  • Page 1 Portable photovoltaic energy storage power station HBP1800 1-3KW Please download the software “SolarPowerMonitor2.2.81”. Download link: https://en.must-ee.com 4200-100001-00A1...
  • Page 3: Table Of Contents

    Contents Manual Basic Information....................1 Usage ..........................1 scope ..........................1 SAFETY INSTRUCTIONS ....................1 Product introduction ......................2 Features.......................... 2 Basic system structure......................2 Product Overview ......................3 Installatio......................... 4 Unpacking and Inspection....................4 prepare..........................4 Install equipment......................4 PV board connection......................
  • Page 4: Manual Basic Information

    About the Manual Scope: This manual describes the assembly, installation, operation and troubleshooting of this equipment. Please read this manual carefully before installation and operation. Retain this manual for future reference. This manual provides safety and installation guidelines and information on tools and wiring . The following situations are not covered by the warranty : (1) Overdue the warranty period .
  • Page 5: Product Introduction

    Product Description This is a multi-functional photovoltaic energy storage power station, integrated with battery, MPPT solar charge controller, high frequency pure sine wave inverter and UPS function module into one , which is suitable for outdoor backup electric compartment and spontaneous self-use system . MPPT solar charge controller adopts advanced MPPT method and intelligent battery management...
  • Page 6: Product Overview

    Product Description USB 5V DC 12V 1. LCD display 7. AC input 2. Status Indicator 8. PV input 3. Charge/discharge Indicator 9. AC output 4. Indicator light 10. Switch 5. Function Button 11. DC5V USB output AC input over-current protection 12.
  • Page 7: Installatio

    Installation Unpacking and Inspection Check the equipment before installation. Make sure nothing in the package damages the product . The followingcontainsincluded: Machine X 1 User Manual X 1 Mains input line X 1 Preparation Before turning on the device, please reserve a distance of more than 30CM above the device and to the left and right to ensure for heat dissipation.Input andOutput Connection 1.
  • Page 8: Pv Board Connection

    PV Panel Connection Please choose the appropriate wire according to the matching photovoltaic panel. PV module selection : When choosing the right PV module, be sure to consider the following parameters: 1. The open-circuit voltage (VOC) of the PV module does not exceed the maximum open-circuit voltage of the PV array of the inverter.
  • Page 9: Operation

    Operation On/Off USB 5V Once the unit is installed correctly,batteries is connected.The unit could be turned on by simply pressing the on/off button (the button on the chassis). Operating and Display Panels The operation and display panel shown in the following figure is located on the front panel of the inverter.
  • Page 10: Lcd Display Icon

    LCD Display Icons Icon Function description Input Source Information and Output Information Indicates the AC information. Indicates the DC information. Indicate input voltage, input frequency, PV voltage, battery voltage and charger current. Indicate output voltage, output frequency, load in VA, load in Watt and discharging current.
  • Page 11 In battery mode, it will present battery capacity. Load Percentage Battery Voltage LCD Display < 1.717V/cell 1.717V/cell ~ 1.8V/cell Load >50% 1.8 ~ 1.883V/cell > 1.883 V/cell < 1.817V/cell 1.817V/cell ~ 1.9V/cell 50%> Load > 20% 1.9 ~ 1.983V/cell > 1.983V/cell <...
  • Page 12: Lc D Settings

    LCD Setting After pressing and holding "ENTER" button for 2 seconds, the unit will enter setting mode. Press "UP"or "DOWN" button to select setting programs. And then, press "ENTER" or "MENU" button to confirm the selection and exit. Setting Programs: Program Description Selectable option...
  • Page 13 Appliances (default) If selected, acceptable AC input voltage range will be within 90- 280VAC. If selected, acceptable AC input voltage range will be within AC input voltage range 170-280VAC. If selected, acceptable AC input voltage range will conform to VDE4105(184VAC-253VAC) When the user uses the device to connect the generator, select the generator mode.
  • Page 14 Only Solar Solar energy will be the only charger source no matter utility is available or not. If this inverter/charger is working in Battery mode or Power saving mode, only solar energy can charge battery. Solar energy will charge battery if it's available and sufcient.
  • Page 15 Battery stop discharging Setting range is from 22.0V to 23V (default) voltage when grid is 29.0V available Increment of each click is 0.1V Available options for 24V models: Battery stop charging 27.0V (default) Setting range is from 22.0V to voltage when grid is 29.0V.
  • Page 16 Battery equalization Battery equalization disable(default) Battery equalization 28.8V (default) Battery equalization voltage Setting range is from 24.0V to 29.2V. Increment of each click is 0.1V. Setting range is from 5 min to 60min(default) 900min. Battery equalization time Increment of each clink is 5min. 120min(default) Setting range is from 5 min to 900min.
  • Page 17: Fault Reference Code

    Fault Reference Code Fault Code Fault Event Icon on Fan is locked when inverter is off Inverter transformer over temperature battery voltage is too high battery voltage is too low Output short circuited Inverter output voltage is high Overload time out Inverter bus voltage is too high Bus soft start failed Main relay failed...
  • Page 18 Inverter grid under frequency Inverter grid over frequency Inverter over current protection error Inverter bus voltage is too low Inverter soft start failed Over DC voltage in AC output Battery connection is open Inverter control current sensor error Inverter output voltage is too low -15-...
  • Page 19: Warning Indicators

    Warning Indicator Icon on Fault Code Fault Event Fan is locked when inverter is on. Fan 2 is locked when inverter is on. Battery is over-charged. Low battery. Overload. Output power derating. Solar charger stops due to low battery. Solar charger stops due to high PV voltage. Solar charger stops due to over load.
  • Page 20: Operating State Description

    Operating State Description Operation state Description LCD display PV is on PV energy is charger Utility-Tie state into the battery and utility provide power to the AC load. PV is off Charge state PV energy and grid can charge batteries. Bypass state Error are caused by inside circuit error or...
  • Page 21: Display Settings

    Display Setting The LCD display information will be switched in turns by pressing "UP" or "DOWN" key. The selectable information is switched as below order: battery voltage, battery current ,inverter voltage, inverter current, grid voltage, grid current, load in Watt, load in VA, grid frequency, inverter frequency, PV voltage, PV charging power, PV charging output voltage, PV charging current.
  • Page 22: Specifications

    SPECIFICATIONS Table 1 Line Mode Specifications MODEL HBP18-1012 HBP18-2024 HBP18-3024 Rated Power Waveform Pure Sine Wave INVERTER AC Voltage Output 230Vac Rated Batterry 12VDC 24VDC Input Voltage Efficiency Max PV Current MPPT Tracking PV Input 98%max Efficiency Max PV Array Open 75VDC 100VDC 145VDC...
  • Page 24 GUARANTEECERTIFICATE GUARANTEECERTIFICATE...
