Summary of Contents for Kuppersbusch KSG1222
- Page 1 KSG1222 Instruction Manual Bedienungsanleitung Notice d'Utilisation...
- Page 2 Please read this manual first! Dear Customer, We hope that your product, which has been produced in modern plants and checked under the most meticulous quality control procedures, will provide you an effective service. For this, we recommend you to carefully read the entire manual of your product before using it and keep it at hand for future references.
-
Page 3: Table Of Contents
CONTENTS 1 Your refrigerator 5 Using your refrigerator 14 Thermostat setting button....14 2 Important Safety Cooling ..........15 Warnings Freezing ...........15 Intended use ........5 Defrost ..........15 General safety ........5 Stopping your product .....16 Child safety ........7 6 Maintenance and HCA Warning ........8 cleaning Things to be done for energy saving ..8 Protection of plastic surfaces ..17... -
Page 4: Your Refrigerator
Your refrigerator 1. Dairy comparment 8. Movable shelves 2. Adjustable door shelves 9. Wine rack 3. Egg tray 10. Light bulb and thermostat box 4. Bottle shelves 11. a.) Freezing compartment & ice 5. Crispers tray (for models) 6. Crisper cover b.) Frozen food compartment &... -
Page 5: Important Safety Warnings
Important Safety Warnings Please review following • Do not touch frozen food by hand; information. If these are not followed, they may stick to your hand. personal injury or material damage • Vapor and vaporized cleaning may occur. Otherwise, all warranty and materials should never be used in reliability commitments will become cleaning and defrosting processes of... - Page 6 • Place the beverage with higher proofs • Do not hook up the refrigerator to tightly closed and vertically. electronic energy saving systems as it may damage the product. • Flammable items or products that contain flammable gases (e.g. spray) •...
-
Page 7: Child Safety
• Do not place objects filled with water Otherwise condensation may occur on top of the refrigerator as it may on the side walls facing each other. result in electric shock or fire. • Water mains pressure must not be •... -
Page 8: Hca Warning
HCA Warning Things to be done for energy saving If your product is equipped with a cooling system that contains • Do not leave the doors of your R600a: refrigerator open for a long time. This gas is flammable. Therefore, pay •... -
Page 9: Installation
Installation Before operating your Please remember that the refrigerator manufacturer shall not be held liable if the information given in the instruction Before starting to use your refrigerator manual is not observed. check the following: 1. Is the interior of the refrigerator dry Points to be considered and can the air circulate freely in the when re-transporting your... -
Page 10: Disposing Of The Packaging
Electric connection Disposing of your old refrigerator Connect your product to a grounded socket which is being protected by a Dispose of your old machine without fuse with the appropriate capacity. giving any harm to the environment. Important: • You may consult your authorized •... -
Page 11: Replacing The Interior Light Bulb
Replacing the interior light bulb Should the light fail to work switch off at the socket outlet and pull out the mains plug. Follow the below instructions to check if the light bulb has worked itself loose. If the light still fails to work obtain a replacement E14 screw cap type 15 Watt (Max) bulb from your local electrical store and then fit it as follows:... -
Page 12: Reversing The Doors
Reversing the doors... -
Page 13: Preparation
Preparation "Your refrigerator should be installed at least 30 cm away from heat sources such as hobs, ovens, central heater and stoves and at least 5 cm away from electrical ovens and should not be located under direct sunlight. The ambient temperature of the room where you install your refrigerator should at least be 10°C. -
Page 14: Using Your Refrigerator
Using your refrigerator Thermostat setting button to close the door again as soon as possible after use. The interior temperature of your refrigerator changes for the following reasons; • Seasonal temperatures, • Frequent opening of the door and leaving the door open for long periods, •... -
Page 15: Cooling
Cooling Defrost Food storage A) Fridge compartment The fridge compartment is for the Fridge compartment performs full- short-term storage of fresh food and automatic defrosting. Water drops and drinks. a frosting up to 7-8 mm can occur on the inner rear wall of the fridge Freezing compartment while your refrigerator Freezing food... -
Page 16: Stopping Your Product
B) Freezer compartment Defrosting is very straightforward and without mess, thanks to a special defrost collection basin. Defrost twice a year or when a frost layer of around 7 (1/4”) mm has formed. To start the defrosting procedure, switch off the appliance at the socket outlet and pull out the mains plug. -
Page 17: Maintenance And Cleaning
Maintenance and cleaning Protection of plastic Never use gasoline, benzene or similar surfaces substances for cleaning purposes. We recommend that you unplug the Do not put the liquid oils or oil-cooked appliance before cleaning. meals in your refrigerator in unsealed containers as they damage the plastic Never use any sharp abrasive surfaces of your refrigerator. -
Page 18: Recommended Solutions For The Problems
Recommended solutions for the problems Please review this list before calling the service. It might save you time and money. This list includes frequent complaints that are not arising from defective workmanship or material usage. Some of the features described here may not exist in your product. - Page 19 • Your new product may be wider than the previous one. This is quite normal. Large refrigerators operate for a longer period of time. • The ambient room temperature may be high. This is quite normal. • The refrigerator might have been plugged in recently or might have been loaded with food.
- Page 20 The operation noise increases when the refrigerator is running. • The operating performance of the refrigerator may change due to the changes in the ambient temperature. It is normal and not a fault. Vibrations or noise. • The floor is not even or it is weak. The refrigerator rocks when moved slowly. Make sure that the floor is strong enough to carry the refrigerator, and level.
