Page 11: About This Manual
About this Manual This user guide is designed for the technician who will install the Forum 525/ 526 and put it into operation. Usually this is the responsibility of your Proximus agent, who will prepare the Forum 525/526 and hand over the configured, operational system.
Page 12: Features
(point-to-multipoint) are both supported. The two forms of access can be configured in parallel. For this purpose the Forum 525/526 with interface cards provides up to 12 S ports (switchable between internal/external). An overview of all possible interface card combinations can be found under Forum 525/526 (5 Slots) starting on page 34.
Page 13 The Forum 525/526 supports the display of the name on system telephones. However, if you have created an entry in the telephone book of the Forum 525/526 under the number of the caller, this will be displayed instead.
Page 14 As your company’s requirements grow, the Forum 525/526 can be networked with other telecom systems (see PBX Networking starting on page 133). The Forum 525/526 can then operate as a sub-system or DECT server. To operate the networked Forum 525/526 as a DECT server the system’s U...
Page 15 Packet data transfer through the ISDN D channel (according to X.31 via SAPI 16) can also be established between several S interfaces of the Forum 525/526. Simultaneous connections are distinguished by means of a TEI (Terminal Endpoint Identifier).
Page 16 IP address. Only this is externally visible. The local IP addresses of the client PCs are translated to the IP address of the Forum 525/526 by network address translation (NAT). In this way the client PCs in the LAN cannot be reached directly from the Internet.
Page 17 Important events and errors are kept by the Forum 525/526 in an internal log book: the error store. To inform or alert the system administrators, entries in the log book (system messages) can be sent via e-mail. Further network features You can offer staff the possibility of dialling into the LAN by means of RAS access.
Page 18: Factory Settings On Delivery
“Administrators” can access all functions in Forum 525/526 and have unlimited configuration rights. Users in the “Guests” group can not configure Forum 525/526, may not make any external calls and can only use a limited range of Forum 525/526 terminal functions. The “Standard” user group is well suited as a starting point for creating user groups for normal users of the system (e.
Page 19 Authorisations Note: When the Forum 525/526 is commissioned, all connected terminals are initially in the “Administrators” group. For more details on the configuration of user groups, refer to the online help in the chapter entitled “User manager”. The following functions are delivered preset for user groups:...
Page 20 Authorisations User group settings Function / authorisation Standard Adminis- Guests trators Dial in (outgoing) External Inter- Inter- Incoming national national only Immediate external line seizure External line seizure over operator Deactivate LCR LCR at call forwarding to extern VIP call PIN dial Announcement Announcement accept...
Page 21 Authorisations User group settings Function / authorisation Standard Adminis- Guests trators Take Call removal Calling suppression at the parallel terminal Reaction: connection will be disconnected Display phone number off (intern Call queue Call forwarding Call forwarding Call forwarding to extern Call forwarding of MSN groups Call forwarding door call Indicate call forwarding after time...
Page 22 Authorisations User group settings Function / authorisation Standard Adminis- Guests trators MOH at internal connections Protection Call protection ring-back ring-back tone tone Call waiting protection Int. + ext. Int. + ext. calls calls Announcement protection Intercom protection Pickup protection Phone lock Intercept Lists Black lists...
Page 23 Authorisations User group settings Function / authorisation Standard Adminis- Guests trators Menu and ABC keys DECT trunc keys Disconnect ISP connection Connection data Send incoming connections Send outcoming connections Recording incoming connections Recording outgoing connection Number of suppressed digits Incoming basic amount 0,000 0,0000 0,0000...
Page 24 The door opener can be opened from all terminals. Door calls can be forwarded. ● Every standard user can change the configuration of Forum 525/526. ● Every standard user can create a personal telephone book and edit entries in the central telephone book.
Page 25: Lan Settings / Internet Functions
Domain name assigned via DHCP “domain” ● RAS access (with or without callback) can be set up for every Forum 525/ 526 user. RAS access requires the activation of the RAS authorisation. ● Multiple e-mail account queries can be set up for every user. Every user with a system terminal can be automatically informed about incoming e- mails with this function.
Page 26: Update Notes
Forum CTI Touch CTI solution for smartphones You can also use these features as needed on an existing Forum 525 communications system. You can thus purchase an upgrade licence: ● When updating the software to release 9 you can use the new release 9 features without the extended range of functions.
Page 27: Technical Notes
Technical Notes ● An upgrade licence enables you to use the new release 9 features including the extended functions (see table New features Forum 526). When you enter the upgrade licence authorisation key, the communica- tions system changes its designation to Forum 526. The upgrade licence is already included when you purchase a new Forum 526 communications system.
Page 28: Updating
Updating ● From release 9 the IP telephones “Forum IPhone 520” und “Forum IPhone 530” are no longer supported. During an update, configured devices will be converted to “Forum IPhone 525” or “Forum IPhone 535” to retain the key data. ●...
Page 29: Installation
This device contains hazardous voltages. To make the system powerless, remove the power plug from the socket. The Forum 525/526 may only be plugged into mains sockets with a protective earth conductor. Mount the Forum 525/526 only close to easily accessible sockets.
Page 30: Mounting Location
Do not install the Forum 525/526 during a thunderstorm. Do not connect or disconnect lines during a thunderstorm. The Forum 525/526 is designed for indoor use only. Lay the cables so that they cannot be walked on or tripped over.
Page 31: Wall Mounting
Mounting plan To fasten the screws at points B and C, remove the cover of the Forum 525/ 526 and insert the screws in the holes provided for this purpose. The Forum 525/526 is suspended from the screw at point A, so there must be a space of 3 mm between the screw and the wall.
Page 32: V.24 And Doorstation Equipment Slots
V.24 Doorstation equipment Forum 525/526: V.24 and doorstation equipment slots The Forum 525/526 has two slots in which special interface cards can be operated (V.24 and doorstation equipment). You can see the location of these slots in the diagram. ●...
Page 33: Slots For Additional Interface Cards
Slots for Additional Interface Cards The Forum 525/526 has five large slots in which you can operate interface cards. Each interface card is connected to the main module via two port jacks. The following properties characterise the large slots: ●...
Page 34 Forum 525/526: Installing an interface card Proceed as described below to install an interface card: 1. Turn off the Forum 525/526. Open the housing cover. 2. Remove the slot card from the transport packaging. Check that it is the correct slot card type. There is a sticker with the type name on the connector.
Page 35: Available Ports
34). 5. Close the housing cover and turn on the Forum 525/526 again. The software of the Forum 525/526 can detect the type of interface card present. The interface card must still be configured individually for commissioning.
Page 36: Positions Of The Ports
One CompactFlash socket to incorporate a type I or type II CompactFlash memory card. The memory card is always necessary for operating the communications system. The Forum 525/526 communications system is always delivered with a pre-installed CompactFlash card. Positions of the Ports...
Page 37 Interface Cards Interface card Slots Special features Forum 523 / 525 are switchable internally/ Card 4 S0/T0: externally 4 x S Forum 523 / 525 also usable for DECT- Card 4 digital extensions: 4 x U Forum 523 / 525 also usable for DECT- Card 8 digital extensions:...
Page 38 Interface Cards Slot 1 Slot 2 Slot 3 Slot 4 Slot 5 Ports: 4 x S (Forum 523 / 525 Card 4 S0/T0) Slot 1 Slot 2 Slot 3 Slot 4 Slot 5 Ports: 4 x U (Forum 523 / 525 Card 4 digital extensions) Slot 1 Slot 2 Slot 3...
Page 39: Port Assignment, Termination, Cable Lengths
Port Assignment, Termination, Cable Lengths Slot 1 Slot 2 Slot 3 Slot 4 Slot 5 Ports: 2 x S and 6 x a/b (Forum 523 / 525 Card 2 So/T0, 6 analogue exten- sions) Slot 1 Slot 2 Slot 3 Slot 4 Slot 5 Ports: 4 x a/b (Forum 523 / 525 Card 4 analogue extensions)
Page 40 Ports on interface cards Forum The S bus is terminated at one end by the Forum 525/526. IAE = ISDN socket (German: “ISDN Anschluss Einheit”) or an ISDN terminal. TR = terminating resistor, the S termination. The TR must be at the termi- nation of the line.
Page 41: U Pn Ports
1 2 3 4 5 6 7 8 Switchable S port on a pressure terminal You can add S ports to the Forum 525/526 by installing suitable interface cards in a slot. These S ports can be switched between internal and external operation.
Page 42: A/B Ports
A door station of the type “Doorphone” can also be operated on the Forum 525/526. This intercom is connected via a “Doorphone” module to one of a/b ports of the Forum 525/526 (see Intercom system (for a/b) starting on page 44).
Page 43: Dsl Port
External DSL modems can be connected via the LAN port. In the case of the Forum 525/526, the output of the DSL modem (NTBBA) is led to the LAN port of the Forum 525/526 via an external switch or hub. The router subsequently converts the PPPoE protocol to the TCP/IP protocol of the LAN.
Page 44: Connectible Terminals
Connectible Terminals Connectible Terminals The Forum 525/526 ports offer a large number of possibilities for connecting terminals. Internal/External S Ports All S ports can either be connected externally (i.e. to ISDN network terminators) or internally. It is not possible to use both assignments simultaneously.
Page 45: A/B Ports
The maximum transmission rate for analogue modems is 33.6 kbit/s (V.34+). Music on Hold If you do not operate an external MoH device, the Forum 525/526 offers an internal MoH, which you can load in the Web console Configurator in the System: Components menu.
Page 46: Com Port
“Doorphone” module. COM Port By installing the V.24 interface card (Forum 525 Card serial interface) a serial port on the COM interface is provided. Please note:The connection line for the COM port can be up to three metres long.
Page 47: Pra Connector Module
PRA Connector Module (ISDN 30/Forum 516 PRA Module) The Forum 516 PRA Module allows you to operate a Forum 525/526 on a primary rate access. This access provides up to 30 voice channels. You can also use the Forum 516 PRA Module to network two systems, e.g. in order to use the Forum 525/526 as a subsidiary system or DECT server.
Page 48 Installation 1. Pull out the mains plug of the Forum 525/526. 2. Open the housing cover of the Forum 525/526. 3. On the module board, remove the protective covers of the two S slots (A) and (B). slots Activity LED...
Page 49 NT or the other PBX according to the following drawing. Make sure the RX and TX lines are crossed over (connect the RX lines of the Forum 525/526 to the TX lines of the other PBX).
Page 50: Configuration
Configuration Configuration The menu item S appears in the Configurator, menu Telephony: Ports after installation of the S module. Configure the port in the input mask of this menu item. Further information on this can be found in the online help.
Page 51: Mounting The Forum 526 Rack Infocom System
Safety Precautions Mounting the Forum 526 Rack InfoCom System The Forum 526 is also available as rack version for mounting in a standard 19" EIA rackmount cabinet. Forum 526 Rack Frame and Ports Safety Precautions The system needs to be mounted in earthed cabinets or cases. Lines and cables connected to the communications system must only be laid inside buildings.
Page 52: Technical Data
Technical Data supply and protective earthing, should only be performed by skilled, qualified personnel. EN, IEC regulations, along with other recognised technical rules regarding safety, must be observed. Technical Data (differences to the wall-mounted Forum 526 only) Dimensions: ● Width: 19-inch panel with flange for mounting in installation cabinet ●...
Page 53 ... a/b4 An overview of the interface cards can be found under the heading Forum 525/526 (5 Slots) starting on page 34. For each of the five slots, there is a LED on the front panel of the Forum 526 Rack. These LEDs are labelled SLOT1..SLOT5. An LED will show a constant light, if an interface card is inserted into the corresponding slot and the operating software has detected an interface card.
Page 54: Scope Of Delivery
Scope of Delivery Scope of Delivery ● One communications system Forum 526 Rack ● One AC adapter with connection cable ● One set of short user guides ● One CD Mounting the Forum 526 Rack InfoCom System...
Page 55: Configuration
For the initial configuration you can connect the PC to the Forum 525/526 via the Ethernet port. The TCP/IP network protocol is used to set up a connection via one of these ports. You can then open the Web console of the Forum 525/ 526 and call up the Configurator from there.
Page 56: Brief Guide To Initial Configuration
Brief Guide to Initial Configuration Setting up a first connection is quite simple with a standard Windows PC: 1. Connect the PC’s network card with one of the Forum 525/526.’s LAN ports Use a cross-wired Ethernet cable to do this.
Page 57: Configuring The Forum 525/526
● A list of the users to be set up (staff entitled to use the services of the Forum 525/526) with their names, departments, and the internal call numbers you want to allocate to them ● For Internet access: the Internet service provider access data.
Page 58: Starting The Web Console
Load. The update takes a couple of minutes, after this a new page is displayed in the browser. 3. First set the country in which you are operating the Forum 525/526, and in which language the Web console is to be displayed.
Page 59 5. Confirm this by clicking on Login. 6. When you first commission the system, you have to update the system software. Upload the system software file. The communications system will then reboot. The login page is displayed again. Forum 525/526: dialogue box for initial access Configuration...
Page 60 Make a note of the password and keep it in a safe place. Since release 8 the communications system Forum 525/526 distinguishes between safe and unsafe passwords. A safe password consists of: – at least eight characters –...
Page 61: Finishing The Configuration
2. Then select the Log-off command in the upper menu bar. Saving and Loading the Configuration Configurations are saved in a file archive and can be loaded to the Forum 525/ 526 either locally from a connected configuration PC, or by remote configuration.
Page 62: Remote Configuration
LAN prerequisites. Remote Configuration The Forum 525/526 configuration can be edited or updated by the Proximus Customer Service Centre via a remote access connection (ISDN-RAS) or via an Internet connection (reverse ssh tunnel). In the factory setting on delivery, two Proximus Remote Service Centre telephone numbers are preset, under which a system technician can dial into the Forum 525/526.
Page 63 In order for the system technician to be able to log into the Forum 525/526, he requires a user name and password. In this case, the solution would be to configure a “Service”...
Page 64: Codes For Ip Configuration
The IP configuration of the Forum 525/526 is performed on the Web console in the Configurator, in the Network: LAN menu. In the event that the IP configuration of the Forum 525/526 has to be changed and access via the Web console is not possible, you can also use a code digit procedure to change these basic settings.
Page 65: Receiving System Messages As E-Mail
“0000”. Receiving System Messages as E-Mail Important events and errors are kept by the Forum 525/526 in an internal log book: the error store. To inform or alert the system administrators, entries in the log book (system messages) can be sent via e-mail.
Page 66: Resetting The System Data
For further information, refer to the online help documentation under the item System: Firmware. Resetting the System Data You can restore the factory settings of the Forum 525/526 in the Configurator. If this is not possible, refer to the next section entitled Basic Hardware Settings Switch.
Page 67 34. Press and hold the switch. 4. Replace the power plug in the mains socket. Wait about 30 seconds until the indicator on the front of the Forum 525/526 constantly flashes. 5. Disconnect the power plug from the mains socket again.
Page 68: Configuration Examples
(if the multi-company variant is activated). In addition, the Forum 525/526 can be used as an Internet access server. RAS access can also be implemented using the Forum 525/526, which enables the integration of external staff in the LAN.
Page 69: Introduction To Tcp/Ip
In a single LAN it is possible to use various protocols for the transmission of data. The connection between a workstation computer and the Forum 525/ 526 runs via the IP protocol (also named TCP/IP) used on the Internet. IP can be used together with other protocols (e.g.
Page 70: Forum 525/526 In A Serverless Lan
Forum 525/526 in a Serverless LAN IP range Common netmask Comment 192.168.0.0- 255.255.255.0 256 smaller networks 192.168.255.255 172.16.0.0- 255.255.0.0 16 medium networks 172.31.255.255 10.0.0.0- 255.0.0.0 1 large network 10.255.255.255 IP enables the establishment of connections via one or more intermediate stations.
Page 71: Dns Name Resolution
PC 2 The Forum 525/526 in a serverless LAN In a serverless LAN, the Forum 525/526 takes over the IP configuration of the connected workstations. All IP settings necessary for the workstations are assigned by the Forum 525/526 via DHCP (dynamic host configuration protocol).
Page 72: Internet Access
Internet as the domain name (“firm-forum.co.uk” for example). RAS Access You can establish a connection to the Forum 525/526 from an external PC via an ISDN card. The necessary IP settings are transmitted by the Forum 525/526 on establishment of the connection.
Page 73: Forum 525/526 In A Lan With An Ip-Enabled Server
In a LAN with an IP-enabled server, you should coordinate integration of the Forum 525/526 with the responsible network administrator. You must decide on the IP address space to be used and which network services (DHCP, DNS, RAS, Internet access) the Forum 525/526 is to handle in the LAN. Forum Server...
Page 74: Dns Name Resolution
Internet Access You can also use the Forum 525/526 as an Internet access server in a LAN with an IP-enabled server. To do this, you must enter the Forum 525/526 IP address on the server as the default gateway. In addition, you must edit the internal DNS server configuration so that the resolution of external DNS names is forwarded to the Forum 525/526.
Page 75: Ras Access
Forum 525/526 in a LAN with an IP-enabled Server There are two different ways of suitably configuring the internal DNS server. You can enter the Forum 525/526 IP address as a DNS forwarder. If you require access to extended DNS information, you can also configure the DNS server for a recursive DNS request without the DNS forwarder.
Page 76: Branch Link
Branch Link You can use the Forum 525/526 to interlink two LANs via ISDN. To do this, you configure two Forum 525/526 systems so that they can dial in to each other. In order for this to work, the two LANs must be configured for different IP address ranges (subnetworks).
Page 77: Useful Information On Internet Access
Useful Information on Internet Access In the Configurator, Network: Branch menu you can configure the dial-in settings. The Forum 525/526 will set up a connection whenever a IP data transfer to the other LAN is requested. Note that such a connection is only set up when specific requests are made.
Page 78: Using The Web
One of the most important services in the Internet is e-mail. E-mails are buffered in individual e-mail accounts on a mail server. Mail servers are operated by ISPs for example. With the Forum 525/526 you can set up one or more e-mail accounts for every user account configured on the Forum 525/ 526.
Page 79 The protocol will function without TCP/UDP port numbers, e.g. ICMP or IGMP. The Forum 525/526 NAT has suitable processes for ensuring the functions of many important protocols affected by these rules. These are the protocols FTP (in “active” mode), CuSeeMe (“videoconferencing”), IRC (“chat”), ICMP errors (“traceroute”) and ICMP echo (“ping”).
Page 80: Voice Over Ip (Voip)
Integrating the two communi- cation networks into a single communications network can provide consid- erable savings. The Forum 525/526 gives users all the features of system telephony through its use of an IP-based protocol. Furthermore, the standardised SIP protocol can also be used on the intranet.
Page 81: Quick Start
Fundamentals starting on page 83. Quick Start IP System Telephony VoIP system telephony can be quickly and easily set up using the Forum 525/ 526. 1. For Q.SIG-IP or to increase performance, install a Forum 523 / 525 Media Gateway Card.
Page 82: External Sip Line
Pair cable) to connect an IP telephone to a Local Area Network (LAN). External SIP Line If your Forum 525/526 has access to the Internet, you can an easily and quickly set up a SIP line. 1. Request at least one SIP account from a SIP provider.
Page 83: Internal Sip Telephony
2. Call up the Configurator and go to the page Telephony: Ports: Slots. Click on the corresponding slot. Under Configured, select MGC VoIP. Optional: enter an IP address from the Forum 525/526 IP network which is not being used, such as 192.168.99.253 under IP Address Configured. Click on Apply.
Page 84 Quick Start 3. Call up the Telephony: Devices: VoIP phones page in the Configurator. Click on New. Select the “SIP” option under Type and enter an internal Phone No. Click on Apply. 4. Call up the User manager: User page. Assign the new internal call number to a user.
Page 85: Fundamentals
Fundamentals you click on Reset licences, the available licences will be reassigned with the next incoming or outgoing calls. Fundamentals VoIP makes the transmission of voice and telephony signalling via IP (“Internet Protocol”) possible. After a connection is established, the terminal collects voice data (PCM data), which is then sent to the receiver using an IP packet.
Page 86: Voice Quality
Fundamentals The length of the voice-data packets must therefore be adjusted to the requirements of the transmission medium. Shorter voice-data packets can be sent if a direct ethernet connection exists. If an 64 kbit/s ISDN line is to be used for transmission, then longer voice-data packets should be used. Longer voice data packages are generally used for SIP telephony over the Internet.
Page 87 Fundamentals Quality levels for voice transmission with VoIP Level Voice comprehensibility Comparable to Very Good ISDN Good DECT Satisfactory Limited Defective GSM > 4 Unacceptable No Connection When a call is set up, the terminals involved negotiate the voice-data compression (“codec”) that will be used. This is the first factor that determines the achievable quality level: ●...
Page 88: Optimisation
Fundamentals Packet propagation delay and packet loss Value Quality level Value Quality level Propagation Optimal Loss < 1 % Optimal delay < 50 ms Propagation 0.5 level Loss 1-2 % 0.5 level delay 50-100 ms depreciation depreciation Propagation 1 level Loss 2-3 % 1 level delay...
Page 89: Call Set-Up
Various IP-based protocols are used for system telephony via the Internet protocol (“IP”) (see also Start Procedure starting on page 110). Multiple TCP connections are made between an IP telephone and Forum 525/526 for the telephone’s start procedure, registration and signalling.
Page 90: Voip Profiles For Sip
After successfully agreeing on a codec, the resulting RTP connection is established between the terminals directly. The Forum 525/526 communications system can also serve as a proxy for the media data stream (“RTP Proxy function”) if external SIP lines do not allow direct RTP data connection between the terminals.
Page 91 The extended codec list contains definitions for codecs which are used by the usual SIP terminals. The codecs on this list are for usage in VoIP profiles and are not directly supported by the Forum 525/526 communications system.
Page 92: Voice Activity Detection (Vad)
Allocate this VoIP profile to the desired SIP terminal or to the desired SIP tie line. Please note that any codecs not in the VoIP profile are filtered out by the Forum 525/526 communications system during codec negotiation. Voice Activity Detection (VAD) You can change the codec configuration under Telephony: Extended: VoIP profile.
Page 93: Software Mgw
The MGW interface card is connected via the slot to the internal ethernet Switch. There are no external ports via pressure terminals. ● With a Forum 525/526 up to two MGW interface cards can be operated in slots 3 and 4. ●...
Page 94: Sip Telephony
The SIP Internet (Session Initiation Protocol) protocol provides you with a low- cost, standardised option for telephoning via IP-based networks. The Forum 525/526 enables you to use external SIP telephone connections (“SIP trunk lines”). The Forum 525/526 communications system supports configuration of standard SIP lines with one call number for each as well as extension-capable SIP-DDI lines with base call number and extension.
Page 95: External Sip Connections
● You must log on (“Login”) to the SIP registrar before you can use SIP telephony. Use the Forum 525/526 to manage important information for the registration (user name and password) of one or more SIP accounts. It is possible to make several calls simultaneously using a single SIP account.
Page 96 For this reason, incoming RTP calls often fail to get past the Firewall or NAT configuration of the Internet gateway product used. If you do not use the Forum 525/ 526 as the Internet gateway, the product should be compatible with SIP telephony.
Page 97: Internal Sip Subscribers
Call Number Mapping. Internal SIP Subscribers The Forum 525/526 becomes available as the SIP server for internal SIP subscriber telephony switching services. SIP telephones connected via LAN or SIP programmes installed on workstation computers can thus establish connections to all other devices or trunks connected to the Forum 525/526.
Page 98 "Displayname" <sip:123@192.168.99.254>. The text portion of the SIP-URI (“Display Name”) is not evaluated at log-on from the Forum 525/ 526. The series of characters before “@” is the “User Name” or “SIP Username”. The internal call number of the user must always be used here (the Ph.No.
Page 99 “Forum 500 / Forum 5000 – Standard Terminals” user guide. Alongside code number procedures, SIP subscribers can also use a series of functional features realized via the SIP protocol. The Forum 525/526 is the ending for all SIP connections as opposed to what is usually the case on the Internet.
Page 100: Sip System Telephones
You can operate the Forum IPhone 512, Forum IPhone 545 and Forum IPhone 5010/5020/5025/5030/5040 SIP system telephones on the Forum 525/526 communications system. The firmware of the communications system already includes the matching firmware files (Firmware addons, “*_fwaddons_*.cnt”) for the following SIP system...
Page 101 SIP Telephony SIP system telephones Model Short description Forum IPhone 5010 ● Display: Monochrome LCD, 2.75" (128x48 pixels) ● Hi-Q : Wideband handset and speaker-phone ● Network ports: 2 Ports Fast Ethernet ● PoE support: PoE Class 1, separate wall power supply available ●...
Page 102 DTMF signals according to RFC 2833/4733. An MGW Interface Card is required to operate SIP system telephones with the Forum 525/526 communications system. As an additional requirement, a memory card with 256 Mb or more must be installed. This will provide the...
Page 103 IP address configuration from the DHCP server of the Forum 525/ 526 communications system. The IP address and the location for loading files from the TFTP server of the Forum 525/526 is received as a part of the DHCP answer.
Page 104 DHCP Settings The address and device configuration is transferred from the Forum 525/526 communications system to the SIP system telephone using the DHCP protocol. You can configure the necessary address settings while adding a...
Page 105 DHCP answer is activated. The TFTP server of the Forum 525/526 communications system will serve up to 4 concurrent data transfers. To avoid overloading the TFTP server (e.g.
Page 106: Sip Entrance Intercom Systems
SIP Entrance Intercom Systems You can operate IP-based entrance intercom systems (EIS) in the Forum 525/ 526. The “SIP” protocol is used for signalling. As far as the Forum 525/526 communications system is concerned, an SIP entrance intercom system (SIP EIS) is an SIP telephone produced by another manufacturer that is used for the audio connection to the door.
Page 107 ● Configuration of the SIP EIS (device configuration). The configuration of the SIP EIS must be coordinated with the configuration of the Forum 525/ 526 communications systems. This is the only way to ensure fault-free operation. You can find details on the configuration of the SIP EIS in the documentation provided by the relevant manufacturer.
Page 108 SIP EIS documentation. Make a note of the SIP parameters that are necessary for configuration of the SIP EIS by opening the setup help for the Forum 525/526 communications system. To do this, on the Telephony: Devices: VoIP phones page, click Help in the table row for the relevant SIP EIS.
Page 109: Voip System Telephones
Bell 3: Call number = 13 Bell 4: Call number = 14 To complete the doorbell configuration, in the Forum 525/526 communi- cations system, set up the call distribution for each doorbell of the SIP EIS in the Telephony: Ports: Doorbell menu.
Page 110: Voip System Telephone Configuration
Standard operating procedure is to contact the Forum 525/526’s DHCP server so that the start procedure can be concluded without problems. To register a new VoIP system telephone, proceed as follows: 1.
Page 111: Lan Dhcp Server
The MAC address of all VoIP system telephones always begins with 00:30:42. 2. Configure a fixed IP address for the Forum 525/526. To do this, call up the Configurator and open the Network: LAN page. Click on the Change button.
Page 112: Start Procedure
VoIP System Telephones 4. Configure the Forum 525/526’s DHCP server to assign IP addresses. To do this, call up the Configurator and open the Network: DHCP page. Click on the Change button. 5. From Status, select the address assignment option. Confirm with Apply.
Page 113 5. The VoIP system telephone creates a TCP connection to the supplied IP- address/port-number combination and sends a registration query. The Forum 525/526 checks the MAC address sent with the registration and confirms the registration request if the VoIP system telephone is listed in the menu Telephony: Devices: VoIP phones.
Page 114: Local Configuration
VoIP System Telephones the Telephony: Devices: VoIP phones for the VoIP system telephone. The operations software provided via TFTP must match the type of device and communications system. You may also need to configure BOOTP, DHCP and TFTP servers for the VoIP system telephone. Local Configuration In addition to automatic configuration via BOOTP/DHCP, it is possible to manually configure a Forum IPhone 525 or a Forum IPhone 535.
Page 115 VoIP System Telephones Note: Java programmes can be run on all common operating systems. To execute Java-based programmes, you must install a suitable Java runtime environment on your operating system (JRE). This can be downloaded under the following web address: http:// www.java.com/.
Page 116 (see table on page 110). Registration IP address and Registration port: This is where you usually enter the IP address of the Forum 525/526 and the port number 8100. Default gateway: Click on the Add parameter command to have this optional entry field displayed.
Page 117: Forum Iphone Pc
You will not need a licence to install Forum IPhone PC but you will require a licence to operate it with the Forum 525/526. Unit licences, enabling the simultaneous operation of a certain number of Forum IPhone PCs, are available.
Page 118: Installation
Options dialogue is automatically opened. Here you must configure the following values: 1. Enter in the VoIP IP Address field the Forum 525/526’s IP address. 2. Enter six hexadecimal-digits into the Device ID field. This device ID is not a MAC address, so overlapping with existent MAC addresses is possible.
Page 119 Forum IPhone PC The displayed menu texts and parts of the operations software are elements of the Forum IPhone PC installation, but they can be loaded from the Forum 525/526 via TFTP where necessary. Voice over IP (VoIP)
Page 120: U Pn Dect And Dect Over Ip
DECTover IP® is a registered trademark of Mitel Networks Corporation. Properties DECT Base Stations DECT base stations can be connected to the Forum 525/526 via U accesses or via network (TCP/IP). These DECT base stations are available for the type of access selected: DECT ●...
Page 121 When started, the operating software for the DECTover IP base stations is transmitted via TFTP protocol from the Forum 525/526. The configuration for the start sequence is transmitted by the DHCP server of the Forum 525/ 526 to a DECTover IP base station for the start sequence.
Page 122: Features
Forum Base DECT IP (v1 & v2) if desired. VoIP audio communication between the DECTover IP base station and the Forum 525/526 is made via the RTP/RTCP protocol. RTP voice data are directly converted into DECT voice data by the base station. The base stations support the following VoIP codecs: G.711...
Page 123: Configuration
DHCP server” setting. Select the desired DECTover IP base station with the MAC address (IP address) setting. Confirm with Apply. If the Forum 525/526’s DHCP server is not configured for static address assignment, you first need to configure the IP address of the DECTover IP Manager with the help of an additional programme (see Local IP address configuration starting on page 128).
Page 124: Dual Operation
DECT terminal automatically re-establishes a connection (roaming). Be sure to keep the PARK ID of your Forum 525/526 in mind. The PARK ID is displayed under System Info: Versions in the Configurator. If the PARK ID starts with 31, there may be an attempt at a handover between DECT base stations using different access technology.
Page 125: Synchronisation
Configuration Synchronisation Transmissions of all DECT base stations at a single location must be synchronised in order that DECT terminals are able to receive multiple DECT base stations simultaneously. Synchronisation can be conducted via U access. It cannot be conducted via an Ethernet / IP connection. DECTover IP base stations are thus synchronised via wireless connection.
Page 126 DECT: DECT over IP and click on the WLAN Config. button. Log in under the User Name “Administrator” and enter the same password as for the Forum 525/526. DECTover IP/OpenMobility Managers Login Page The WLAN settings are then made as follows: 1.
Page 127 Configuration If you operate older Forum Base DECT IP-WLAN indoor v1 and more recent Forum Base DECT IP-WLAN indoor v2 simultaneously, you need at least 2 different profiles. Under WLAN profile type, select the RFP42 (Forum Base DECT IP-WLAN) or RFP43 (Forum Base DECT IP-WLAN indoor v2) setting.
Page 128 Configuration DECTover IP/OpenMobility Manager: WLAN Profiles Use the following settings for standard operations. General settings ● Select the desired WLAN Profile and activate the Profile Active option. ● Enter a SSID (Service Set Identifier, wireless network identification) to identify a network. This network identification is transmitted at regular intervals, making it easier to find the networks you’re looking for, using the “View available wireless networks”...
Page 129: Configuring For A Remote Location
For the DHCP function to be available, the DECTover IP base station must be able to reach the Forum 525/526 via a “Broadcast”. In the case of a remote location this kind of access - via a VPN connection for example - will not be possible.
Page 130 Forum Base DECT IP v2 und Forum Base DECT IP User: “admin”, Password: “Admin” For RFPs in factory configuration, which are never connected to an Forum 525/526 communications system, the login credentials are: IP-DECT (Forum Base DECT IP): User: “admin”, Password: “Admin”...
Page 131 IP address. Leave the TFTP file name setting on the default setting (“/ ram/ip_tel/ip_rfp.cnt”) or “ng_ip_rfp.cnt”. 6. For a remote location, the Forum 525/526’s LAN will usually be accessed via a (VPN) router. Click on Router addresses: [+]. Enter the router’s IP address (“default gateway”).
Page 132: Pbx Cascading
PBX installations. If you merely need a larger number of connections, it is easy to link a second PBX (PBX Cascading). If you want to operate the Forum 525/526 at several locations with different PBXs, this is possible by PBX Networking (see page 133).
Page 133: Putting A Cascaded Pbx Into Operation
Putting a Cascaded PBX into Operation Putting a Cascaded PBX into Operation Proceed as follows to put a cascaded PBX system into operation: 1. Take the additional slave system out of its packaging and place it in imme- diate proximity to the master system. Connect a system telephone to the slave system for a later performance check.
Page 134: Notes
Putting a Cascaded PBX into Operation Notes Observe the following when operating a cascaded PBX system: ● All U and a/b ports of the slave system can be used with appropriate telephones. All features of system telephones on U ports are available without restriction.
Page 135: Pbx Networking
PBX networking in the following cases: ● To operate the Forum 525/526 as a subsidiary system on another PBX. This will also allow you to use the Forum 525/526 as a DECT server, for example. ● To network several Forum 525/526s into a PBX system.
Page 136: Point-To-Point Connection Technology
Point-to-Point Connection Technology Note: Networking via IP network connections requires a MGW interface card Forum 523 / 525 Media Gateway Card. Trunk line Point-to-point connection Example of a PBX network Various line types and transmission protocols can be used for point-to-point connections.
Page 137: Master/Slave
Point-to-Point Connection Technology ● L2: Layer 2 enables communication via individual error-protected channels that are independent of each other. ● L3: Layer 3 defines the administration of the individual channels and implements the features designed for ISDN. Master/Slave For an ISDN connection, it is possible to determine which PBX is the protocol master and which the protocol slave.
Page 138: Point-To-Point Connection Lines
If more than one port with the setting L1 Type = “Slave” is configured on an Forum 525/526 and the setting L1 sync possible has been activated, then one of the ports is automatically defined as the L1 clock source. The Forum 525/526 will automatically switch the clock source to another port configured as an L1 clock source (if a line fails, for example).
Page 139: Connection Via An Active Transmission System
Point-to-Point Connection Lines PBX 1, S PBX 1, S 1 2 3 4 5 6 7 8 Rx+ Rx- Tx+ Tx- 8 7 6 5 4 3 2 1 Rx+ Rx- Tx+ Tx- PBX 2, S PBX 2, S (RJ-45 socket) (Pressure clamps) Wiring of a direct connection Note:...
Page 140: Ip Network Connections
Connection via Q.SIG.IP The Forum 525/526 communications system supports transmission of the Q.SIG protocol – intended for ISDN point-to-point connections – via network connection (Q.SIG-IP). Protocol and call data are exchanged using IP connections with Q.SIG-IP.
Page 141: Connection Via Sip Tie Line
Select a VoIP profile for the codec selection. Please refer to the relevant help topics in the Online Help for the Forum 525/526 as well. Note: Q.SIG-IP cannot be operated using a connection with NAT.
Page 142 Select a VoIP profile for codec selection. Please note the corresponding help topics in the online help Forum 525/526. En-bloc dialling only is supported with a SIP tie line as with other SIP connections.
Page 143: Configuration
Configuration Configuration The possible configurations described below can be set up in the Web console using the Telephony: Trunks menu. Bundles A bundle is a group of lines of the same type and direction. A line can only be assigned to one bundle. Network PBX 1 PBX 3...
Page 144: Numbering
A default entry in the numbering table makes it possible to seize a “default route” for all remaining unassigned numbers. In particular, this simplifies configuration of the Forum 525/526 as a subsidiary system: the only entry you assign to the default entry is the route to the host system...
Page 145: Technical Details
Technical Details A different PBX number must be set for each Forum 525/526 in a PBX network. This setting can be found in the Web console, in the menu Telephony: Settings under the heading QSIG linking. You can also set the maximum value for the transit counter there.
Page 146 Technical Details Tip: If, for example, you are configuring a route which can be seized using routing code “5” and have selected one or more bundles for this route, change the Prefix for dest. call number at incoming internal setting to “5” for this bundle in order to enable the route to be reseized.
Page 147: Telephony
Telephony E.164 conversion The Forum 525/526 communications system supports two different types of call numbers when dialling external call numbers. Usually you enter the code for a route, e. g. a “0” for the “external line” route. Then you enter an external call number.
Page 148 E.164 conversion Call the Telephony: Settings page. Click on the Change button. Enter the country code without a zero in front into the International area code field, e. g. “49” for Germany. The setting in the Own area code field is not relevant for the “E.164 conversion”...
Page 149: Example
E.164 conversion Example The following example explains the “E.164 conversion” function on a terminal which is operated on an external line with the following configuration: Attribute Number International area code (Country Code, CC) (Belgium) Local area code (National Destination Code, NDC) (Brussels) Access call number 4444...
Page 150: Further Information
E.164 conversion Number dialled Number actually used 0024444888 (Internal) The local area code and the access call number are deleted. The destination is called internally without using the ISDN connector / SIP trunk. +3224444888 You can only enter the plus sign (after E.123) with a SIP telephone (see Internal SIP Subscribers starting on page 95).
Page 151: Call Forwarding
Call Forwarding Call Forwarding The current version of the Forum 525/526 communications system also offers configuration of multi-level call forwarding. When you forward a call number that has already been forwarded, this results in a call forwarding chain. Call Forwarding Chain Multiple call forwarding is executed independent of the call forwarding type.
Page 152: Attributes
Call Forwarding Call forwarding Name Description Call forwarding by a system Call forwarding via Forum Auto Attendant user (with the Connect to phone number and Connect to voicebox function) or via Forum Voicemail (with the secretarial function) Attributes A call forwarding chain can contain any call forwarding types and call forwarding users.
Page 153: Virtual Call Numbers
Call Forwarding place, e. g. by the Indicate call forwarding after time parallel setting in the user group, the call is cleared when there is a loop. Loop Detection A loop is also detected during call diversion. When you wish to divert an incoming call to a destination call number which is already part of the call forwarding chain, the display shows NEG.
Page 154 Call Forwarding ● Parallel setting: all users of the hunt group are called simultaneously. ● Linear, Cyclical or Statistical setting: the users of a time-dependent hunt group are call successively. The user called first is determined by the respective setting. The users of a hunt group can also configure their own respective call forwarding.
Page 155: External Call Forwarding
Call Forwarding External Call Forwarding You can also forward calls to external destinations without restriction. However, the call forwarding history cannot be continued with external destinations. When multiple users of a parallel hunt group configure call forwarding to external destinations, a single call to the hunt group can also occupy multiple external lines.
Page 156: Busy Keys
The call can be retrieved with the busy key. Busy keys on the system network Busy keys on the Forum 525/526 communications network are realised as a subscriber model. A busy key requests busy information to do so. The destination of a busy key keeps a dynamic list of terminals which have to be reported when there is a status change.
Page 157: Pin Code Telephony
PIN Code Telephony using busy keys on the system network (see PBX Networking starting on page 133). Please note the following points: ● Busy key information can be transferred via all connection types of a PBX system networking: Q.SIG-ISDN, Q.SIG-IP and SIP-Tie-Line. The Protocol extension option has to be activated in the bundle configuration for Q.SIG- ISDN.
Page 158: Configuration
You can configure the “PIN Code Telephony” feature separately for each company. Configuration is done with the following steps: 1. Call the Forum 525/526 communications system Configurator. On the introductory page, change the Level option to Expert. 2. Open the User manager: User groups menu page. Click on the New button.
Page 159: Switch Authorisation
You can configure the “Switch authorisation” feature separately for each company. Configuration is done with the following steps: 1. Call the Forum 525/526 communications system Configurator. On the introductory page change the Level option to Expert. 2. Open the User manager: User groups menu page. Click on the New button.
Page 160: Implementation
Switch authorisation desired. Activate the Immediate External line seizure option as desired. Deactivate the Switch authorisation option to prevent authorisation from being activated for an additional call in an unauthorised manner. Confirm with Apply. 4. Click on the user group for the user who is to execute the “Switch authori- sation”...
Page 161: Generating Your Own Moh Files
The MoH file must be coded with 8000 Hz, 8 bit mono in accordance with CCITT, A-Law. This coding is required for the Forum 525/526 and can be set in the “Sound Recorder” when you save the file under Format (CCITT, A-Law) and Attributes (8000 Hz, 8 bit mono).
Page 162: Installing And Deinstalling The Kda Manager
Installing and Deinstalling the KDA Manager The following guide is for the Proximus service technician. There are multiple language versions of the KDA Manager program package on the product CD of the Forum 525/526 communications system in the …\Forum directory. Installing the KDA Manager 1.
Page 163: Hunt Group Calls
With the Forum 525/526 communications system, you can use licence-free standard hunt groups and additional licensed comfort hunt groups (feature Forum Comfort Hunt Group). Up to 20 standard hunt groups and up to 10 comfort hunt groups can be configured.
Page 164 Additional features of comfort hunt groups ● Calls that cannot be accepted are parked in a call queue. ● Music on hold can be played for the caller during the waiting time. ● It is possible to configure welcome tracks that inform the caller that they will either be immediately connected to a group member or that they must wait a while before their call can be accepted.
Page 165: Setting Up Hunt Groups
Setting Up Hunt Groups Setting Up Hunt Groups Hunt groups are set up and managed on the web console of the communications system in the Configurator, menu Telephony: Groups: Hunt groups. Example: Configuration dialog for a comfort hunt group Configure the internal call number of the hunt group (Hunt group no.) and give the group a name (Name).
Page 166 Other settings are required, depending on the hunt group call type selected. A detailed description of the other input fields can be found in the online help for the Forum 525/526 communications system. The following chapters provide information about aspects that are important to consider when configuring hunt groups.
Page 167: Call Queue For A Comfort Hunt Group
Call Queue for a Comfort Hunt Group Call Queue for a Comfort Hunt Group A call queue can only be configured in connection with a (licensed) comfort hunt group. Callers who cannot currently be assigned to a group member because all logged-in members are busy are parked in the call queue. Once members are available to accept calls, hunt group calls will be assigned to them from the call queue.
Page 168 Call Queue for a Comfort Hunt Group Example: Forum Phone 536, signalling a comfort hunt group call that is currently assigned to the member Legend 1 Name /call number of the caller (401) and call number of the relevant hunt group /name of the user to which the hunt group call number is assigned (Customer service) 2 Waiting time of caller 3 Name of the comfort hunt group through which the call is coming...
Page 169: Welcome Tracks For A Comfort Hunt Group
Welcome Tracks for a Comfort Hunt Group Call queue of a comfort hunt group and local queues If a (local) call queue is configured for the internal call number of a group member's terminal, the group member is assigned the calls parked in their local queue first.
Page 170: Last Group Member Logoff
(when busy, after a certain amount of time, immediately). Note: Multi-level call forwarding can be configured in the Forum 525/ 526 communications system. For information regarding this, please refer to the chapter entitled Call Forwarding starting on page 149.
Page 171: Configuring Music On Hold
Configuring Music on Hold member who has since logged back in. After waiting for an hour, the caller receives a busy signal. In the event that a hunt group becomes busy, call forwarding can be programmed so that the caller is directed to an alternative destination (please refer to the chapter entitled Forwarding Hunt Group Calls starting on page 167).
Page 172 Configuring Music on Hold As soon as a caller has been assigned to a member of the comfort hunt group, the music on hold that is assigned to the caller (subscriber A) is used again in consultation, hold and parking situations. It also possible for the music on hold in the call queue and the music on hold that is used in case of consultations to differ.
Page 173: Configuring Group Member Terminals
Configuring Group Member Terminals Configuring Group Member Terminals Group members can log into and out of hunt groups in various ways: ● Using programmed function keys (possible on U , IP and SIP system phones or softphones) ● Using the device menu (possible on U , IP and SIP system phones, soft- phones and DECT system terminals) ●...
Page 174 Configuring Group Member Terminals ● In the case of a standard hunt group, the key is labelled with the internal hunt group call number and the internal call number of the group member, e.g. HG no.: 798/402. ● In the case of a comfort hunt group, the key is labelled with the group name, e.g.
Page 175: Enabling Operation Via "Forum Cti
“Forum CTI” application to log into and out of hunt groups. The application can be used in connection with any terminal that can be used on the Forum 525/526 communications system, i.e. by group members using a DECT terminal or an analogue phone.
Page 176: Particular Features Of Hunt Group Calls
Particular Features of Hunt Group Calls Particular Features of Hunt Group Calls Users must be familiar with the following features for hunt group calls in order to use the feature correctly. Features of standard and comfort hunt groups ● A group member can forward an accepted hunt group call to another subscriber like any other call.
Page 177: Team Functions
Introduction Team Functions Introduction With the team functions you can manage your telephone communication tasks by assigning lines with separate call numbers to the keys of different terminals. The terminal users, or team members, can thus pick up one another’s calls or telephone each other using the configured keys. Team functions can only be configured on the Forum Phone 516/526/536, Forum Phone 515/525/535 and Forum IPhone 525/535 system telephones because only these have the required features.
Page 178 Introduction Number of available call keys Telephone Number of keys Forum Phone 525 or 36 additional keys without a display Forum Phone 535 with an Up to three of these key extensions can be additional key extension used with a Forum Phone 525/ Forum 500 Keypad Paper Forum Phone 535.
Page 179: Team Configuration
Team Configuration You can create teams and programme call keys in the Configurator of the Forum 525/526 (Telephony: Groups and Telephony: Ports: Upn menu). Call key 1 is preset as a trunk key on all system telephones. This setting can be changed by the system administrator.
Page 180: Examples Of Use
Examples of Use Examples of Use The following examples illustrate the various uses of teams and team functions. For information on the display texts and how to use the individual functions, refer to the chapter “Managing Calls in a Team” in the „Forum Phone 516, 526, 536”...
Page 181 Examples of Use Call numbers 11 and 10 are both configured as a trunk key on the executive’s and the secretary’s terminal respectively. Thus the executive and the secretary can use either call number (for answering as well as making calls). Each can act as a substitute for the other.
Page 182: Three-Member Team
Examples of Use Three-member Team The three-member team described here is an example of a team configuration within a project group, e.g. export sales. Each team member has one Forum Phone 525 system telephone with all call keys programmed as trunk and team keys. Miller TrK 10: Miller TK 11: Johnson...
Page 183: Unified Team
Examples of Use Call signalling In this example, calls via the trunk keys are signalled acoustically. Calls via the team keys are indicated by a visual signal (the team key LED flashes). Unified Team The unified team described here is an example of a team configuration within a department in which calls are to be managed quickly (e.g.
Page 184: Toggle Team
Examples of Use telephone, he can accept the call. For further information on function keys, refer to the „Forum Phone 516, 526, 536” or “Forum Phone 515, 525, 535” user guide. Line busy indication If a line is busy, e.g. TrK 11 Johnson, the trunk keys on the other team telephones will indicate this.
Page 185 Examples of Use Call signalling In this example, calls via trunk keys are signalled acoustically. Calls via team keys are indicated by a visual signal (the team key LED flashes). Miller 14:22 Mi.14.Feb.07 TrK 10: Support 1 TrK 11: Support 2 TrK 12: Support 3 TrK 13: Support 4 TrK 14: Support 5...
Page 186: Call Queue
If more than one telephone number with a queue is configured on the telephone, the total number of entries are displayed. Calls in a queue are handled by the Forum 525/526 in the following order of priority: instant connection, door calls, automatic recalls, VIP calls, then other internal and external calls.
Page 187: Activation Of Queues
As calling fax machines often operate with the “voice” service indicator (e.g. on analogue ports), you should assign ports for fax machines on the Forum 525/526 to a user group without a queue. Queues can be combined with the “call forwarding,” “pickup” and “hunt group”...
Page 188: Pickup
Examples of Use queue when the call forwarding function is activated, these calls can only be accepted on the source terminal. If a call is to be forwarded “After delay”, it enters the queue. If the call has not been answered before the delay period expires, it will be forwarded to the target terminal and can then be answered there.
Page 189 Examples of Use ● Configure the Forum Free 567/577/587under Telephony: Devices: DECT phones and assign the Forum Free its own telephone number. Check in the Forum Free. ● Under Telephony: Call distribution: Incoming or Telephony: Call distri- bution: Incoming DDI route all incoming calls to the number of the Forum Phone 535trunk key.
Page 190: Group Of Three Enquiry Stations
Examples of Use Group of Three Enquiry Stations The enquiry stations switch all incoming calls. Incoming calls are administered in queues. Depending on the number of arriving calls, one to three enquiry stations in this group are manned. The enquiry stations are each equipped with a Forum Phone 535.
Page 191 Examples of Use stations. The display at each enquiry station (Forum Phone 535) indicates how full the queue is. If attendants leave the station, they sign off from the hunt group by means of a feature key. In contrast to Example 1, further calls do not have to be processed after the sign-off, as the calls are also registered in the queues of the other signed-on enquiry stations.
Page 192: Multi-Company Variant
The Forum 525/526 hardware and software are used equally by all the companies, however. It is possible to configure the Forum 525/526 for each company and define the extent to which the features of the system may be used.
Page 193: Configuring The Multi-Company Variant
(see Allocating Routing Codes starting on page 193). 5. An exchange must be set up for each company so that the Forum 525/ 526 can correctly process statuses in which a call should be routed to the exchange (see Configuring the Company Exchange starting on page 193).
Page 194: Assigning Users
(the users) via the lines of a certain bundle of the Forum 525/526, each of the available bundles must be assigned to one of the companies. This is necessary to be able to transfer incoming external calls to the correct company exchange in cases where the called internal subscriber cannot be reached, for example.
Page 195: Allocating Routing Codes
“source” principle. Charges are billed to the company to which the user belongs who set up the connection. The Forum 525/526 recognises this on the basis of the assignment between user groups and companies and on the basis of the routing code with which a line of the bundle/SIP trunk was seized.
Page 196: Working With The Multi-Company Variant
Working with the Multi-Company Variant All the features of the Forum 525/526 which the users may already be familiar with from the single-company variant are available in the multi- company variant. These features can be used to the same extent and can be used in exactly the same way.
Page 197: Making Calls Between Companies
Foreign telephone books can only be edited in the Configurator in the Phone Book menu. The number of entries in a company telephone book is unrestricted. The Forum 525/526 can manage up to 2000 entries in all telephone books (in the central, personal and company telephone books). Making Calls Between Companies All users of the Forum 525/526 can make internal calls to one another, irrespective of which company they belong to.
Page 198: Configuring The Pc Software
Forum Hotel You can simplify the daily use of the Forum CTI and Forum Hotel Web applications using the Web browser especially adapted for the Forum 525/ 526. Each time the workstation computer is restarted, this browser programme can automatically start and log you in. This means that the applications are always operational and can be accessed using the icon in the information area of the task bar.
Page 199: Synchronising The Pc Clock
GMT (Greenwich Mean Time) required for SNTP: 1. Go to the Configurator, System: Common menu. Click on Change. 2. Enter the Time zone for which the time of the Forum 525/526 applies and whether summer time is allowed for. Confirm this with Apply. Configuring SNTP For various operating systems, you can use one of the numerous SNTP programmes offered for downloading on the Internet.
Page 200 Synchronising the PC Clock SNTP with Windows Here you configure the SNTP server by double-clicking on the time in the Start bar. Enter the Forum 525/526 as the Server in the Internet time tab. Configuring the PC Software...
Page 201: Application Interfaces
Remote Switching Application Interfaces The Forum 525/526 communications system supports a series of application interfaces which are used by external systems to access functions of the communications system. Communication between the external system and the Forum 525/526 communications system is principally transported via the LAN connection or using the IP network protocol.
Page 202 Remote Switching ● The Forum 525/526 communications system can participate in the field bus communication. This way, for instance, it is possible to make the occupied status of a terminal visible. Bus participants are configured by means of a separate software, the ETS tool.
Page 203: Configuration
● current configuration of the remote switching IP router; ● current status of the connection between the Forum 525/526 communi- cations system and the remote switching IP router: – A tick indicates that the connection is established. – A cross indicates that the connection could not be established yet.
Page 204 IP router in the Configurator, menu Network > DHCP. 3. Port 1, Port 2: By default, the usual port numbers are set for the connection between the Forum 525/526 communications system and the remote switching IP router. Usually, you can apply the default values.
Page 205 1. Action: Enter a name for the action (max. 20 characters). This name serves as an assignment criterion for connecting the action with a terminal or an application of the Forum 525/526 communications system. 2. Type: Select the Switch with timeout setting.
Page 206 LED (also see the Configuring the Key LED Function on the System Phone starting on page 205 chapter). 6. Timeout: This timer controls the time span after which the Forum 525/ 526 communications system sends the opposite command to bus partic- ipant.
Page 207 System Phone starting on page 205 chapter). 6. Time for pulse and Time for pause: With these time values, the Forum 525/526 communications system controls the flashing rhythm when flashing is switched on (Command = on of Command = switch over): –...
Page 208: Applications
Remote Switching Applications Using the Remote switching function, the following applications can be set up on the Forum 525/526 communications system: ● Perform action on Device free / Device busy ● Perform action if the ACD queue reaches a critical size (queue indication changes to red or from red to yellow or green).
Page 209 Remote Switching Perform Action when ACD Queue Full In combination with the integrated application Forum ACD the remote Remote switching function allows for an action if the ACD queue reaches a critical size. One application example would be to install a warning lamp in the agents' pause room, that starts flashing once the call queue indication turns to red.
Page 210 Remote Switching Configuring the remote switching action on a system phone Application Interfaces...
Page 211: Csta Interface
Applications” (CSTA, phase 3 based on ECMA-269 and ECMA-285 (BER) / ECMA-323 (XML), phase 2 based on ECMA-217 and ECMA-218) external programs and applications can access services of the Forum 525/526 communications system via network connection. The CSTA interface provides...
Page 212: Setting Up Tapi Interface
With a TAPI (Telephony Application Programming Interface) you can operate a CTI application (Computer Telephony Integration). Here, the CTI application uses the services of the Forum 525/526 with the help of the TAPI driver installed on a Windows PC. Many telephony functions, such as enquiry, toggling, three-party conference, pick-up, call protection and call forwarding can be controlled using appropriate TAPI-compatible software.
Page 213 Forum 525/526. Using the […] button you can search for this in the LAN. In the boxes Username and Password you enter the user data of one of the users configured on the Forum 525/526. This user must be allocated a system terminal. Confirm your entry with OK.
Page 214: Ldap Interface
Directory information can be transferred using the LDAP protocol. A central service (LDAP server) manages a comprehensive, hierarchically organised directory which can be queried by an LDAP client via LDAP. The Forum 525/ 526 communications system supports two different LDAP applications: ●...
Page 215: Querying External Ldap Server
4. Check the function. In the Edit menu, call up the Find: People command. The Find: People dialogue box will then open. 5. In the Look in list, select the entry with the Forum 525/526 address. Enter a user in the Name input field, Administrator for example. Then click on Find now.
Page 216 LDAP Interface of the LDAP server into the Server entry field. The online help of the Forum 525/526 communications system provides detailed descriptions of the other entry fields. 3. Use Apply to confirm your settings. An LDAP server can be configured to saved various types of information which are available in a tree-like data structure.
Page 217 ● Each individual LDAP-queried record is reserved for a definable time in a Forum 525/526 communications system cache (setting: Delete cache in minutes, 50 cache entries per company each with a separate time counter per entry). You should shorten this time (e. g. to 10 minutes) if, for example, the assignment of guests and room telephones in a hotel is managed via the LDAP server.
Page 218 After authorisation via a license key, the Forum Name program offers a LDAP service which can be queried by the Forum 525/526 communications system. The Forum Name program provides you with the following features: ●...
Page 219: Snmp Interface
You can integrate the Forum 525/526 communications system into the SNMP-based network management. There is a Windows service program for this (“SNMP Agent”). The SNMP Agent communicates with the Forum 525/ 526 communications system via the CSTA interface. The status information queried via the CSTA interface is forwarded by the SNMP Agent to the network management software.
Page 220: Configuring Snmp
The SNMP Agent requires the IP address of the SNMP Manager for operation. System messages in the form of SNMP Traps are sent to this IP address. You manage the IP address of the SNMP Manager in the Forum 525/526 communications system configurator.
Page 221: Frequently Asked Questions
This chapter provides tips and information on how to deal with any malfunctions or faults you may experience with the Forum 525/526. Please note:Repairs to the Forum 525/526 should only be carried out by qualified personnel. The following LEDs indicate that the Forum 525/526 is ready for operation:...
Page 222: Telephony
Telephony If not, contact your service centre. The AC adapter plug of the Forum 525/ 526 may be defective. Question: After restarting the Forum 525/526, nothing is indicated on the displays of any connected terminals. It takes a short while for the Forum 525/526 to start up.
Page 223 Question: One of the features (e.g. call diversion) on one of the tele- phones cannot be used even though the feature has been configured in the Configurator of the Forum 525/526. Make sure the user configured for this telephone belongs to a user group that has access to this feature (Configurator, User manager: User and User groups menus).
Page 224: Pbx Networking
PBX Networking Question: An ISDN telephone always rings, if another telephone on the bus is being called. This case also requires configuring the MSN on the ISDN telephone (see above answer). Question: It is not possible to configure Call Distribution: Outgoing for multi-terminal access.
Page 225: Dect
DECT Question: Why is it not possible to reach a communications system indi- rectly via another communications system? You have interconnected e.g. three communications system with two Q.SIG- IP / SIP tie line connections. While configuring the routes, you applied the default “Business”...
Page 226: Lan
Check whether the LEDs for the switch and the PC’s network card are indicating a connection. Check the LEDs for the LAN functions of the Forum 525/526. The green LAN LED at the top indicates whether the network cable has been properly connected.
Page 227: Internet
Internet Question: You have just configured the Forum 525/526 via the network. Why is it not possible now to establish a remote data transfer network connection? The network card and the communication (remote data transfer) adapter cannot be run with the same routing setting. Deactivate the network card before connecting via the dial-up network.
Page 228 You need to activate the SIP support at your internet router, such as “SIP- ALG” or “Full Cone NAT” functions. You can also use the Forum 525/526 for internet access. Correct the STUN setting in the Telephony: Trunks: SIP Provider menu.
Page 229: Forum Phone 51X/52X/53X: Extensions And Accessories
Power Supply Unit Forum Phone 51x/52x/53x: Extensions and Accessories Power Supply Unit The power supply unit 90035810 is required in the following cases: ● when connecting a key extension to a Forum Phone 52x/53x system tele- phone (see also the chapter Key Extensions starting on page 227) ●...
Page 230 The number of key extensions connected to a system telephone (up to three) can be set in the Configurator of the Forum 525/526’s Web Console (in the menu Telephony: Ports: Upn or Telephony: Devices: VoIP phones). Here the keys can also be programmed as call keys or assigned functions or destination call numbers.
Page 231 Key Extensions The maximum distance between the connecting socket that the telephone/ key extension device combination is operating through and the Forum 525/ 526 must be less than 1000 metres. You will need a plug-in power supply unit no. 90035810 to provide power. The power supply unit is plugged into the last in the series of key extensions.
Page 232: Headset
Headset This symbol on the system telephone indicates the connector for the key extension. It is on the underside of the telephone. This symbol on the key extension indicates the connector for a further key extension. This symbol on the key extension indicates the connector for the power supply unit and is on the underside of the device.
Page 233 Headset Connecting a headset to a system telephone The connector for the headset is in the bottom of the system telephone’s casing and is indicated by this symbol 1. Plug the RJ45 jack on the headset cable into the socket provided. 2.
Page 234: Technical Specifications
Technical Specifications System data Mains power supply 230 V ~ 50 Hz Rated power 160 VA Safety class Permissible temperatures, stationary, +5 °C to +40 °C weatherproofed Dimensions (W x H x D) 396 x 390 x 100 mm Weight (system only) 3.2 kg ports Euro ISDN switchable (S...
Page 235 1.2 VA – Feed current 25 mA – Range 1,000 m V.24 port / COM (Forum 525 Card serial interface) for connection of a PC 1 x (optional) – Range Doorstation equipment interface card (Forum 525 Card double doorphone) for connection of doorstation...
Page 236: Environmental Information
Environmental Information ● The equipment that you bought has required the extraction and use of natural resources for its production. It may contain hazardous substances for the health and the environment. ● In order to avoid the dissemination of those substances in our environment and to diminish the pressure on the natural resources, we encourage you to use the appropriate take-back systems.
Page 237: Index
Index preconfiguration 59 preparation 55 Actor remote configuration 60 See Intercom system 44 resetting the system data 64 Actor/sensor port 40 saving and loading the Analogue a/b ports 40 configuration 59 Authorisations 16 starting the Web console 56 system prerequisites 54 via V.24 port 11 Base station 118 Configuration examples 66...
Page 238 Doorstation equipment interface configuring function keys 171 card 30 configuring terminals 171 DSL 41 distribution strategy 163 DSL port 41 last group member login/ DSS1 134 logoff 168 DTMF 87 music on hold 169 operation 171 potential faults (comfort hunt groups) 173 E.123 96 Hunt groups...
Page 239 LDAP 212 Ports Local area code 145 actor/sensor 33 doorstation equipment 33 LAN 44 LAN (basic module) 33 Media Gateway 90 positions 34 Memory card 34 S2M 45 MGW 90 , 44 V.24 33 hardware 91 Ports (see Interfaces) 37 , 133 Multi-terminal access 10 Power failure 41...
Page 240 SIP 88 , 92 , 93 external 80 V.24 add-on card 33 , 95 internal 81 V.24 interface card 30 SIP system telephones 98 VAD 90 SIP (external) 13 Virtual call numbers SIP (internal) 13 call forwarding 151 SIP entrance intercom systems 104 Voice Activity Detection 90 , 139 SIP tie line 13...
Page 241 Notes Index...
Page 242 Notes Index...
Page 243 Support You can contact our support on the following telephone numbers: For configuration changes of your Forum™ 500 or Forum™ 5000 communications system SMEs and residential Large companies customers in Dutch: 0800 22 500 0800 22 200 in French: 0800 33 500 0800 33 200 in German: 0800 44 500...
Page 244 For more information: ● Visit us in the Internet at www.proximus.be/pabx ● Contact your Proximus dealer Subject to changes Status 06.2017...

This manual is also suitable for:

Forum 526

Proximus Forum 525 Mounting And Commissioning

Quick Links

Related Manuals for Proximus Forum 525

Summary of Contents for Proximus Forum 525
