Manual for
drilling motor
115 V
Valid from 01.2006
All rights reserved
DR. BENDER
Our website address is: http://www.dr-bender.de
GmbH
Art.-Nr.
GmbH • D-75382 Althengstett • Tel 07051-9291-0 • Fax 07051-9291-91
EBM 25
EBM 25 F
EBM 25 S
200714
200715
200713
info@dr-bender.de
• eMail:
Subject to alterations
Advertisement
Table of Contents
Related Manuals for DR. BENDER EBM 25
Summary of Contents for DR. BENDER EBM 25
- Page 1 DR. BENDER GmbH Innovative Elektrowerkzeuge Manual for drilling motor EBM 25 EBM 25 F 115 V EBM 25 S Valid from 01.2006 Art.-Nr. 200714 Subject to alterations 200715 200713 All rights reserved DR. BENDER GmbH • D-75382 Althengstett • Tel 07051-9291-0 • Fax 07051-9291-91 info@dr-bender.de...
-
Page 2: Conformity Declaration
Innovative Elektrowerkzeuge EC Conformity Declaration for DR.BENDER stone processing machine EBM 25 EBM 25 F EBM 25 S DR.BENDER GmbH, as manufacturer, hereby declares that the electrical stone processing machine men- tioned above comply with the requirements of the following guidelines:... -
Page 3: Table Of Contents
Contents page Conformity declaration Contents Symbol- and Pictograph description Function description General instructions Application Safety Transport and storage Transport Storage Main dimensions and technical data Dimensions Technical data Noise emissions and vibrations [EN 50144] Commissioning Changing gear Safety coupling Core bits To change a core bit Safety instructions Servicing and care... -
Page 4: Symbol- And Pictograph Description
Warning The safety instructions set out in this operating manual must be followed at all costs. Special designs and versions may differ from the standard models in terms of their technical de- tails. If any points are unclear, we urgently recommend that you contact DR.BENDER GmbH, indi- cating the machine type and machine number. -
Page 5: General Instructions
General instructions Application Core drilling machines may be used in accordance with the data shown on the model plate. The details in the quotation and order confirmation also apply for the use of special machines. The core drilling machines generally comply with safety class I, this alone ensures the complete protection of the RCCB or PRCD. -
Page 6: Transport And Storage
Transport and storage Transport Warning The core drills are to be checked for signs for transport damage on receipt. Any damage must be documented in writing. Storage If possible, the storage site should be dry, clean and have a constant temperature. To ensure that the film of lubricant in the bearings and sealing system is not lost, the motor shaft should be turned through several revolutions by hand after a lengthy period of storage, for example at monthly intervals. -
Page 7: Main Dimensions And Technical Data
Main dimensions and technical data Dimensions Technical Data Rated Voltage Current consumption Power requirement 1800 Frequency 50 – 60 Idling speed 1750 / 4080 Full speed 1100 / 2600 Output rating 1300 Torque 15 / 6,5 Drilling diameter 20 – 80 Weight EBM 23 Weight EBM 23 S / EBM 23 F Core bit connection... -
Page 8: Noise Emissions And Vibrations [En 50144]
Noise emissions and vibrations [EN 50144] Noise level Noise level Vibration dB(A) < 2,5 Commissioning Check that the mains voltage is identical with the voltage specified on the model plate. Stand-mounted: Secure the core drilling machine and the water collection device on the drill stand with a reverse lock. The drill stand should have high rigidity and precise, low-play guides. -
Page 9: Changing Gear
Changing gear Warning Never change gear using force and only do so when the machine is slowing down or at a standstill. Move the gear switch handle by approx. 40° to the next higher or lower gear. If necessary (if it is difficult to engage the gear) turn the drive spindle briefly by hand until the gear engages easily. -
Page 10: Safety Instructions
Safety instructions Important Only use the core drill under supervision. Disconnect the mains plug and check that the switch has been turned off, if you intend to leave the core drill unsupervised, for attachment and disconnection work, if the voltage drops (below 100 V), for adjustments or for fitting an accessory, Switch off the machine if it stops for any reason. -
Page 11: Servicing And Care
Servicing and care Warning Before starting any servicing or repair work always disconnect the mains plug. After all repairs you must have the core drilling machine inspected by an electri- cian (statutory regulation pursuant to VBG4 since 1.1.1990). Daily care Ensure that no water escapes from the overflow hole. -
Page 12: Speed Adjustment Dependent On The Cutting Speed
Speed adjustment dependent on the cutting speed [m/s] 4775 6366 7958 9549 11141 2.Gang 4093 5457 6821 8185 9549 2.Gang 3581 4775 5968 7162 8356 2.Gang 3183 4244 5305 6366 7427 2.Gang 2865 2.Gang 3820 4775 5730 6685 2604 3472 4341 5209 6077... -
Page 13: Warranty
Warranty In keeping with our terms of sale, we offer a warranty for six months from the date of sale. This refers to the free repair of material and workmanship defects, which were verifiably caused before the sale. An original purchase document must always be submitted in case of a warranty claim. It has to contain the full address of the dealer, the date of purchase and the type designation of the product. -
Page 14: General Safety Instructions
10.0 General safety instructions Read and follow these instructions before you use the tool. Keep these safety instructions in a safe place. Keep your workplace tidy. Untidiness in the workplace can cause accidents. Protect yourself from electric shocks. Refer to the applicable regulations. Avoid physical contact with earthed parts, such as pipes, heaters, furnaces and refrigerators. - Page 15 Check the machine every day for signs of damage, conduct a visual inspection: Before reusing the tool, carefully check the safety equipment or slightly damaged parts to ensure that they offer perfect and proper function. Check that all moving parts function correctly, that they do not jam and that none of the parts are damaged.
-
Page 16: Spare Parts List
11.0 Spare parts list 11.1 Motor complete EBM 25... - Page 17 Item Art. No. Description Motor complete 200397 Motor casing 401117 Magnet casing 401426 Brush bridge 800076 Locking washer 900339 Hexagon socket head cap screw 801425 Carbon brush 2 ** 900183 Spring washer 900407 Cheese-head screw 401099 Bearing cap complete 200549 Bearing cap 401098 Insulation...
-
Page 18: Motor Complete Ebm 23 F
11.2 Motor complete EBM 25 F... - Page 19 Item Art. No. Description Motor complete 200397 Motor casing 401117 Magnet casing 801426 Brush bridge 800076 Locking washer 900339 Hexagon socket head cap screw 801425 Carbon brush 2 ** 900183 Spring washer 900407 Cheese-head screw 401099 Bearing cap complete 200549 Bearing cap 401098 Insulation...
-
Page 20: Motor Complete Ebm 23 S
11.3 Motor complete EBM 25 S... - Page 21 Item Art. No. Description Motor complete 200397 Motor casing 401117 Magnet casing 801426 Brush bridge 800076 Locking washer 900339 Hexagon socket head cap screw 801425 Carbon brush 2 ** 900183 Spring washer 900407 Cheese-head screw 200569 401098 Insulation 1 ** 200812 Handle complete 801226...
-
Page 22: Gear Complete
11.4 Gear complete... - Page 23 Item Art. No. Description 300911 Gear complete 200391 Gear casing 100723 Control grip 1 ** 801367 O ring 401038 Sleeve 401036 Switch handle complete 900623 Fillister self-tapping screw 900020 Shaft sealing ring 1 ** 900019 Shaft sealing ring 2 ** 800001 Locking ring 1 **...
-
Page 24: Connection Cables And Accessories
11.5 Connection cables and accessories... - Page 25 Item Article number Description Plugs (no more permitted) Schuko 800256 Connection cable compl. 800265 Plug 800583 Connection cable, finished Plugs for Germany, France, Italy PRCD 801244 Connection cable compl. 800265 Plug 800853 Safety switch 801236 Connection cable – S compliant 801245 Connection cable –...
