Summary of Contents for LSI LASTEM ESV108
- Page 1 Environmental monitoring solutions Hot-wire anemometers cod. ESV108, ESV108.1, ESV308, EXP126 User manual...
-
Page 2: About This Manual
LSI LASTEM. LSI LASTEM reserves the right to carry out changes to this product without timely updating of this document. Copyright 2024 LSI LASTEM. All rights reserved. - Page 3 Maintenance ............................... 8 Accessories / Spare parts ........................... 9 Handling ..............................9 Storage, packaging, preservation, delivery ....................9 10 Disposal ..............................9 11 How to contact LSI LASTEM ........................10 12 CE conformity declaration ........................11 LSI LASTEM SRL INSTUM_05555 Pag. 3 / 11...
- Page 4 Models ESV108-ESV108.1 measure air velocity and output the average value of all measurements sampled every 100 ms (10 Hz). Model ESV308 is similar to model ESV108 but has a digital output for transmitting measurements over a serial line; this output is compatible with the RS232-2 port on E/M-Log data loggers.
-
Page 5: General Safety Rules
• Accuracy respected for Va >= 0.1 m/s Protection grade IP54 Operative temperature -40 ÷ 85 °C Cable L=1 m (ESV308, ESV108); L=10 m (ESV108.1); L=5 m + DEA261.2 (EXP126) Mounting On BVA320 stand Radio (EXP126 only) Frequency 869.450 MHz Radio transmission power 25 ±3 mW... -
Page 6: Mechanical Mounting
The ESV308 sensor with RS-232 serial output is equipped with a DB9 connector, compatible for connection to serial port 2 of LSI LASTEM data loggers. It is necessary to configure the communication speed of the data logger's serial line to 9600 bps and to use the proprietary CISS protocol. -
Page 7: Troubleshooting
The sensor does not switch on or switches on intermittently. Cause 1. Data logger not configured in the right way. 2. Measurement sampling rate too slow, actuator powered off. 3. Incorrect data logger version. 4. Damaged sensor. LSI LASTEM SRL INSTUM_05555 Pag. 7 / 11... -
Page 8: Maintenance
The probe does not require any maintenance; only a particular care on probe’s movement is required because of its delicate sensitive element. In case of break of tungsten wire, send the probe to LSI LASTEM for the reparation. If you are in possession of the SPMCA1004 kit and the SVSKA202 cable, you can proceed with the hot-wire head replacement yourself as described in the INSTUM_05564 manual. -
Page 9: Accessories/Spare Parts
(RAEE). For this reason, at the end of its life, the instrument must be kept apart from other wastes. LSI LASTEM is liable for the compliance of the production, sales and disposal lines of this product, safeguarding the rights of the consumer. Unauthorized disposal of this product will be punished by the law. -
Page 10: How To Contact Lsi Lastem
Hot-wire anemometer – User manual 11 How to contact LSI LASTEM In case of problem contact the technical support of LSI LASTEM sending an e-mail to support@lsi-lastem.com, or compiling the technical support request module at www.lsi-lastem.com. For further information refer to addresses and numbers below: •... -
Page 11: Ce Conformity Declaration
Hot-wire anemometer – User manual 12 CE conformity declaration LSI LASTEM SRL INSTUM_05555 Pag. 11 / 11...
