Summary of Contents for LSI LASTEM E-Log
- Page 1 Environmental monitoring solutions E-Log Quick Start Update 27/10/2022 Cod. MW6160...
-
Page 2: Table Of Contents
This manual can be modified without notice. Anybody can copy, print or publish this manual without LSI LASTEM written authorization. LSI LASTEM reserves the right to modify the product without an immediate revision of this document. Cod. INSTUM_00951 Page 2 / 19... -
Page 3: Introduction
For special applications, such as - for example – the use of specific communication devices (modem, communicators, Ethernet/RS232 converters etc.) or where the implementation of actuation logics or the setup of calculated measurements is requested, please refer to the E-Log and 3DOM software User Manuals are available on www.lsi-lastem.com... -
Page 4: Installation Procedure
Through 3DOM software, you can perform the instrument configuration, change the system date/time and download stored data by saving them in one or more formats. At the end of the installation procedure, start 3DOM program from LSI LASTEM programs list. The aspect of the main window is as below: 3DOM program uses the Italian language in case of Italian version of the operating system;... -
Page 5: Datalogger Configuration
2.2.1. Starting the instrument All E-Log models can be powered through an external power supply (12 Vcc) or through a terminal board. Refer to the table below for connection to the instrument input plugs and to the output plugs of sensors or electric devices. -
Page 6: Adding The New Instrument To 3Dom Program
Adding the new instrument to 3DOM program Connect your PC to serial port 1 through the supplied ELA105 serial cable. Start 3DOM program from the LSI LASTEM programs list, select Instrument-> New…and follow the guided procedure. Set as communication parameters: •... -
Page 7: Instrument Configuration
It is recommended to create a new configuration starting from the basic one or from one of the available models. In the first case, proceed as follows: ➢ Start the 3DOM program from the LSI LASTEM program list; ➢ Select your instrument serial number in the Instruments panel;... - Page 8 3DOM contains a registry of LSI LASTEM sensors where each sensor is suitably configured to be acquired by E-Log. If the sensor was provided by LSI LASTEM, simply press the Add button, carry out the sensor research by setting the sensor commercial code or by searching it in its category and press the OK button.
- Page 9 E-Log – Quick start • Calculated measure: Besides, if a measure is used by a derived quantity, the icon changes: The measures order can be changed according to your requirements by pressing the Sort button. It is however advisable to keep coupled the quantities that need to be acquired together (for ex.: wind speed and direction) and give priority to the measures with a fast acquisition rate, moving them on top of the list.
-
Page 10: Creating A Configuration Report
If some measures have no connection assigned, a possible cause could be that the measure was created without using the LSI LASTEM sensors registry. It is recommended to print the document in order to be able to use it later when connecting the probes to the datalogger. - Page 11 E-Log – Quick start TERMINAL BOARD Analogue Signal Actuators Input Number Digital Signal Actuators Input Number Frequency signal from optoelectronic Digital status (on/off) Digital status of frequency signal probe Sensors with digital signal Cod. INSTUM_00951 Page 11 / 19...
- Page 12 Current signal from 2 wires probe Current signal from 4 wires sensor (powered from signal wires) powered (fixed or switched) from E-Log Probe power supply Probe power supply * the shortcut is only required for the sensors with the universal power supply Sensors with analog signal (single ended mode) Cod.
-
Page 13: Serial Connection
50 Ω to obtain voltage signals up to 1 V. 2.4.2. Serial connection Serial output probes can be connected only to the datalogger serial port 2. In order to allow E-Log to acquire correct data, the set communication parameters should be suitable to the connected probe type. -
Page 14: Saving Data On A Gidas Database
3.2. Saving data on a Gidas database Note To store data on LSI LASTEM Gidas database for SQL Server 2005, you need to install the GidasViewer program: it provides for the installation of the database and requests the activation license for each instrument. Gidas database needs a SQL Server 2005 installed in the PC: if the user hasn’t got this program installed, the free “Express”... - Page 15 E-Log – Quick start This window displays the Gidas data source in use and allows its change. To change the data source used by the program, select an item from the list of the available data sources or add a new one by pressing Add;...
- Page 16 E-Log – Quick start Specify the SQL Server 2005 instance where to connect and check connection with button. The list only shows the instances in the local computer. SQL Server instances are identified as follows: servername\instance name where servername represents the network name of the computer where SQL Server is installed; for local instances, either the computer name, the name (local) or the simple dot character can be used.
-
Page 17: Receiving Elaborated Data
E-Log – Quick start 4. Receiving elaborated data To receive the elaborated data from 3DOM, select the Communication-> Elaborated Data… menu or press the Elab. Values button on the instrument bar of Instrument or the Elaborated Data… contextual menu of the instrument. -
Page 18: Displaying Elaborated Data
E-Log – Quick start 5. Displaying elaborated data The elaborated data filed in Gidas database can be displayed with Gidas Viewer software. At startup, the program has the following aspect: To display data, proceed as follows: ➢ Expand the branch corresponding to the instrument serial number that appears in the Data Browser;... - Page 19 E-Log – Quick start ➢ To display the chart select Show Chart on the table with the right key of your mouse. Enjoy your E-Log Cod. INSTUM_00951 Page 19 / 19...
