND WELDING CURRENT ........13 BASIC SETTINGS FOR TIG WELDING ........... 13 ROUTINE MAINTENANCE & INSPECTION ..........14 STATEMENT OF WARRANTY ..............15 DISPOSAL ....................15 ALFA IN a.s. © www.alfain.eu... -
Page 3: Introduction
Manual represents the Manufacturer's best judgement, the Manufacturer assumes no liability for its use. PEGAS 200 AC/DC PULSE welds by those methods 1. E – (MMA) DC coated electrodes up to 4,0 mm 2. E – (MMA) AC coated electrodes up to 4,0 mm 3. -
Page 4: Safety Instructions And Warnings
To prevent electric shock, we strongly suggest the following rules: Do not work in a damp or humid environment. Do not use the welding machine if its cables are damaged in any way. ALFA IN a.s. © www.alfain.eu... -
Page 5: Electromagnetic Compatibility (Emc)
Domestic electronic appliances (radios, TVs, videos, telephones, burglar alarms, etc.). Computers, robots, electro-medical instruments and life-support systems. Radio-television transmitters and receivers. Pacemakers and hearing aids. All very sensitive electrical equipment. ALFA IN a.s. © www.alfain.eu... -
Page 6: Technical Data
TIG - DC Mains voltage V/Hz 1x230/50-60 Welding current range 10/10,4 - 200/18,0 5/10,2 - 200/18,0 Open-circuit voltage U20 Welding current (DC=100%) I2 /U2 70/12,8 80/13,2 ta=40 oC Welding current (DC=60%) I2/U2 90/13,6 110/14,4 ta=40 oC ALFA IN a.s. © www.alfain.eu... -
Page 7: Equipment
EQUIPMENT CONTENT OF DELIVERY Item No. Description Quantity 5.0172 PEGAS 200 AC/DC PULSE 5.0189 Set of Connectors for PEGAS AC/DC ACCESSORIES TO ORDER Item No. Description VM0184-1 Hose Gas ATA PULSE 3m G1/4, D 9.5 HD... -
Page 8: Operator Controls
Display Voltage, %, time and Hz. LED Main Welding Current in the pulse mode. 5 – 200 A DC, 10 – 200 TIG AC LED Pulse Base Current. 5 – 200 A DC, 10 -200 A AC. ALFA IN a.s. © www.alfain.eu... - Page 9 LED Gas Test. If illuminated the mode of setting the gas flow was selected (by means of the gas valve on the gas cylinder). To turn it off press the button 31 again or it will go off this mode after 10 s. ALFA IN a.s. © www.alfain.eu...
-
Page 10: Getting Started
Prevent touching the electrode any metal material for in this mode the terminals 42 and 44 are under current. Insert the coated electrode into the electrode holder, connect the clamps of the ground cable to the welding piece and you may start welding. ALFA IN a.s. © www.alfain.eu... -
Page 11: Getting Started Tig
Connect the work clamp to the work piece or at the welding table and you can start welding. The following table describes the influence setting the clearance effect. Clearance effect Value 20-30% Value 50% Shape of the current curve Penetration Deep Shallow ALFA IN a.s. © www.alfain.eu... -
Page 12: Remote Control
Level of wear of the of Smaller Bigger tungsten electrode REMOTE CONTROL The PEGAS 200 AC/DC PULSE supports three kinds of remote controls. 1. TIG torch with UP-DOWN buttons 2. Foot pedal 3. Standard separate remote control for changing the value of the welding current. -
Page 13: Two Stroke And Four Stroke In Tig Mode
BASIC SETTINGS FOR TIG WELDING Table for stainless steel, DC current Material Tungsten Filler material Welding Argon flow thickness electrode diameter mm current l/min nozzle ALFA IN a.s. © www.alfain.eu... -
Page 14: Routine Maintenance & Inspection
The welder should also be wiped clean. If necessary, solvents that are recommended for cleaning electrical apparatus may be used. Troubleshooting and repairing of PEGAS welding equipment should only be carried out only by suitably qualified or competent person. ALFA IN a.s. © www.alfain.eu... -
Page 15: Statement Of Warranty
In accordance with European Council Directive 2002/96/EC on electrical and electronic equipment waste and its implementation in accordance with national law, electric tools that have reached the end of their service life must be collected separately and returned to an environmentally ALFA IN a.s. © www.alfain.eu... - Page 16 -16- compatible recycling facility. ALFA IN a.s. © www.alfain.eu...
