Major Component Specifications - Argo ASS36PH Technical Data & Service Manual

1-2 Major Component Specifications

ASS36PH
Controller PCB
Part No.
Controls
Fan & Fan Motor
Type
Q'ty ....... Dia. and lenght
Fan motor model...Q'ty
No. Of poles...rpm (230 V, High/Med/Low/LowLow)
Running Amps
Power input
Coil resistance (Ambient temp. 20 °C )
Safety devices
Run capacitor
Panel
Model
Flap motor
Dew proof heater
Heat Exch. Coil
Coil
Rows
Fin pitch
face area
Type
Operating temp. Open
Close
rating
rpm
nominal output
coil resistance (25°C)
1.... Ø 280 L 166
mm
K35407-MO1972 ...1
4... 880/740/660/290
A
W
Ω
BLU-BRN: 33,9 ÷ 39,1
BLU-BLK: 325 ÷ 374
BLK-GRY: 78,7 ÷ 90,5
GRY-RED: 49,7 ÷ 57,2
RED-WHT/YEL: 155 ÷ 178
Internal thermal protector
°C
Automatic reclosing
°C
µF
VAC
W
kΩ
Aluminium plate fin / Copper tube
mm
m2
DATA SUBJECT TO CHANGE WITHOUT NOTICE
6
CR-CRP50A-B
Microprocessor
Centrifugal fan
0,27
61
150 ± 10
2,0
440
ASGM0918
M2LB24ZA12
240 VAC
2,5
3
15,62 ± 15%
240 V, 26W
1
1,3
0,258
