- Page 1 ® Field I/O SIO-MB04RTDS USER GUIDE Temperature Input Module: RTD, 4-channel Manual Number: SIO-MB04RTDS-UG...
-
Page 2: Register Addresses
Stride Field I/O GENERAL DESCRIPTION Modbus data is mapped in tables and assigned an address. Data can be of two types: • REGISTER, 2 bytes (word of 16 bits) that can be associated to an analog input or output, a variable, a setpoint, etc. •... - Page 3 Stride Field I/O PRODUCT LABEL AND WIRING DIAGRAM Terminal block pinouts and wiring diagrams are printed on the side of the module, as shown below. SIO-MB04RTDS User Guide, 1st Edition...
- Page 4 Stride Field I/O DESCRIPTION OF MODBUS REGISTERS 40002 / 40003: FIRMWARE Two read-only registers, containing the firmware version. 40007: NODE ID Contains the Modbus address of the device; the values allowed are from 1 to 245 decimal. This value must match the Modbus address of the connected Modbus device (data source). Default value: 1 Decimal (01 Hex).
- Page 5 Stride Field I/O 40033: INPUT TYPE CHANNEL 2 INPUT TYPE TABLE This register shows the type of sensor configured for this input (see “Input Type Table”). Type Value (Hex) Default: Pt100 (0D Hex) Disabled 15 14 13 12 11 10 09 08 07 06 05 04 03 02 01 00 Resistor 0–2000 Ohm Description Input Type #2...
- Page 6 Stride Field I/O WEB SERVER STRUCTURE Login Screen To access the server, open the web browser and enter the IP address of the device. Our examples use Chrome screen captures. Browsers may differ slightly. Enter the Username and Password. • Default username: admin •...
- Page 7 Stride Field I/O Network Settings On the Network Settings page, set the Ethernet communication parameters. • IP Address: set the IP address of the device. • Subnet Mask: set the subnet mask to match the local network. • Gateway Mask: set the default gateway. A default gateway allows this device to communicate with devices on another subnet. •...
-
Page 8: System Configuration
Stride Field I/O System Configuration On the System Configuration page, set the basic system parameters. • Name: set a helpful name to identify this device; max 15 alphanumeric characters. • Modbus Address: set the Modbus address of this device; the default value is 1. In INIT mode this value is temporarily set to 245. •... - Page 9 Stride Field I/O Software Update When a software upgrade is required, click Upgrade. • Upgrade: opens a dialog to enter credentials, select a file from the local PC and proceed with the update. • Firmware Version: shows the firmware version loaded on the device. •...
- Page 10 Stride Field I/O Username and Password Set the user name and password. • Username: set the user name to access the device. Default “admin”. • Password: set the password to access the device. Default “password”. Click Save to apply and store the modified parameters. SIO-MB04RTDS User Guide, 1st Edition...
-
Page 11: Analog Input
Stride Field I/O Analog Input This page displays the values of the analog inputs in the unit of measurement defined by the “Input Type”. Each input is electrically isolated from all others and can be configured independently. • Read: retrieves current value and break status from the device for all channels. •... - Page 12 Stride Field I/O INIT, RESET AND WATCHDOG FUNCTIONS INIT Function The INIT function facilitates access to a device when there is a problem accessing it at its configured IP address. The configured username and password are required for INIT access. The INIT terminal is adjacent to the power terminals.
