DR. BENDER
Innovative Elektrowerkzeuge
Manual for
drilling motor
230 V
Valid from 03.2018
All rights reserved
DR. BENDER
Our website address is: http://www.dr-bender.de
GmbH
Art.-Nr.
GmbH • D-75382 Althengstett • Tel 07051-9291-0 • Fax 07051-9291-91
EBM 33
EBM 33 F
EBM 33 S
200940
200942
200944
• eMail:
Subject to alterations
info@dr-bender.de
Advertisement
Table of Contents
Related Manuals for DR. BENDER 200940
Summary of Contents for DR. BENDER 200940
- Page 1 DR. BENDER GmbH Innovative Elektrowerkzeuge Manual for drilling motor EBM 33 EBM 33 F 230 V EBM 33 S Valid from 03.2018 Art.-Nr. 200940 Subject to alterations 200942 200944 All rights reserved DR. BENDER GmbH • D-75382 Althengstett • Tel 07051-9291-0 • Fax 07051-9291-91 Our website address is: http://www.dr-bender.de...
-
Page 2: Conformity Declaration
EN 61029-1 The instructions contained in the operating manual for installation and start up the machine have to be fol- lowed. Authorised Person for Documentation: Min Wei c/o Dr. Bender GmbH Industriestrasse 22 75382 Althengstett Deutschland DR.BENDER GmbH Althengstett, 30.07.2018 Industriestraße 22... -
Page 3: Table Of Contents
Contents page Conformity declaration Contents Symbol- and Pictograph description Function description General instructions Application Safety Transport and storage Transport Storage Main dimensions and technical data Dimensions Technical data Noise emissions and vibrations [EN 50144] Commissioning Changing gear Safety coupling Core bits To change a core bit Safety instructions Servicing and care... -
Page 4: Symbol- And Pictograph Description
Warning The safety instructions set out in this operating manual must be followed at all costs. Special designs and versions may differ from the standard models in terms of their technical de- tails. If any points are unclear, we urgently recommend that you contact DR.BENDER GmbH, indi- cating the machine type and machine number. -
Page 5: General Instructions
General instructions Application The core drills can be used for the purposes outlined by the data on the model plate. If you are using spe- cial machines, the details in the quotation and order confirmation also apply. The core drills are supplied as standard in protection class I, only this can guarantee the full high quality production of the residual current-operated circuit-breaker or PRCD switch. -
Page 6: Transport And Storage
Transport and storage Transport Warning The core drills are to be checked for signs for transport damage on receipt. Any damage must be documented in writing. Storage If possible, the storage site should be dry, clean and have a constant temperature. To ensure that the film of lubricant in the bearings and sealing system is not lost, the motor shaft should be turned through several revolutions by hand after a lengthy period of storage, for example at monthly intervals. -
Page 7: Main Dimensions And Technical Data
Main dimensions and technical data Dimensions Technical Data Rated Voltage Current consumption Power requirement 2200 Frequency 50 – 60 Idling speed 830 / 2200 / 4600 Full speed 520 / 1400 / 2900 Output rating 1300 Torque 27 / 12 / 6 Drilling diameter 15 –... -
Page 8: Noise Emissions And Vibrations [En 50144]
Noise emissions and vibrations [EN 50144] Noise level Noise level Vibration dB(A) < 2,5 Commissioning Check that the mains voltage is identical with the voltage specified on the model plate. Stand-mounted: Secure the core drilling machine and the water collection device on the drill stand with a reverse lock. The drill stand should have high rigidity and precise, low-play guides. -
Page 9: Changing Gear
Changing gear Warning Never change gear using force and only do so when the machine is slowing down or at a standstill. Move the gear switch handle by approx. 40° to the next higher or lower gear. If necessary (if it is difficult to engage the gear) turn the drive spindle briefly by hand until the gear engages easily. -
Page 10: Safety Instructions
Safety instructions Important Only use the core drill under supervision. Disconnect the mains plug and check that the switch has been turned off, if you intend to leave the core drill unsupervised, for attachment and disconnection work, if the voltage drops (below 200 V), for adjustments or for fitting an accessory, Switch off the machine if it stops for any reason. -
Page 11: Servicing And Care
Servicing and care Warning Before starting any servicing or repair work always disconnect the mains plug. After all repairs you must have the core drilling machine inspected by an electri- cian (statutory regulation pursuant to VBG4 since 1.1.1990). Daily care Ensure that no water escapes from the overflow hole. -
Page 12: Speed Adjustment Dependent On The Cutting Speed
Speed adjustment dependent on the cutting speed [m/s] 3820 5093 6366 7639 8913 3rd gear 2900 3820 4775 5730 6685 3rd gear 2292 2900 3820 3rd gear 4584 5348 1910 2546 2900 3820 4456 3rd gear 1637 2183 2728 3274 3820 3rd gear 1400... -
Page 13: Warranty
Warranty In keeping with our terms of sale, we offer a warranty for twelve months from the date of sale. This refers to the free repair of material and workmanship defects, which were verifiably caused before the sale. An original purchase document must always be submitted in case of a warranty claim. It has to contain the full address of the dealer, the date of purchase and the type designation of the product. -
Page 14: General Safety Instructions
10.0 General safety instructions Read and follow these instructions before you use the tool. Keep these safety instructions in a safe place. Keep your workplace tidy. Untidiness in the workplace can cause accidents. Protect yourself from electric shocks. Refer to the applicable regulations. Avoid physical contact with earthed parts, such as pipes, heaters, furnaces and refrigerators. - Page 15 Check the machine every day for signs of damage, conduct a visual inspection: Before reusing the tool, carefully check the safety equipment or slightly damaged parts to ensure that they offer perfect and proper function. Check that all moving parts function correctly, that they do not jam and that none of the parts are damaged.
-
Page 16: Spare Parts List
11.0 Spare parts list 11.1 Stone drilling machine complete EBM33... - Page 17 Item Art. No. Description 200940 Stone drilling machine complete EBM33 200939 Motor complete 300887 Gear complete 800076 Locking washer 901012 Hexagon socket head cap screw 802980 Water connection complete 1 ** 802981 Hose complete 800028 Sealing ring 800023 Ball cook complete...
-
Page 18: Stone Drilling Machine Complete Ebm33 F
11.2 Stone drilling machine complete EBM33 F... - Page 19 Item Art. No. Description 200942 Stone drilling machine complete EBM33 F 200941 Motor complete 300887 Gear complete 800076 Locking washer 901012 Hexagon socket head cap screw 802980 Water connection complete 1 ** 802981 Hose complete 800028 Sealing ring 800023 Ball cook complete 800020 Slot-in nipple 800040...
-
Page 20: Stone Drilling Machine Complete Ebm33 S
11.3 Stone drilling machine complete EBM33 S... - Page 21 Item Art. No. Description 200944 Stone drilling machine complete EBM33 S 200943 Motor complete 300887 Gear complete 800076 Locking washer 901012 Hexagon socket head cap screw 802980 Water connection complete 1 ** 802981 Hose complete 800028 Sealing ring 800023 Ball cook complete 800020 Slot-in nipple 800040...
-
Page 22: Motor Complete Ebm
11.4 Motor complete EBM 33... - Page 23 Item Art. No. Description 200939 Motor complete 200397 Motor casing 401300 Magnet casing 400888 Brush bridge 800076 Locking washer 900339 Hexagon socket head cap screw 800948 Carbon brush 2 ** 900183 Spring washer 900407 Cheese-head screw 900231 Washer 900181 Spring washer 900412 Flat head screw 300892...
-
Page 24: Motor Complete Ebm 33 F
11.5 Motor complete EBM 33 F... - Page 25 Item Art. No. Description 200941 Motor complete 200397 Motor casing 401300 Magnet casing 400888 Brush bridge 800076 Locking washer 900339 Hexagon socket head cap screw 800948 Carbon brush 2 ** 900183 Spring washer 900407 Cheese-head screw 900231 Washer 900181 Spring washer 900412 Flat head screw 401101...
-
Page 26: Motor Complete Ebm 33 S
11.6 Motor complete EBM 33 S... - Page 27 Item Art. No. Description 200943 Motor complete 200397 Motor casing 401300 Magnet casing 401315 Brush bridge 800076 Locking washer 900339 Hexagon socket head cap screw 800948 Carbon brush 2 ** 900183 Spring washer 900407 Cheese-head screw 900231 Washer 900181 Spring washer 900412 Flat head screw 301075...
-
Page 28: Gear Complete
11.7 Gear complete... - Page 29 Item Art. No. Description 300887 Gear complete 200570 Gear casing 900020 Shaft sealing ring 1 ** 900019 Shaft sealing ring 2 ** 800001 Locking ring 1 ** 900000 Grooved ball bearing 1 ** 800559 Locking ring 1 ** 301213 Drill spindle complete, 1 ¼“ / R ½“ optional 900013 Compression spring 900014...
-
Page 30: Connection Cables And Accessories
11.8 Connection cables and accessories... - Page 31 Item Article number Description Plugs for UK and standards for type EBM 801462 Connection cable compl. 4h 900159 Plug, 4h 801328 Connection cable, finished Plugs for UK and standards for type BBM 801460 Connection cable compl. 4h 900159 Plug, 4h 801459 Connection cable, finished Plugs for USA and Japan up to 30 amps for type BBM...
