  • Page 1 RealVIEW User Manual SEW-3042W English...
  • Page 2 Disclaimer For wireless camera only(FCC ID: NLMSEB101BRWN) Samsung makes the best to verify the integrity and correctness of the contents in this To comply with FCC RF exposure compliance requirements, a separation distance of at least 20 document, but no formal guarantee shall be provided. Use of this document and the cm must be maintained between the antenna of this device and all persons.
  • Page 3 Do not use extension cords with the AC power adapters to avoid entanglement. Connect the equipment into an outlet on a circuit different from that to which the monitor is This product should only be serviced by qualified and authorized Samsung service centers. connected.
  • Page 4: Table Of Contents

    Contents WHAT’S INCLUDED INSTALLATION Package Contents ………………………………………………… 5 How to Install ……………………………………………………… 14 Wireless Monitor …………………………………………………………… 14 Wireless Camera …………………………………………………………… 14 GETTING STARTED Functional Description ……………………………………………… 6 APPENDIX Powering your monitor ……………………………………………………… 6 Specifications …………………………………………………… 15 Operating the System ……………………………………………………… 6 Troubleshooting …………………………………………………...
  • Page 5: What's Included

    ’ NCLUDED Package Contents The system comes with the following components: Wireless camera Wireless monitor User Manual & Warranty Card Camera Adapter Monitor Adapter Screws (2EA) & Plastic anchors (2EA) Check your package to confirm that you have received the complete system, including all components shown above. English ·...
  • Page 6: Getting Started

    ETTING TARTED Operating the System The basic operation is as follows: Functional Description Pairing The units already come paired for your convenience. This button is used to add an additional camera. User can select camera number Powering your monitor to assign. Up to 4 Cameras may be paired. After opening the box, fully charge the monitor before use.
  • Page 7 Voice activated (VOX) Sound level Select to monitor significant sound with reduced ambient noise. The louder the sound around the camera, the more LEDs turn on. The screen goes off in “VOX” mode if there is no significant sound louder than a certain level about 30 seconds. Meanwhile, the monitor screen turns on as soon as detecting sound around the camera.
  • Page 8: Viewing Mode Display

    IEWING ISPLAY e x1/x1.5/x2 Zoom mode Indicates that current screen is Zoomed in. Press [ ] icon on the monitor to zoom back out. Indicator Description f Night Vision Indicator Indicates camera night vision mode is turned on. The screen will appear in Black/White in this mode. How to use the indicator g VOX On ef g h i j...
  • Page 9: Menu Operation

    How to use the setup icon Menu Operation After configuring the settings, press the [ ] icon to save the changes. To return to the Live screen, press the [ ] icon. How to use the function tools a b c d Press the screen of the monitor to display the menu screen.
  • Page 10 e Camera VOX Sensitivity If not in “VOX” mode, [ ] icon is not displayed. In VOX mode, you can select “Low Sound Level Detection” or “High Sound Level Detection”. If set to “Low Sound Level Detection”, monitor can be triggered by lower audio level than “High Sound Level Detection”...
  • Page 11: Overview

    VERVIEW Getting to know your Monitoring system Wireless Monitor After opening the box, fully charge the monitor before use. After initial charge, recharge as needed. Front Controls Power LED Monitor Antenna When the monitor is being recharged or monitor has low Receives and sends signals from or to the camera.
  • Page 12 Back Controls Power On/Off Belt Clip Turn on/off the wireless monitor. When you carry the monitor, use the belt hanger to hold the monitor onto your belt. Kick Stand Speaker Use to hold the monitor onto a table. Produces the sound transmitted from the camera(s). DC 5V Power Input Connect the included AC power adapter to power and/or charge the monitor battery.
  • Page 13: Wireless Camera

    Wireless Camera Front & Back Controls IR LEDs Camera Antenna Infrared LED’s provide viewing in no / low light Sends & receives signals to or from the monitor. conditions. Microphone Speaker Receives sounds for the area near the camera, and Produces the sound transmitted from the monitor.
  • Page 14: Installation

    Carefully unpack the camera. NSTALLATION If you are installing cameras that did not come with the system, please see the pairing camera section of this manual for details on installation. Mount the camera to the wall. How to Install Mark the position of the screw holes on the wall, and drill holes and insert 2 screws, then firmly attach the CAUTION: If you use the system to watch a young child, do not place the camera in the camera to the wall by placing the stand over the...
  • Page 15: Appendix

    PPENDIX Item Details Operating Temperature Range 0°C~+40°C Operating Humidity Range 85% RH 5RGEK ECVKQPU Environment Rating Indoor use only Pan Angle Not support Item Details Tilt Angle 100° System General Regulation Compliance FCC/CE Operating Frequency Range 2400 MHz~2483.5 MHz RoHS Compliance Yes for CE version only Transmitting Power 16.6 dBm Max.
  • Page 16: Troubleshooting

    Item Details Troubleshooting Audio Built in Microphone/ Speaker Other Special Feature Volume control, Pairing Problem Solution Battery Type Li-on No picture from a 1. Check all connections to the camera. Make sure the adapter is plugged in. camera 2. Make sure that the cameras and monitor are both ON. Battery Capacity 2500mAh, Replaceble 3.
  • Page 17 Correct Disposal of This Product Samsung cares for the environment at all product manufacturing stages, and is taking measures to provide customers with more environmentally friendly products. (Waste Electrical & Electronic Equipment) The Eco mark represents Samsung devotion to creating environmentally friendly products, (Applicable in the European Union and other European countries with separate collection and indicates that the product satisfies the EU RoHS Directive.
  • Page 18 TEMPLATE This template is used to install Screw holes for the camera on the wall. the Camera installation 50,0 mm...
  • Page 19 MEMO...
  • Page 20 SAMSUNG TECHWIN AMERICA Inc. SAMSUNG TECHWIN EUROPE LTD. 100 Challenger Rd. Suite 700 Ridgefield Park, NJ 07660 Samsung House, 1000 Hillswood Drive, Hillswood Business Park Chertsey, Customer support : +1-877-349-3149 Surrey, UNITED KINGDOM KT16 OPS www.samsungsv.com Customer support : 00800-8010-8022...
