Simpli Home WyndenHall brooklyn + max AXCWSH16-RUS Manual

Warm shaker / norfolk / lexington tv media stand
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
SIMP
I
HOME
®
I
L I F E B Y D E S I G N
WARM SHAKER / NORFOLK / LEXINGTON
TV MEDIA STAND
MODEL #
AXCWSH16-RUS
1/23

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WyndenHall brooklyn + max AXCWSH16-RUS and is the answer not in the manual?

Questions and answers

Related Manuals for Simpli Home WyndenHall brooklyn + max AXCWSH16-RUS

Summary of Contents for Simpli Home WyndenHall brooklyn + max AXCWSH16-RUS

  • Page 1 SIMP HOME ® L I F E B Y D E S I G N WARM SHAKER / NORFOLK / LEXINGTON TV MEDIA STAND MODEL # AXCWSH16-RUS 1/23...
  • Page 2 SIMP HOME ® L I F E B Y D E S I G N Questions, problems, assembly help, missing parts? No need to return the product, we will gladly help and ship your replacement parts free of charge Please call Customer Service at 1-866-518-0120 ext. 262 Monday to Friday between 9 am –...

  • Page 3: Safety Information

    IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. SAFETY INFORMATION CAUTION: Injuries and damage can occur from furniture tip over if product is not properly anchored to the wall. Use the Furniture Anti-Tipping Restraint provided with the product.

  • Page 4: Care And Maintenance

    IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. CARE and MAINTENANCE Perhaps the greatest environmental damage to wood furniture comes from wide swings in relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity rises and falls, and in doing so it swells and shrinks.

  • Page 5: Pre-Assembly Information

    PRE-ASSEMBLY INFORMATION MODEL # AXCWSH16-RUS PARTS DESCRIPTION LEFT SIDE RIGHT SIDE QTY 1 QTY 1 QTY 1 CENTRE SHELF BOTTOM SUPPORT LEFT DIVIDER QTY 1 QTY 1 QTY 1 RIGHT DIVIDER DOOR (L&R Same) CENTRE DRAWER GLIDE QTY 1 QTY 2 QTY 1 NEED HELP? For help with assembly or if you are missing a part, Please call customer service at 1-866-518-0120 ext.
  • Page 6 PRE-ASSEMBLY INFORMATION MODEL # AXCWSH16-RUS PARTS DESCRIPTION SHELF SHELF CABINET BACK PANEL QTY 2 QTY 2 QTY 1 Warning Label LEFT BACK PANEL RIGHT BACK PANEL BACK PANEL QTY 1 QTY 1 QTY 1 LEFT DRAWER SIDE RIGHT DRAWER SIDE DRAWER FRONT QTY 2 QTY 2...

  • Page 7: Hardware Description

    PRE-ASSEMBLY INFORMATION MODEL # AXCWSH16-RUS HARDWARE DESCRIPTION CAM LOCK PIN ALLEN KEY SCREW ALLEN KEY CAM LOCK M6 X 30 mm QTY 1 QTY 16 SETS QTY 32 PHILLIPS SCREW PHILLIPS SCREW M4 X 15 mm M3 X 15 mm MAGNET AND PLATE QTY 2 SETS QTY 24...
  • Page 8 COMPONENTS – KEY DIAGRAM MODEL # AXCWSH16-RUS 8/23...
  • Page 9 ASSEMBLY MODEL # AXCWSH16-RUS STEP 1 1. Attach 4 Cam Lock Pins 2 to back of Drawer Front M . 2. Align and insert Cam Lock Pins into guide holes on Drawer Sides NL , NR . 3. Insert 2 Cam Lock 2 into guide holes on each Drawer Side NL , NR . 4.
  • Page 10 ASSEMBLY MODEL # AXCWSH16-RUS STEP 3 1. Align Drawer Back O with Drawer Bottom P and press firmly into slot . 2. Attach back using 2 Allen Key Screws 1 through guide holes on each side. 3. Use Allen Key 3 to tighten. Do not over-tighten. STEP 4 NOTE: The screwdriver is not included in the hardware pack.
  • Page 11 ASSEMBLY MODEL # AXCWSH16-RUS STEP 5 1. Attach Dividers EL , ER to Bottom Shelf C using four Allen Key Screws 1 through guide holes. 2. Use Allen Key 3 to tighten. Do not over-tighten. STEP 6 1. Attach three Cam Lock Pins 2 to Right Side BR using pre-drilled holes. 2.
  • Page 12 ASSEMBLY MODEL # AXCWSH16-RUS STEP 7 1. To attach Left Side BL to Bottom Shelf C , repeat steps 1 - 4 in Step 6. STEP 8 1. Attach two Cam Lock Pins 2 to bottom of Bottom Shelf C using guide holes in centre. 2.
  • Page 13 ASSEMBLY MODEL # AXCWSH16-RUS STEP 9 1. Attach Bottom Support D to Sides BL , BR and Centre Drawer Glide G using Allen Key Screws 1 through guide holes. 2. Use Allen Key 3 to tighten. Do not over-tighten. 13/23...
  • Page 14 ASSEMBLY MODEL # AXCWSH16-RUS STEP 10 1. Insert two Dowels 11 into top corners of each Side BL , BR . 2. Use rubber mallet to tap Dowels 11 into bottom of holes securely. 1/2 length of Dowels should be exposed. 3.
  • Page 15 ASSEMBLY MODEL # AXCWSH16-RUS STEP 11 Note: The back of the cabinet frame does not have pre-drilled holes to attach the back panels. Warning Label 1. Attach Back Panels J , KL , KR , L to back of TV Stand using Phillips Round Head Screws 9 through guide holes from panels.
  • Page 16 ASSEMBLY MODEL # AXCWSH16-RUS STEP 12 1. Attach Adjustable Hinges 12 to Doors F using Phillips Screws 4 into pre-drilled holes on Doors F . 2. Attach Adjustable Hinges on Doors F to Sides BL , BR using Phillips Screws 4 into pre-drilled holes on Sides BL , BR .

  • Page 17: Important Note

    ASSEMBLY MODEL # AXCWSH16-RUS IMPORTANT NOTE: Tighten the Screw marked II to fasten hinge. The door may need to be adjusted so that all the spaces between the door and the unit sides are equal. To adjust, follow instructions: 1. Side adjustment 4 mm To move the door towards the side panel, loosen screw I and tighten screw II .
  • Page 18 ASSEMBLY MODEL # AXCWSH16-RUS STEP 13 1. Attach Magnet Plates 6 to bottom corner of Doors F using Phillips Screws 5 into pre-drilled holes on Doors F . 2. Attach Magnets 6 using Phillips Screws 5 into pre-drilled holes on Centre Shelf C . 3.
  • Page 19 ASSEMBLY MODEL # AXCWSH16-RUS STEP 14 shelf level 1 shelf support anti - tipping shelf level 2 shelf level 3 1. Use Shelf Supports 7 for each Shelf H or I in desired location. 2. Two Shelf Supports 7 may be used on back top of each Shelf H or I as a tipping restraint.
  • Page 20 ASSEMBLY MODEL # AXCWSH16-RUS STEP 15 1. Insert assembled drawers into glides on assembled TV 20/23...
  • Page 21 FURNITURE TIP OVER RESTRAINT ASSEMBLY WARNING Serious or fatal crushing injuries can occur from furniture tip-over. If the furniture tip over restraint kit is not in the box, please contact our customer service department in order to obtain another kit before using the furniture. NOTE: The screwdriver is not STEP 16 included in the hardware pack.
  • Page 22 FURNITURE TIP OVER RESTRAINT ASSEMBLY Furniture Tip Over Restraint Instructions: Attach one of the mounting brackets securely to the back edge of the furniture. Use the shorter screw. Determine where furniture is to be placed and mark location on the wall for mounting bracket screw hole approximately 2 inches below the bracket mounted to the furniture.

  • Page 23: Warranty

    L I F E B Y D E S I G N WARRANTY Thank you for purchasing a Simpli Home – Wyndenhall – Brooklyn + Max product. These products have been made to demanding, high-quality standards and are guaranteed for domestic use against manufacturing faults for a period of 12 months from the date of purchase.
