Specifications

Item
Operating Frequency Range 2400 MHz~2483.5 MHz
Transmitting Power 17dBm Max
Monitor Sensitivity -88dBm
Type of Spread Spectrum TX FHSS
Type of Modulation GFSK
Data Rate 3Mbps
Transmission range Max 250m
Weight Gross weight: 955g
Image Sensor Type 1/5" Color CMOS Image Sensor
Effective Pixel H: 640, V: 480
White Balance Auto
Lens EFL=3.0mm, F=2.5
Viewing Angle (Diagonal) 56 degree
IR LED Type/ Night Vision 8pcs IR LED – 940nm /5m
Loud Speaker Output 80dBA
Power Requirement DC 6V ±10%
Power Consumption 480mA Condition Night vision mode and talk back.
VOX level detection High: 50dBA / Low: 60dBA
Operating Temperature Range 0°C~+40°C
14 · Appendix
Details
System General
Wireless Camera
Item
Wireless Camera
Operating Humidity Range 85% RH
Environment Rating Indoor use only
Regulation Compliance FCC/CE
RoHS Compliance Yes for CE version only
Audio Built in Microphone/ Speaker
Weight 122g
Wireless Monitor
Display Type/Size Color TFT 4.3"
Resolution (Pixel) 480X272 (RGB)
Viewing Angle H: 80 degree, V: 100 degree
Number of Camera Support Up to 4 cameras
Power Requirement Adapter : DC 6V ±10%, Battery : 3.7V Li-polymer
Loud Speaker Output 80dBA
Loud Speaker Noise level 45dBA
Power Consumption 480mA maximum Condition Charging + Speaker with voice at volume 5
Operating Temperature Range 0°C~+40°C
Operating Humidity Range 85% RH
Environment Rating Indoor use only
Regulation Compliance FCC/CE
RoHS Compliance Yes for CE version only
Audio Built in Microphone/ Speaker
Other Special Feature Volume control, Pairing
Battery Type Li-on
Battery Capacity 1300mAh
Weight 186g
Details
