DR. BENDER
GmbH
Innovative Elektrowerkzeuge
Manual for
drilling motor
EBL 33 F
230 V
Valid from 07.2018
Art.-Nr.
201287
Subject to alterations
All rights reserved
DR. BENDER
GmbH • D-75382 Althengstett • Tel 07051-9291-0 • Fax 07051-9291-91
Our website address is: http://www.dr-bender.de
info@dr-bender.de
• eMail:
Advertisement
Table of Contents
Related Manuals for DR. BENDER 201287
Summary of Contents for DR. BENDER 201287
- Page 1 DR. BENDER GmbH Innovative Elektrowerkzeuge Manual for drilling motor EBL 33 F 230 V Valid from 07.2018 Art.-Nr. 201287 Subject to alterations All rights reserved DR. BENDER GmbH • D-75382 Althengstett • Tel 07051-9291-0 • Fax 07051-9291-91 Our website address is: http://www.dr-bender.de info@dr-bender.de...
-
Page 2: Conformity Declaration
EN 61029-1 The instructions contained in the operating manual for installation and start up the machine have to be fol- lowed. Authorised Person for Documentation: Min Wei c/o Dr. Bender GmbH Industriestrasse 22 75382 Althengstett Deutschland DR.BENDER GmbH Althengstett, 30.07.2018 Industriestraße 22... -
Page 3: Table Of Contents
Contents page Conformity declaration Contents Symbol- and Pictograph description Function description General instructions Application Safety Transport and storage Transport Storage Main dimensions and technical data Dimensions Technical data Noise emissions and vibrations [EN 50144] Commissioning Changing gear Safety coupling Core bits To change a core bit Safety instructions Servicing and care... -
Page 4: Symbol- And Pictograph Description
Warning The safety instructions set out in this operating manual must be followed at all costs. Special designs and versions may differ from the standard models in terms of their technical de- tails. If any points are unclear, we urgently recommend that you contact DR.BENDER GmbH, indi- cating the machine type and machine number. -
Page 5: General Instructions
General instructions Application The core drills can be used for the purposes outlined by the data on the model plate. If you are using spe- cial machines, the details in the quotation and order confirmation also apply. The core drills are supplied as standard in protection class I, only this can guarantee the full high quality production of the residual current-operated circuit-breaker or PRCD switch. -
Page 6: Transport And Storage
Transport and storage Transport Warning The core drills are to be checked for signs for transport damage on receipt. Any damage must be documented in writing. Storage If possible, the storage site should be dry, clean and have a constant temperature. To ensure that the film of lubricant in the bearings and sealing system is not lost, the motor shaft should be turned through several revolutions by hand after a lengthy period of storage, for example at monthly intervals. -
Page 7: Main Dimensions And Technical Data
Main dimensions and technical data Dimensions Technical Data Rated Voltage Current consumption 10,5 Power requirement 2500 Frequency 50 – 60 Idling speed 720 / 1890 / 3960 Full speed 450 / 1200 / 2500 Output rating 1590 Torque 36 / 19 / 10 Drilling diameter 20 –... -
Page 8: Commissioning
Commissioning Check that the mains voltage is identical with the voltage specified on the model plate. Stand-mounted: Secure the core drilling machine and the water collection device on the drill stand with a reverse lock. The drill stand should have high rigidity and precise, low-play guides. Ensure that the core drilling machine axis is parallel to the drill stand axis. -
Page 9: Changing Gear
Changing gear Warning Never change gear using force and only do so when the machine is slowing down or at a standstill. Move the gear switch handle by approx. 40° to the next higher or lower gear. If necessary (if it is difficult to engage the gear) turn the drive spindle briefly by hand until the gear engages easily. -
Page 10: Safety Instructions
Safety instructions Important Only use the core drill under supervision. Disconnect the mains plug and check that the switch has been turned off, if you intend to leave the core drill unsupervised, for attachment and disconnection work, if the voltage drops (below 200 V), for adjustments or for fitting an accessory, Switch off the machine if it stops for any reason. -
Page 11: Servicing And Care
Servicing and care Warning Before starting any servicing or repair work always disconnect the mains plug. After all repairs you must have the core drilling machine inspected by an electri- cian (statutory regulation pursuant to VBG4 since 1.1.1990). Daily care Ensure that no water escapes from the overflow hole. -
Page 12: Speed Adjustment Dependent On The Cutting Speed
Speed adjustment dependent on the cutting speed [m/s] 3820 5093 6366 7639 8913 3rd gear 2900 3820 4775 5730 6685 3rd gear 2500 2900 3820 4584 5348 3rd gear 1910 2500 2900 3820 4456 3rd gear 3274 3820 1637 2183 2728 3rd gear 1400... -
Page 13: Warranty
Warranty In keeping with our terms of sale, we offer a warranty for twelve months from the date of sale. This refers to the free repair of material and workmanship defects, which were verifiably caused before the sale. An original purchase document must always be submitted in case of a warranty claim. It has to contain the full address of the dealer, the date of purchase and the type designation of the product. -
Page 14: Spare Parts List
11.0 Spare parts list 11.1 Stone drilling machine complete EBL 33 F... - Page 15 Item Art. No. Description 201287 Stone drilling machine complete EBL 33 F 200983 Motor complete 302529 Gear complete 800076 Locking ring 901358 Hexagon socket head cap screw 802980 Water connection complete 1 ** 802981 Hose complete 800028 Sealing ring 800023...
-
Page 16: Motor Complete Ebl 33 F
11.2 Motor complete EBL 33 F... - Page 17 Item Art. No. Description 200983 Motor complete EBL 33 F 200397 Motor casing 401165 Magnet casing 402164 Distance ring 402251 Force ring 401320 Brush bridge 800076 Spring washer 901225 Allen bolt 800948 Carbon brush 2 ** 900183 Spring washer 900407 Cheese-head screw 900231 Washer...
-
Page 18: Gear Complete
11.3 Gear complete... - Page 19 Item Art. No. Description 302529 Gear complete 200570 Gear casing 900486 Grooved ball bearing 1 ** 800483 Compensation slice 100723 Control grip 801367 O ring 401038 Sleeve 401036 Switch handle complete 801755 Slotted cheese head screws 900020 Shaft sealing ring 1 ** 900019 Shaft sealing ring...
-
Page 20: Connection Cables And Accessories
11.4 Connection cables and accessories... - Page 21 Item Article number Description Plugs for UK and standards for type EBM 801462 Connection cable compl. 4h 900159 Plug, 4h 801328 Connection cable, finished Plugs for UK and standards for type BBM 801460 Connection cable compl. 4h 900159 Plug, 4h 801459 Connection cable, finished Plugs for USA and Japan up to 30 amps for type BBM...
