- Page 1 CORDLESS POLE TRIMMER HELPN40V-A WARNING: Read thoroughly the instruction manual before use.
- Page 2 SAFETY WARNINGS General Power Tool Safety Warnings WARNING Read all safety warnings and all instructions. Failure to follow the warnings and instructions may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term "power tool" in the warnings refers to your mains-operated (corded) power tool or battery-operated (cordless) power tool.
- Page 3 f) Dress properly. Do not wear loose clothing or jeweler. Keep your hair, clothing and gloves away from moving parts. Loose clothes, jeweler or long hair can be caught in moving parts. g) If devices are provided for the connection of dust extraction and collection facilities, ensure these are connected and properly used.
- Page 4 Before felling, check where the trees or branches are going to fall. Make sure that there are no obstacles to prevent or hinder the fall. Do not work in areas where the grass is wet and where the soil is slippery. Do not use this tool in a tree, on an unstable ladder or surface.
- Page 5 Inspect the tool before use and after dropping or other impacts in order to identify any significant damage or defects. In case of damages or dysfunction, do not use the tool and bring it to a qualified service for inspection and reparation. There is danger of using this machine near overhead electric power lines.
- Page 6 Read instruction manual and follow all warnings and instructions Remove battery when servicing and maintenance Do not expose the tool to rain and humidity Do not saw with the tip of the saw head. Do not use the tool with only one hand Always hold the tool with two hands Be aware about the risk of saw head back.
- Page 7 Guaranteed sound power level PRODUCT Description Technical data Volume of oil tank 50 ml Cutting attachment Saw chain Guide bar Vibration ˂ 2,5 m/s² k= 1,5 m/s² Guarantee sound power level 92 dB(A) Measured sound power level 88,3 dB(A) K=3 dB(A) Sound pressure level 74,6 dB(A) K=3 dB(A) Weight...
- Page 8 of the need to identify safety measures to protect the operator that are based on an estimation of exposure in the actual conditions of use (taking account of all parts of the operating cycle such as the times when the tool is switched off and when it is running idle in addition to the trigger time). Wear hearing protection.
- Page 9 Removing battery pack Press and hold the latch button at the bottom of the battery pack. Remove battery pack from the pole saw. Shoulder strap Hang the harness in its dedicated location on the tube. Adjust the size of the harness properly to have a correct working position.
- Page 10 NOTE: Do not use dirty, used or contaminated oil. Damage may occur to the bar or chain. NOTE: It is normal for oil to seep from the saw when not in use. To prevent seepage, empty the oil tank after each use then run for one minute. When storing the unit for a long period of time (three months or longer) be sure that the chain is lightly lubricated.
- Page 11 NOTE: For second and final cuts (from top of limb of branch), hold font cutting guide against the limb being cut. This will help steady the limb and make it easier to cut. Allow chain to cut for you. Exert only low downward pressure. If you force the cut, damage to the bar, chain or motor can result.
- Page 12 MAINTENANCE AND STORAGE Before inspecting, cleaning or servincing the unit, stop the motor, wait for all moving parts to stop, and remove the battery pack. Failure to follow these instructions can result in serious personal injury or properly damage. Maintenance must be provided after each use. Improper or lack of maintence may cause dysfunction of the tool, reduction of the performance, kickback of the chain, injuries and accidents.
- Page 13 Using light but firm pressure, stroke towards the front corner of the tooth. Lift file away from the steel on each return stroke. Put a few firm strokes on every tooth. File all left hand cutters in one direction. Then move to the other side and file the right hand cutters in the opposite direction.
- Page 14 DISPOSAL Disposal of an exhausted battery pack To preserve natural resources, please recycle or dispose of the battery pack properly. Consult your local waste authority for information regarding available recycling and/or disposal options. Discharge your battery pack by operating your tool, then remove the battery pack from the tool and cover the battery pack connections with heavy duty adhesive tape to prevent short circuit and energy discharge.
-
Page 15: Declaration Of Conformity
BUILDER SAS ZI, 32, rue Aristide Bergès – 31270 Cugnaux - France Tel: +33 (0)5.34.502.502 Fax: +33 (0)5.34.502.503 Declare that the machine CORDLESS POLE TRIMMER HELPN40V-A Serial number: 20201135588-20201135737 Is in conformity with the following standards EN 60745-1:2009+A11:2010 EN ISO 11680-1:2011... -
Page 16: Warranty
WARRANTY WARRANTY The manufacturer guarantees the product against defects in material and workmanship for a period of 2 years from the date of the original purchase. The warranty only applies if the product is for household use. The warranty does not cover breakdowns due to normal wear and tear. The manufacturer agrees to replace parts identified as defective by the designated distributor. -
Page 17: Product Failure
PRODUCT FAILURE WHAT TO DO IF MY MACHINE BREAKS DOWN? If you bought your product in a store: a) Empty the fuel tank. b) Make sure that your machine is complete with all accessories supplied, and clean! If this is not the case, the repairer will refuse the machine. -
Page 18: Warranty Exclusions
WARRANTY EXCLUSIONS THE WARRANTY DOES NOT COVER: • Start-up and setting up of the product. • Damage resulting from normal wear and tear of the product. • Damage resulting from improper use of the product. • Damage resulting from assembly or start-up not in accordance with the user manual. •...
