VIBIA Class 2800 Assembly Instructions Manual page 8

Step 3/5
Installation Preparation
3.4
- Nuts (not supplied)
- Tuercas (no suministrados)
- Mutter (nicht im Lieferumfang)
- Dadi (non incluse)
- Écrou (non fournies)
- Screws (not supplied)
- Tornillos (no suministrados)
- Schrauben (nicht im Lieferumfang)
- Viti (non incluse)
- Vis (non fournies)
8/17
ANCHOR BOLT OPTION
CONCRETE SCREWS OPTION
- Holes for drainage
- Agujeros de drenaje
- Entwässerungsloch
- Foro di drenaggio
- Orifice d'évacuation
- Holes for drainage
- Agujeros de drenaje
- Entwässerungsloch
- Foro di drenaggio
- Orifice d'évacuation
