Date: 29.06.2016
Responsible: Uwe Laarmann
email: uwe.laarmann@kueppersbusch.de
KE 9600-1-2T / KE 9600-1-2T-CN
Power problems were identified in some of the SBS refrigerators with VNTU-type electronic units.
Models concerned: KE 9600-1-2T/KE 9600-1-2T-CN Production before March 2016
Product numbers 7292248782 and 7292248784
Solution
A new electronic unit with corresponding cables, spare-part no. 442556, must be installed in these
appliances. The electronic unit with spare-part no. 442102 (code number xxxxx0800) can no longer be
delivered. The electronic unit with spare-part no. 442557 (code number xxxxx3700 or xxxxx3701 or
xxxxx3702) serves as a replacement.
Production identification
Date
Production (Identification)
15-
100161
Year
Serial no.
The serial number begins with 10001 every year
The product code begins with 72.xxxx or 75.xxxx
Wiring spare-part no. 442556 comprises:
2 self-adhesive
blue dots
Tools required
Nur zum internen Gebrauch
Technical Information
Tel
Fax
Power Failures
Identifying the electronic code number
06
Month
1 cable (black) with
an AMP plug
Screwdriver
Sturdy needle or similar
+49 (0)209 401-732
+49 (0)209 401-743
1 1 cable connector
T8-94-03
Advertisement
Table of Contents
Related Manuals for Kuppersbusch KE 9600-1-2T
Summary of Contents for Kuppersbusch KE 9600-1-2T
- Page 1 Power Failures KE 9600-1-2T / KE 9600-1-2T-CN Power problems were identified in some of the SBS refrigerators with VNTU-type electronic units. Models concerned: KE 9600-1-2T/KE 9600-1-2T-CN Production before March 2016 Product numbers 7292248782 and 7292248784 Solution A new electronic unit with corresponding cables, spare-part no. 442556, must be installed in these appliances.
- Page 2 T8-94-03 Procedure 1. Disconnect the appliance from the power supply. 2. Remove the control circuit board and all the plug connections. 3. Change the electronic unit. 4. Change the wiring. Pull out the double clamp and change the black cable as follows: Internal use only...
- Page 3 T8-94-03 The black cable can be shortened up as follows: Open the plastic clip. Press hard on the metal clamp for fastening and close the plastic clip again. Insert all the cables into the electronic unit again. Appliance marking Once electronic unit been...
- Page 4 T8-94-03 Power-down mode of the display circuit board The new software switches the appliance to the power-down mode after a few minutes, which fades out the temperature display. This mode is show on the display with a green LED. The functioning of the appliance thus remains unchanged.
