- Page 1 Warm Shaker / Norfolk / Lexington Low Storage Cabinet Model # AXCWSH14-RNAB...
- Page 2 Great quality is a right. Thank you for shopping with Simpli Home, America's top brand for high-value furniture. It's time to register your product warranty. It's quick and easy. And you'll be happy you did. ü Activate your 1-year warranty ü...
- Page 3 Review your product and collect rewards! Thank you for your purchase! We hope you enjoy it. We’d love your feedback. Please share a review and get instant rewards! simpli-home.com/product-review Share photos and get your cash back! Send us images or share them on social and qualify for instant rewards.
- Page 4 For Fastest Customer Service: Open your phone’s camera. Point your phone’s camera at the QR code to scan. Click on the pop up. You’ll be taken to our customer service page. Fill the form with your order information and issue. Submit form.
-
Page 5: Safety Information
IMPORTANT : Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. Safety Information CAUTION: Injuries and damage can occur from furniture tip over if product is not properly anchored to the wall. Use the Furniture Anti-Tipping Restraint provided with the product. -
Page 6: Care And Maintenance
Care & Maintenance This furniture is designed for indoor use. Perhaps the greatest environmental damage to wood furniture comes from wide swings in relative humidity (RH) in our homes. Wood absorbs and desorbs water as relative humidity rises and falls, and in doing so it swells and shrinks. Making matters worse, it expands and contracts unequally along different grain directions. - Page 7 Pre-Assembly Information Model # AXCWSH14-RNAB Part Description LEFT SIDE RIGHT SIDE QTY 1 QTY 1 QTY 1 BOTTOM SHELF DIVIDER SHELF QTY 1 QTY 1 QTY 2 Warning Label LEFT DOOR RIGHT DOOR LEFT BACK PANEL RIGHT BACK PANEL QTY 1 QTY 1 QTY 1 QTY 1...
- Page 8 Pre-Assembly Information Model # AXCWSH14-RNAB Hardware Description CAM LOCK PIN WOOD DOWEL ALLEN KEY SCREW CAM LOCK M6 X 30mm ALLEN KEY Ø8 X 30mm QTY 6 SETS QTY 12 QTY 1 QTY 10 PHILLIPS SCREW HANDLE PHILLIPS SCREW ROUND HEAD M4 X 25 mm M3 X 15mm M4 X 15mm...
- Page 9 Components - Key Diagram Model # AXCWSH14-RNAB...
- Page 10 Assembly Model # AXCWSH14-RNAB Step 1 1. Insert 2 Dowels 3 into guide holes on Divider C . 2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. 1/2 length of Dowels should be exposed. 3. Attach Divider C to Bottom Shelf D using 3 Allen Key Screws 1 . 4.
- Page 11 Assembly Model # AXCWSH14-RNAB Step 2 1. Insert 4 Dowels 3 into guide holes on Bottom Shelf D ( 2 dowels on each side). 2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. 1/2 length of Dowels should be exposed.
- Page 12 Assembly Model # AXCWSH14-RNAB Step 3 1. Insert 2 Dowels 3 into guide holes on each Side BL , BR . 2. Use rubber mallet to tap Dowels 3 into bottom of holes securely. 1/2 length of Dowels should be exposed. 3.
- Page 13 Assembly Model # AXCWSH14-RNAB Step 4 Triangle ruler NOTE: The triangle ruler is not included in the hardware pack. Adjust the cabinet frame before assembling the back panels. Step 5 Note: Warning Label 1. Attach Back Panels GL , GR to back frame of storage using 18 Phillips Screws Round Head 5 through guide holes.
- Page 14 Assembly Model # AXCWSH14-RNAB Step 6 & 1. Attach Adjustable Hinges 11 to Doors FL , FR using Phillips Screws 10 into pre-drilled holes on Doors FL , FR . 2. Attach Adjustable Hinges on Doors FL , FR to Sides BL , BR using Phillips Screws 10 into pre-drilled holes on Sides BL , BR .
-
Page 15: Important Note
Assembly Model # AXCWSH14-RNAB IMPORTANT NOTE: Tighten the Screw marked II to fasten hinge. The door may need to be adjusted so that all the spaces between the door and the unit sides are equal. To adjust, follow instructions: 1. Side adjustment 4 mm To move the door towards the side panel, loosen screw I and tighten screw II . - Page 16 Assembly Model # AXCWSH14-RNAB Step 7...
- Page 17 Assembly Model # AXCWSH14-RNAB Step 8 shelf level 1 shelf support anti - tipping shelf level 2 shelf level 3 1. Use 4 Shelf Supports 6 for each Cabinet Shelf E in desired location. 2. 2 Shelf Supports 6 may be used on back top of each Cabinet Shelf E as a tipping restraint.
- Page 18 Furniture Tip Over Restraint Assembly WARNING Serious or fatal crushing injuries can occur from furniture tip-over. If the furniture tip over restraint kit is not in the box, please contact our customer service department in order to obtain another kit before using the furniture. NOTE: The screwdriver is not Step 9 included in the hardware pack.
- Page 19 Furniture Anti-Tipping Restraint Instructions Attach one of the mounting brackets securely to the back edge of the furniture. Use the shorter screw. Determine where furniture is to be placed and mark location on the wall for mounting bracket screw hole approximately 2 inches below the bracket mounted to the furniture.
