TECHNICAL DATA & SERVICE MANUAL INDOOR UNIT: ASR525CL ASR536CL ASR548CL SPLIT SYSTEM AIR CONDITIONER Model No. Product Code No. ASR525CL 387006100 ASR536CL 387006101 ASR548CL 387006102 0.8180.365.0 10/2004... - Page 2 IMPORTANT! • Ground the unit following local electrical codes. • The Yellow/Green wire cannot be used for any connection Please read before installation different from the ground connection. • Connect all wiring tightly. Loose wiring may cause overheating This air conditioning system meets strict safety and operating at connection points and a possible fire hazard.
-
Page 3: Table Of Contents
Table of Contents Page 1. SPECIFICATIONS 1-1 Unit specifications 1-2 Major Component specifications 1-3 Other Component specifications 2. DIMENSIONAL DATA 3. ELECTRICAL DATA 3-1 Electric Wiring Diagram 3-1 Schematic Diagram 4. FUNCTION 4-1 Room Temperature Control 4-2 Freeze Prevention 5. TROUBLESHOOTING 6. -
Page 4: Specifications
1. SPECIFICATIONS 1-1 Unit Specifications ASR525CL 220 - 240V ~ 50Hz Power source 230V Voltage rating Cooling Performance See catalogue with the requested matching Capacity 1140/1020/840 Air circulation (High/Med./Low) m³/h Features Controls/Temperature controls Microprocessor/ I.C. thermostat Wireless remote control unit... - Page 5 ASR536CL 220 - 240V ~ 50Hz Power source 230V Voltage rating Cooling Performance See catalogue with the requested matching Capacity Air circulation (High/Med./Low) m³/h 1920/1680/1320 Features Microprocessor/ I.C. thermostat Controls/Temperature controls Wireless remote control unit Remote Controller ON/OFF 24 hours & Daily program, 1-hour OFF Timer 3 and Auto Fan speed...
- Page 6 ASR548CL 220 - 240V ~ 50Hz Power source 230V Voltage rating Cooling Performance See catalogue with the requested matching Capacity Air circulation (High/Med./Low) m³/h 1920/1680/1320 Features Microprocessor/ I.C. thermostat Controls/Temperature controls Wireless remote control unit Remote Controller ON/OFF 24 hours & Daily program, 1-hour OFF Timer 3 and Auto Fan speed...
-
Page 7: Major Component Specifications
1-2 Major Component Specifications ASR525CL Controller PCB CR-XR254GS Part No. Microprocessor Controls Fan & Fan Motor Centrifugal fan Type 1…. Ø 443 Q'ty ……. Diameter Fan motor model…Q'ty SFG6X-41D6P…1 6 … 470 No. Of poles…rpm (230 V, High) Running Amps... - Page 8 ASR536CL Controller PCB CR-XR254GS Part No. Microprocessor Controls Fan & Fan Motor Centrifugal fan Type 1…. Ø 443 Q'ty ……. Diameter Fan motor model…Q'ty SFG6X-81A6P…1 6 … 530 No. Of poles…rpm (230 V, High) Running Amps 0,765 Power input Coil resistance (Ambient temp. 20 °C ) Ω...
- Page 9 ASR548CL Controller PCB CR-XR254GS Part No. Microprocessor Controls Fan & Fan Motor Centrifugal fan Type 1…. Ø 443 Q'ty ……. Diameter Fan motor model…Q'ty SFG6X-81A6P…1 6 … 530 No. Of poles…rpm (230 V, High) Running Amps 0,871 51,9 Power input Coil resistance (Ambient temp.
-
Page 10: Other Component Specifications
1-3 Other Component Specifications ATR-II215TA Trasformer VAC 230V, 50Hz Rating Primary 10,6V - 0.93A Secondary 7 VA Capacity Coil resistance Ω (WHT-WHT): 96,5 (BRN-BRN): 0,8 (at 20°C) Thermal cut-off temp. 150°C PBC-41E-S14 Thermistor ( Coil sensor ) -10 °C 23,7 ± 5% Resistance ΚΩ... -
Page 11: Dimensional Data
2. DIMENSIONAL DATA ASR525CL 820 (Ceiling opening) 757 (Suspention bolt pitch) Air intake grille Air outlet Refrigerant liquid line [D. 9.52 (In case of 25 type , use the tube connector.)] Refrigerant gas line D. 12.7: 9, 12 type Drain connection... - Page 12 ASR536CL ASR548CL 820 (Ceiling opening) 757 (Suspention bolt pitch) Air intake grille Air outlet Refrigerant liquid line (D.9.52) Refrigerant gas line (D.19.05) Drain connection Power supply entry For discharge duct For fresh air intake Suspension bolt mounting...
-
Page 13: Electrical Data
3. ELECTRICAL DATA 3-1 Electric Wiring Diagram IND LAMP ASSY SWITCH ASSY CONNECTOR 4P(WHT) 2P (RED) 2P (YEL) 3P (WHT) 7P (WHT) 3P (RED) 3P (GRN) COIL ROOM SW ASSY W/LESS CONTROLLER (CR-XR254GS) (WHT) 3P (WHT) 5P (WHT) 2P (WHT) 3P (BLU) 3P (RED) 2P (WHT) -
Page 14: Schematic Diagram
3-2 Schematic Diagram CR-XR254GS 4P-2 CONTROLLER RY01 RY02 RY03 RY04 RY05 RY06 4P-4 COIL 49FMI RY08 ROOM 4P-1 F01 (3.15A) SYMBOLS DESCRIPTION INDOOR FAN MOTOR 49FMI INDOOR MOTOR THERMAL PROTECTOR RUNNING CAPACITOR FUSE DRAIN PUMP DEW PROOF HEATER AUTO LOUVER MOTOR POWER TRANSFORMER RY01-RY06, AUXILIARY RELAY... -
Page 15: Function
4. FUNCTIONS 4-1 Room temperature control Room temperature control is obtained by cycling the compressor ON and OFF under control of the room temperature sensor in the remote control unit. The room temperature (and other information) is transmitted every 5 minutes by the remote control unit to the controller in the indoor unit. -
Page 16: Freeze Prevention
4-2 Freeze Prevention This function prevents freezing of the indoor heat exchange coil. When the compressor has been running for 6 minutes or more and the temperature of the indoor heat exchange coil falls below –0.8°C, the control circuit stops the compressor for at least 3 minutes. The compressor does not start again until the temperature rises above 8°C or 6 minutes has elapsed. -
Page 17: Troubleshooting
5. TROUBLESHOOTING (1) Check before and after troubleshooting Many problems may occur because of wiring or power supply problems, and so you should check these areas first. Problems here can cause incorrect results in some of the other tests, and so they should be remedied first. - Page 18 (2) Air conditioner does not operate 1. Circuit breaker trips (or fuse blows). (a) When the circuit breaker is set to ON, it trips immedialely. • There is a possibility of ground fault. • Check insulation resistance. If the resistance value is 1M½ or less, insulation is defective. (Example) Outdoor Indoor...
- Page 19 (b) Circuit breaker trips in several minutes after turning the air conditioner on. • There is a possibility of short circuit. • Check capacity of circuit Replace it with a breaker. suitable one. Is capacity of circuit (= larger capacity) breaker sufficient ? •...
- Page 20 Check “Operation selector” switch in the indoor unit. • Has “Operation selector” IND. LAMP Ass’y or P.C.B. switch been set to ON Ass’y in the indoor unit position ? is defective. Set “Operation selector” switch to ON. Neither unit runs. Switch Ass’y or P.C.B.
- Page 21 Check the auxiliary relay. (1Y or 2Y) • Check coil resistance of auxiliary relay. (1Y or 2Y) Check the indoor fan motor thermal protector (49FMI) • Disconnect the socket from the 9P (WHT) connector. • Check the continuity between No. 8 and No.9 poles of the 9P socket.
- Page 22 Outdoor unit does not run. Check the COOL/FAN selector switch in the remote control unit. • Is COOL/FAN selector switch Set to COOL. set to COOL ? Check the set temperature. Try to lower set temperature using temperature setting button “COOLER”. •...
- Page 23 Check the compressor motor thermal protector (49C) • Check compressor motor Is temperature of compressor thermal protector. (49C) abnormally high ? Insufficient refrigerant gas. Charge refrigerant gas. Compressor is defective. • Check compressor motor magnetic contactor. (52C) (Only the outdoor fan does not run.) Check the indoor unit P.C.B.
- Page 24 Indoor unit does not run. The indoor fan and louver motor do not run. P.C.B. Ass’y is defective. Some parts fail to operate. (1) Only indoor fan does not run. Check fan casing Remove foreign for foreign matter matter or repair. Fan cannot on inside.
- Page 25 Outdoor fan does not run. • Check fan casing Remove foreign for foreign matter matter or repair. Fan cannot on the inside. be rotated. • Check fan rotation. Rotate fan gently once or twice by hand. • Fan motor burnout Repair or replace.
- Page 26 Poor cooling Check position of remote Change position of control unit. remote control unit. • Does cool air from air condi- tioner reach remote control unit directly ? Insulate wide tube and • Is wide tube between indoor unit then execute taping with and outdoor unit insulated ? narrow tube.
- Page 27 (11) PCB for "SCL" models S002 1 2 3 LED1 LED2 S001 D005 S002 (Capacity Code) 25 type 36 type 48 type Meaning of LED indication LED1 LED2 D005 Cause of trouble Light Light Normal state Light Light High pressure switch is activated, Light Flash Outdoor fan thermal protector activated,...
- Page 28 (12) Defective Sensor. 1. Indoor (heat exchanger) coil temp. Sensor is defective. (a) Open (=No continuity in sensor) Compressor and outdoor fan repeatedly go ON for 10 minutes and OFF for 6 minutes when sensor opens. (b) Short “Freeze Prevention” does not operate when dehumidified water is frozen on the indoor coil. 2.
-
Page 29: Checking Electrical Components
6. CHECKING ELECTRICAL COMPONENTS 6-1 Measurement of Insulation power plug (Local supply) Resistance Ground The insulation is in good condition if the resistance exceeds 1MΩ probe Insulation tester NOTE 6-1-1. Power supply wires The shape of the power plug may differ from that of the air conditioner which you are servicing. -
Page 30: Checking Continuity Of Fuse On Pcb Ass'y
6-2 Checking Continuity of Fuse on PCB Ass'y Fuse Remove the PCB Ass'y from the electrical component box. Then pull out the fuse from the PCB Ass'y. (fig.5) PCB Ass’y Check for continuity using a multimeter as shown in fig.6 Fig. -
Page 31: Thermistor Characteristic Curve
6-4 Thermistor Characteristic Curve Room temp. sensor Coil sensor (KTEC-35) (PBC-41E) –20 –15 –10 –5 Temperature ( ° C) Temperature (°C) - Page 32 Via Varese, 90 - 21013 Gallarate - Va - Italy Tel. +39 0331 755111 - Fax +39 0331 776240 www.argoclima.it...
